Security menu
Miscellaneous Security Settings menu
Menu item Description
Login Restriction
Login failures
1–10
Failure time frame
1–60
Lockout time
1–60
Panel Login Timeout
1–900
Remote Login Timeout
1–120
Limits the number and time frames of failed login attempts from the printer control
panel before all users are locked out
Notes:
• “Login failures” specifies the number of failed login attempts before users are
locked out. 3 attempts is the factory default setting.
• “Failure time frame” specifies the time frame during which failed login attempts
can be made before users are locked out. 5 minutes is the factory default setting.
• “Lockout time” specifies how long users are locked out after exceeding the login
failures limit. 5 minutes is the factory default setting.
• Panel Login Timeout specifies how long the printer remains idle on the home
screen before automatically logging the user off. 30 seconds is the factory default
setting.
• Remote Login Timeout specifies how long a remote interface (for example, a
Web page) can remain idle before automatically logging the user off. 10 minutes
is the factory default setting.
Confidential Print menu
Menu item Description
Max Invalid PIN
Off
2–10
Limits the number of times an invalid PIN can be entered
Notes:
• This menu appears only if a formatted, non-defective printer hard disk is installed.
• Once the limit is reached, the print job for that user name and that PIN are deleted.
Confidential Job Expiration
Off
1 hour
4 hours
24 hours
1 week
Limits the amount of time a confidential print job stays in the printer before it is deleted
Notes:
• If the Job Expiration setting is changed while confidential print jobs reside on the printer
RAM or printer hard disk, then the expiration time for those print jobs does not change
to the new default value.
• If the printer is turned off, then all confidential jobs held in printer RAM are deleted.
Repeat Job Expiration
Off
1 hour
4 hours
24 hours
1 week
Sets a time limit on how long the printer stores print jobs
Note: Off is the factory default setting.
