Mechanical installation
Mounting steps
3
36
EDK94ZPM113 DE/EN/FR/ES/IT 4.0
3.3 Mounting steps
Mounting procedure:
1. Prepare M5 threaded holes on the mounting plate according to the
mounting grid.
– Start on the left with the mounting backplane of DC−supply module
E94AZPNxxxx or with DC input module E94AZEX100.
– Install the axis modules from the left to the right with decreasing rated
power.
– Axis modules E94AMxE0324 and installation backplane E94AZPM0324
can only be connected directly to each other! A use with another device
or installation backplane of size 3 is not permissible and is prevented
through a plug protection.
2. Screw the mounting backplane onto the mounting plate. Do not yet
tighten the screws.
– Use M5 screw and washer assembly or M5 hexagon socket screws with
washer.
– The screw joint in the installation backplane may not jut out more than
7 mm.
3. Align all components.
Note!
The installation backplane fixing screws are not tightened until the
busbars are connected.
