Menu item Description
Displayed Information
Waste Toner Bottle
Paper Jam
Load Paper
Service Errors
Lets you customize the displayed information for Waste Toner
Bottle, Paper Jam, Load Paper, and Service Errors
Choose from the following options:
Display
No
Yes
Message to Display
Default
Alternate
Default
[text entry]
Alternate
[text entry]
Notes:
• No is the factory default setting for Display.
• Default is the factory default setting for Message to Display.
Home screen customization
Change Language
Search Held Jobs
Held Jobs
USB Drive
Profiles and Solutions
Bookmarks
Jobs by user
Forms and Favorites
Eco-Settings
Showroom
Change Background
Lets you add or remove icons and buttons that appear on the
home screen
Available options for each button are:
Display
Do Not Display
Date Format
[MM-DD-YYYY]
[DD-MM-YYYY]
[YYYY-MM-DD]
Specifies the format for the printer date
Time Format
12 hour
24 hour
Specifies the format for the printer time
Note: 12 hour is the factory default setting.
Screen Brightness
20–100
Specifies the brightness of the printer control panel screen
Note: 100 is the factory default setting.
