Instruction Manual

11 Parameter reference
11.2 Parameters of the communication module for slot MXI1
89
Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13132
C13136
C13203
C13205
Parameter | Name:
C13132 | EPL CN: Link interruptions
Data type: UNSIGNED_32
Index: 11443 = 0x2CB3
EPL index: 0x1C10
The code indicates the counter of the Controlled Node for POWERLINK connection interruptions (C13118).
Each event is counted. Every single event is followed by an error message. No threshold value management is
implemented.
Display area (min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13136 | EPL telegram counter
Data type: UNSIGNED_32
Index: 11439 = 0x2CAF
EPL index: 0x1101.0x01
The subcodes of the code indicate a counter for EPL cycles. The counter is started with each mains power-up of the
EPL node at 0. An overflow occurs at 4.294.967.295.
Display area (min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13203 | EPL CN response error
Data type: UNSIGNED_32
Index: 11372 = 0x2C6C
EPL index: See subcodes
The subcodes of the code indicate Controlled Node-specific cumulative counters for missing PRes frames. The
behaviour corresponds to a node The behaviour corresponds to subcode 1 of the single error counters.
Each subcode corresponds to an EPL node with node ID = subcode number.
Display area (min. value | unit | max. value)
0 4294967295
Subcodes Info EPL index
C13203/1 Managing Node 0x1C07.0xF0
C13203/2 Diagnostics device 0x1C07.0xFD
C13203/3 router 0x1C07.0xFE
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13205 | EPL CN response error: Monit. thresholds
Data type: UNSIGNED_32
Index: 11370 = 0x2C6A
EPL index: See subcodes
Setting range (min. value | unit | max. value)
0 1000
Subcodes Lenze setting Info EPL index
C13205/1 0 Managing Node 0x1C09.0xF0
C13205/2 0 Diagnostics device 0x1C09.0xFD
C13205/3 9 router 0x1C09.0xFE
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
