EXTERNAL CONTROL DEVICE SETUP
CommandReferenceList
CommunicationParameters
y Baud rate: 9600 bps (UART)
y Data length: 8 bits
y Parity : None
y Stop bit: 1 bit
y Communication code: ASCII code
y Use a crossed (reverse) cable.
* Note : During USB operations such as DivX or EMF, all commands except Power(ka) and Key(mc) are not
executed and treated as NG.
(Depending on model)(Depending on Model)
COMMAND1 COMMAND2
DATA
(Hexadeci-
mal)
COMMAND1 COMMAND2
DATA
(Hexadeci-
mal)
01. Power k a 00 to 01 13. Balance k t 00 to 64
02. Aspect
Ratio
k c (See p. 34)
14. Colour
Temperature
x u 00 to 64
03. Screen
Mute
k d (See p. 34)
15. Energy
Saving
j q 00 to 05
04. Volume
Mute
k e 00 to 01
16. Auto Con-
figuration
j u 01
05. Volume
Control
k f 00 to 64 17. Equalize j v (See p. 36)
06. Contrast k g 00 to 64
18. Tune Com-
mand
m a
(See p. 36)
07. Brightness k h 00 to 64
19. Programme
Add/Skip
m b 00 to 01
08. Colour k i 00 to 64 20. Key m c (See p. 30)
09. Tint k j 00 to 64
21. Control
Back Light
m g 00 to 64
10. Sharpness k k 00 to 32
22. Input select
(Main)
x b (See p. 37)
11. OSD Select k l 00 to 01
12. Remote
Control
Lock Mode
k m 00 to 01

