Menu item Description
Output Lighting
Normal/Standby Mode
Off
Dim
Bright
Sleep Mode
Off
Dim
Bright
Sets the amount of light from the optional exit bin
Notes:
• Dim is the factory default setting for Normal/Standby Mode
if Eco-Mode is set to Energy or Energy/Paper.
• Bright is the factory default setting for Normal/Standby
Mode if Eco-Mode is set to Off or Paper.
• Off is the factory default setting for Sleep Mode if Eco-Mode
is set to Energy or Energy/Paper.
• Dim is the factory default setting for Sleep Mode if Eco-Mode
is set to Off or Paper.
Error Lighting
On
Off
Determines if indicator lights will blink when the printer
encounters errors.
Note: On is the factory default setting.
Audio Feedback
Button Feedback
On
Off
Volume
1–10
Notes:
• On is the factory default setting for Button Feedback.
• 5 is the factory default setting for Volume.
Show Bookmarks
Yes
No
Determines whether the Bookmarks icon is displayed
Notes:
• Yes is the factory default setting.
• The Bookmarks icon appears inside Held Jobs. If Show
Bookmarks is set to No, then the Held Jobs icon is only
displayed on the home screen if one or more held jobs exist
on the printer.
Web Page Refresh Rate
30–300
Specifies the number of seconds between Embedded Web Server
refreshes
Note: 120 seconds is the factory default setting.
Contact Name Specifies a contact name for the printer
Location Specifies the location of the printer
Note: The location will be stored on the Embedded Web Server.
