Leviton’s new line of 20 Amp Stage Pin Connectors has been redesigned to be more user-friendly, durable and safe.
The new ergonomic profi le fi ts more comfortably in your hand, making it much easier to assemble and disassemble.
This results in reduced fatigue for both the assembler and the user who frequently connects and disconnects cable
assemblies. The unique profi le also increases safety, as it is less likely to get entangled with other equipment.
The re-designed strain relief system offers 30% more gripping power than the competitors offering, reducing
the chance of personal injury or property damage that results when cables are accidentally stripped from their
connectors under load. The additional strain relief power also helps extend cable assembly life, saving you time
and money over its lifetime.
Applications
Theatres
Studios
Schools
Entertainment Venues
Concert Halls
Anywhere theatrical lighting is required
Features & Benefi ts
Male pins and female contacts have a one-piece solid brass design for superior current fl ow
and resistance from abuse.
“Split” pins and contacts provide a spring action that extends life by compensating for wear.
Pins and contacts “fl oat” for improved electrical connections.
USITT S3 compliance ensures compatibility with all competitive products.
Terminal identifi cation letters molded into device ensure quick and accurate termination.
Superior ergonomic design reduces user fatigue and provides for safer connect/disconnect.
Covers available in a variety of colors, and can be engraved or hot stamped with custom markings.
