Paper size Standard tray Optional 250‑ or
550‑sheet tray
Multipurpose feeder Duplex mode
DL Envelope
110 x 220 mm (4.3 x 8.7 in.)
XX
X
C5 Envelope
162 x 229 mm (6.4 x 9 in.)
XX
X
B5 Envelope
176 x 250 mm (6.9 x 9.8 in.)
XX
X
Other Envelope
229 x 356 mm (9 x 14 in.)
XX
X
1
This size setting formats the page for 216 x 356 mm (8.5 x 14 in.) unless the size is specified by the software application.
2
Universal is supported in the standard tray only if the paper size is at least 105 x 148 mm (4.1 x 5.8 in.). Universal is supported
in the optional 250- or 550-sheet tray only if the paper size is at least 148 x 210 mm (5.8 x 8.3 in.). Universal is supported
in duplex mode only if the width is at least 210 mm (8.3 in.) and the length is at least 279 mm (11 in.). The smallest supported
Universal size is supported only in the multipurpose feeder.
Supported paper types and weights
The standard tray supports 60–90‑g/m
2
(16–24‑lb) paper weights. The optional tray supports 60–120‑g/m
2
(16–32‑lb)
paper weights. The multipurpose feeder supports 60–163‑g/m
2
(16–43‑lb) paper weights.
Paper type 250‑ or 550‑sheet tray Multipurpose feeder Duplex mode
Plain paper
Card stock X X
Transparencies
X
Recycled
Glossy paper X X X
Paper labels
1
X
Vinyl labels X X X
Bond
2
Envelope X X
Rough envelope X
X
Letterhead
Preprinted
Colored Paper
