Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17 92
11 Parameter reference
11.2 Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13229
C13231
C13232
C13233
Parameter | Name:
C13229 | EPL multi-stage node declaration MN
Data type: UNSIGNED_8
Index: 11346 = 0x2C52
EPL index: See subcodes
This code indicates in which multiplexed cycle the node is queried. The value entered must not exceed the value in
code C13074
.
If, for instance, the value "3" is entered in code C13074
, the multiplexed cycle is repeated every three cycles. If now
the value "3" is entered for one node in C13229/x, it is always queried only in the second cycle of the three
multiplexed cycles.
Setting range (min. value | unit | max. value)
0 Cycles 255
Subcodes Lenze setting Info EPL index
C13229/1 0 cycles Managing Node 0x1F9B.0xF0
C13229/2 0 cycles Diagnostics device 0x1F9B.0xFD
C13229/3 0 cycles router 0x1F9B.0xFE
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13231 | EPL RPDO
Data type: UNSIGNED_64
Index: 11344 = 0x2C50
EPL index: See subcodes
EPL RPDO-1
Subcodes Lenze setting Info EPL index
C13231/1 0 EPL RPDO 0x1600.0x01
... ... ... ...
C13231/32 0 EPL RPDO 0x1600.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13232 | EPL RPDO
Data type: UNSIGNED_64
Index: 11343 = 0x2C4F
EPL index: See subcodes
EPL RPDO-2
Subcodes Lenze setting Info EPL index
C13232/1 0 EPL RPDO 0x1601.0x01
... ... ... ...
C13232/32 0 EPL RPDO 0x1601.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13233 | EPL RPDO
Data type: UNSIGNED_64
Index: 11342 = 0x2C4E
EPL index: See subcodes
EPL RPDO-3
Subcodes Lenze setting Info EPL index
C13233/1 0 EPL RPDO 0x1602.0x01
... ... ... ...
C13233/32 0 EPL RPDO 0x1602.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
