Use To
Timeouts
Sleep Mode
Disabled
1–120 min
Set the amount of time the printer waits after a job is printed before
it goes into a reduced power state.
Notes:
• “30 min” is the factory default setting.
• “Disabled” appears only when Energy Conserve is set to Off.
• Lower settings conserve more energy, but may require
longer warm‑up times.
• Select a high setting if the printer is in constant use. Under
most circumstances, this keeps the printer ready to print
with minimum warm‑up time.
To wake the printer from Sleep mode, try one of the following:
• Press any hard button on the printer control panel.
• Open the front door of the printer.
• Remove paper from the standard bin.
• Send a print job from the computer.
• Load paper in the multipurpose feeder.
• Turn off the printer, and then turn it back on.
Timeouts
Hibernate Timeout
Disabled
1 hour
2 hours
3 hours
6 hours
1 day
2 days
3 days
1 week
2 weeks
1 month
Set the amount of time the printer waits after a job is printed before
it enters Hibernate mode.
Notes:
• Disabled is the factory default setting in all countries except
European Union countries and Switzerland.
• 3 days is the factory default setting for all European Union
countries and Switzerland.
• The setting is also disabled if the printer detects an active
Ethernet connection, regardless of country. However, to
enable the setting even with an active Ethernet connection,
click Settings > General Settings > Hibernate Timeout on
Connection > Hibernate.
To wake the printer from Hibernate mode, try one of the following:
• Press the Sleep button for less than three seconds if Press Sleep
Button is set to Hibernate.
• Press and hold the Sleep button for more than three seconds if
Press and Hold Sleep Button is set to Hibernate.
• Turn off the printer, and then turn it back on.
Timeouts
Hibernate Timeout on Connection
Hibernate
Do Not Hibernate
Set the printer to Hibernate mode even if there is an active Ethernet
connection.
Note: Do Not Hibernate is the factory default setting.
Understanding the printer menus 64
