ENGLISH OWNER’S MANUAL IPS LED MONITOR Please read this manual carefully before operating your set and retain it for future reference. IPS LED MONITOR MODEL 24MB35PY www.lg.
TABLE OF CONTENTS CONTENTS ENGLISH ENG 3 ASSEMBLING AND PREPARING 24 SPECIFICATIONS 3 Unpacking 24 24MB35PY 4 Parts and buttons 25 Preset Modes (Resolution) 5 Setting up the Monitor set 25 Indicator 5 - Attaching the Stand Base 5 - Detaching the stand base 26 PROPER POSTURE 6 - Detaching the stand body 26 Proper posture for using the Monitor set.
ASSEMBLING AND PREPARING 3 ASSEMBLING AND PREPARING Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. CD(Owner's Manual) / Card Power Cord Audio Cable ( Depending on the country ) DVI-D Cable D-SUB Cable (This cable is not included in all (This cable is not included in all countries.) countries.
ASSEMBLING AND PREPARING Parts and buttons ENGLISH ENG Power Indicator yyLED On : Power is on yyLED Off: Power is off (Power Button) Front Side Buttons Input Connectors (��������������� See p.
ASSEMBLING AND PREPARING Detaching the stand base Attaching the Stand Base 1 Place the monitor's screen face down. 1 Place the Monitor set with the screen side To protect the screen from scratches, cover the surface with a soft cloth. down on a flat and cushioned surface. CAUTION To protect the screen from scratches, cover yy the surface with a soft cloth. 2 Detach the stand base from the stand body.
ASSEMBLING AND PREPARING Detaching the stand body ENGLISH ENG 1 Place the monitor's screen face down. To protect the screen from scratches, cover the surface with a soft cloth. 2 Using a screwdriver, remove the four screws and detach the stand from the monitor.
ASSEMBLING AND PREPARING Adjusting the angle 1 Lift the monitor and place it on the table in an 1 Place the monitor mounted on the stand base upright position. Install at least 10 cm away from the wall to ensure sufficient ventilation. in an upright position. 2 Adjust the angle of the screen. The angle of the screen can be adjusted up to 5° forwards and 20° backwards for a comfortable viewing experience.
ASSEMBLING AND PREPARING Adjusting the stand height ENGLISH ENG 1 Place the monitor mounted on the stand base in an upright position. 2 Remove the tape attached at the bottom rear of the stand body, then pull out the locking pin. Using the Kensington locking device The connector for the Kensington lock is located on the rear of the monitor. For more information on installation and usage, refer to the Kensington lock user manual or visit the website at http://www.kensington.com.
ASSEMBLING AND PREPARING Swivel stand 1 Swivel 355 degrees and adjust the angle of the Monitor set to suit your view. Using the Pivot function The pivot function allows you to rotate the screen 90 degrees clockwise. 1 Lift the monitor to its highest height to utilize the Pivot function. 2 Landscape & Portrait : You can rotate the panel 90° clockwise. Please be cautious and avoid contact between the monitor head and the Stand Base when rotating the screen to access the Pivot function.
ASSEMBLING AND PREPARING Mounting on a wall Model ENGLISH ENG For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide. 10 cm 10 cm 10 cm 10 cm If you intend to mount the Monitor set to a wall, attach Wall mounting interface (optional parts) to the back of the set.
USING THE MONITOR SET 11 USING THE MONITOR SET Your Monitor set supports Plug & Play*. yy *Plug & Play: A PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention. D-SUB connection Transmits analog video from your PC to the Monitor set. Connect the PC and the Monitor set with the supplied D-sub 15 pin signal cable as shown in the following illustrations.
USING THE MONITOR SET NOTE ENGLISH ENG When you want to use two PC in our Monitor, yy please connect the signal cable(D-SUB/ DVI-D/DP) respectively in Monitor set. If you turn the Monitor set on while it is cold, yy the screen may flicker. This is normal. Some red, green, or blue spots may appear yy on the screen. This is normal. Self Image Setting Function Press the power button on the bottom panel to turn the power on.
USING THE MONITOR SET Peripheral device connection Two USB Downstream ports Connect these ports to a mouse, USB keyboard, memory stick with current spec under 100mA. NOTE Peripheral devices are sold separately. yy The USB ports on the left and bottom of the yy monitor can be used to connect the keyboard, mouse, and other USB devices. Cables with angled plugs may have clearyy ance issues, use straight plugs when possible.
CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS ENGLISH ENG 1 Press the desired button on the bottom of the Monitor set. 2 Change the value of the menu item by pressing the buttons on the bottom of the Monitor set. To return to the upper menu or set other menu items, use the up arrow ( ) button. 3 Select EXIT to leave the OSD menu. Monitor set Buttons Button Description Accesses the main menus.(See p.
CUSTOMIZING SETTINGS 15 Customizing Settings ENG ENGLISH Menu Settings 1 Press MENU button on the bottom of the Monitor set to display the Menu OSD. 2 Set the options by pressing the ◄ or ► or ▼ buttons. 3 Select the "Next Menu" button to enter the more option settings. 4 Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below.
CUSTOMIZING SETTINGS Picture ENGLISH ENG 1 Press MENU button on the bottom of the Monitor set to display the Menu OSD. 2 Select the "Next Menu" button to enter the more option settings. 3 Enter to Picture by pressing the ▼ button. 4 Set the options by pressing the ◄ or ► or ▼ buttons. 5 Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below.
CUSTOMIZING SETTINGS 17 Color ENG ENGLISH 1 Press MENU button on the bottom of the Monitor set to display the Menu OSD. 2 Select the "Next Menu" button to enter the more option settings. 3 Select Color by pressing the ► button. 4 Enter to Color by pressing the ▼ button. 5 Set the options by pressing the ◄ or ► or ▼ buttons. 6 Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below.
CUSTOMIZING SETTINGS Display ENGLISH ENG 1 Press MENU button on the bottom of the Monitor set to display the Menu OSD. 2 Select the "Next Menu" button to enter the more option settings. 3 Select Display by pressing the ► button. 4 Enter to Display by pressing the ▼ button. 5 Set the options by pressing the ◄ or ► or ▼ buttons. 6 Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below.
CUSTOMIZING SETTINGS 19 Others ENG ENGLISH 1 Press MENU button on the bottom of the Monitor set to display the Menu OSD. 2 Select the "Next Menu" button to enter the more option settings. 3 Select Others by pressing the ► button. 4 Enter to Others by pressing the ▼ button. 5 Set the options by pressing the ◄ or ► or ▼ buttons. 6 Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below.
CUSTOMIZING SETTINGS READER Setting ENGLISH ENG 1 Press READER button on the bottom of the Monitor set to display the Reader Mode OSD. 2 Set the options by pressing the ◄ buttons. Each option is explained below. Reader Mode Description Reader 1 It is a mode that the screen is adjusted to the best for the newspaper. If you want screen more bright, you can control brightness in Menu OSD. Reader 2 It is a mode that the screen is adjusted to the best for the cartoon.
CUSTOMIZING SETTINGS 21 SUPER ENERGY SAVING ENG ENGLISH 1 Press button on the bottom of the Monitor set to display the SUPER ENERGY SAVING OSD. 2 Set the options by pressing the ► buttons. Each option is explained below. SUPER ENERGY SAVING Description High Enables SUPER ENERGY SAVING you can save energy with this energy- high efficient function. Low Enables SUPER ENERGY SAVING you can save energy with this energy- low efficient function. Off Disables SUPER ENERGY SAVING.
TROUBLESHOOTING ENGLISH ENG TROUBLESHOOTING Check the following before calling for service. No image appears Is the power cord of the display connected? Is the power indicator light on? Is the power on and the power indicator White? Is the power indicator flickering? Do you see an "OUT OF RANGE" message on the screen? Do you see a "NO SIGNAL" message on the screen? yy Check and see if the power cord is connected properly to the power outlet. yy Press the Power button.
TROUBLESHOOTING 23 CAUTION Display image is incorrect The screen color is mono or abnormal. yy Check if the signal cable is properly connected and use a screwdriver to fasten if necessary. yy Make sure the video card is properly inserted in the slot. yy Set the color setting higher than 24 bits (true color) at Control Panel ► Settings. The screen blinks. yy Check if the screen is set to interlace mode and if yes, change it to the recommend resolution.
SPECIFICATIONS ENGLISH ENG SPECIFICATIONS 24MB35PY Display Sync Input Screen Type 60.4 cm (23.8 inch) Flat Panel Active matrix-TFT LCDAntiGlare coating Visible diagonal size: 60.4 cm Pixel Pitch 0.275 mm x 0.275 mm (Pixel Pitch) Horizontal Frequency 30 kHz to 83 kHz (Automatic) Vertical Frequency 56Hz to 75Hz (D-SUB,DVI-D) 56Hz to 61Hz (Display Port) Separate Sync.
SPECIFICATIONS 25 Preset Modes (Resolution) ENG ENGLISH D-SUB/DVI Timing Display Modes (Resolution) Horizontal Frequency(kHz) Vertical Frequency(Hz) Polarity(H/V) 720 x 400 31.468 70 -/+ 640 x 480 31.469 60 -/- 640 x 480 37.500 75 -/- 800 x 600 37.879 60 +/+ 800 x 600 46.875 75 +/+ 1024 x 768 48.363 60 -/- 1024 x 768 60.023 75 +/+ 1152 x 864 67.500 75 +/+ 1280 x 1024 63.981 60 +/+ 1280 x 1024 79.976 75 +/+ 1680 x 1050 65.290 60 -/+ 1920 x 1080 67.
PROPER POSTURE ENGLISH ENG PROPER POSTURE Proper posture for using the Monitor set. Adjust the Monitor set and your posture to allow you to view images at the optimal viewing angle. Place your hands gently on the keyboard, keeping your arms bent at the elbows and horizontally outright. Adjust the location of the Monitor set to avoid it reflecting light.
Declaration of Conformity Trade Name: LG Model : 24MB35PYI Responsible Party: LG Electronics Inc. Address : 1000 Sylvan Ave. Englewood Cliffs NJ 07632 U.S.A TEL: 201-266-2534 *above information is only for USA FCC Regulatory Make sure to read the Safety Precautions before using the product. Keep the Owner’s Manual (CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service.
