1.3 Terminology used
Term Meaning
Drive Lenze inverter of the "Servo Drives 9400" product series for which the
communication module can be used.
Application as directed
( 13)
Inverter
Standard device
CN Controlled Node (POWERLINK slave)
Code Parameter which serves to parameterise and monitor the drive. In normal usage,
the term is usually referred to as "Index".
Subcode If a code contains several parameters, they are stored in "subcodes".
In the documentation, the slash "/" is used as a separator between the code and
the subcode (e.g. "C00118/3").
In everyday language, the term is also referred to as "subindex".
»Engineer« Lenze PC software which supports you during the "Engineering" process
(parameterisation, diagnostics, and configuration) throughout the whole life
cycle, i. e. from planning to maintenance of the machine commissioned.
EPL Abbreviation for "Ethernet POWERLINK"
(EPL) nodes POWERLINK nodes (Managing Node, Controlled Nodes)
POWERLINK is a real-time capable fieldbus system based on Ethernet. For user
data exchange, POWERLINK specifies a communication protocol based on
CANopen.
POWERLINK is a patented technology, licenced by the Ethernet POWERLINK
Standardization Group (EPSG), Germany.
HW Hardware
Host SPS, Managing Node (POWERLINK master)
Lenze setting Default settings of the device, preconfigured ex works.
Basic setting
MN Managing Node (POWERLINK master)
The Managing Node accepts the control function for the data communication of
the decentralised field devices. Typically, the Managing Node is the
communication interface of a PLC.
Node ID POWERLINK node address
SW Software
