User guide

Table Of Contents



EDK94ZPM113 DE/EN/FR/ES/IT 4.0

Scope of supply

Pos. Description



Installation backplane



Shield mounting kit for control cable and thin motor cable

Device size 1: 3 pieces

Device sizes 2 and 3: 2 pieces



Shield mounting kit for motor cable (only device sizes 2 and 3: 1 piece)

Mounting Instructions

Elements of the installation backplane

Pos. Description

 Nameplate

 DC−bus fuse

(tightening torque for screw design: 8 ... 8.5 Nm (70.8 ... 75.2 lb−in))

 Connection for motor brake control (accessories, optional)

 Locking clip

 Shield connection

X100 DC−bus voltage connection

l As an alternative to using X109/X110 busbars

l Compatible to 9300 series

l Not fused via 

X105 Motor connection

X106 Connection for motor temperature monitoring

X109

Busbars for DC−bus connection

X110

Validity information

These instructions are valid for

ƒ E94AZPMxxxx installation backplane
