ENG ENGLISH OWNER’S MANUAL MONITOR SIGNAGE Please read this manual carefully before operating the your set and retain it for future reference. MONITOR SIGNAGE MODELS 42WS50MW 47WS50MW www.lg.
TABLE OF CONTENTS ENGLISH ENG TABLE OF CONTENTS 4 24 ENTERTAINMENT 24 - Connecting to a wired network ASSEMBLING AND PREPARING 25 - Network Status 26 - Connecting USB storage devices 5 Accessories 27 - Browsing files 6 Optional Accessories 29 - Viewing movies 7 Parts and buttons 32 - Viewing photos 8 Using the Mounting Cable Tie 35 - Listening to music 8 Connecting the Speakers 37 - Viewing the Contents List 9 Connecting the stand 38 - DivX® VOD Guide 9 Using the IR R
TABLE OF CONTENTS TROUBLESHOOTING 62 SPECIFICATIONS 68 IR CODES 69 CONTROLLING THE MULTIPLE PRODUCT 69 Connecting the cable 69 RS-232C Configurations 69 Communication Parameter 70 Command reference list 72 Transmission / Receiving protocol ENG ENGLISH 59 3
LICENSES ENGLISH LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. ABOUT DIVX VIDEO: DivX is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified device that plays DivX video. Visit divx.
ASSEMBLING AND PREPARING 5 Accessories Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. POWER ENERGY MONITOR INPUT OFF ON .,! GHI PQRS 1/a/A SAVING TUV -*# CLEAR ABC JKL DEF MNO WXYZ MARK ARC PSM P BRIGHT A NESS G E MUTE MENU AUTO BACK TILE S.
ASSEMBLING AND PREPARING Optional Accessories ENGLISH ENG Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories. ST-200T Stand SP-2000 Speaker Cable holder/ Cable Tie Screws Screws Diameter 4.0 mm x Pitch 0.7 mm x Length 10 mm(Included Spring Washer) Diameter 4.0 mm x Pitch 0.
ASSEMBLING AND PREPARING 7 Parts and buttons ENG ENGLISH Screen Buttons/ Screen Marks Connection panel Screen Marks Description INPUT Changes the input source. MENU Accesses the main menus, or saves your input and exits the menus. Adjust the up and down. Adjusts the volume level. AUTO/SET /I Displays the current signal and mode. Press this button to adjust the screen automatically (available only in RGB mode) Turns the power on or off.
ASSEMBLING AND PREPARING ENGLISH ENG Using the Mounting Cable Tie Connecting the Speakers First, connect the input signal cable to be used. Insert the cable tie into the bottom hole on the back as shown in the figure to organize cables. 1 Connect an input signal cable to use before - Only on some models. installing the speakers. 2 Mount the speaker by using a screw as shown in the following. Then connect the speaker cable.
ASSEMBLING AND PREPARING Connecting the stand 9 Using the IR Receiver 1 Place a soft cloth on the table and put the product with the screen facing downward. Connect the stand as shown in the following picture. This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via an RS-232C cable. Install the IR receiver towards the front of the set. 2 Use the screws to secure the stand on the rear side of the product as shown in the diagram.
ASSEMBLING AND PREPARING ENGLISH ENG Using the Kensington security system The Kensington security system connector is located at the back of the Monitor. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com . Connect the Kensington security system cable between the Monitor and a table. NOTE The Kensington security system is optional. yy You can obtain additional accessories from most electronics stores.
ASSEMBLING AND PREPARING Mounting on a wall CAUTION 10 cm 10 cm 10 cm Disconnect the power before installing or yy moving the monitor. Otherwise electric shock may occur. If you install the Monitor on a ceiling or yy slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Do not over tighten the screws as this may yy cause damage to the Monitor and void your warranty.
ASSEMBLING AND PREPARING Securing the product to a wall (optional) ENGLISH ENG (Depending on model) 1 Insert and tighten the eye-bolts, or product brackets and bolts on the back of the product. - If there are bolts inserted at the eye-bolts position, remove the bolts first. 2 Mount the wall brackets with the bolts to the wall. Match the location of the wall bracket and the eye-bolts on the rear of the product. 3 Connect the eye-bolts and wall brackets tightly with a sturdy rope.
REMOTE CONTROL 13 The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the Monitor correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse. CAUTION Do not mix old and new batteries, as this yy may damage the remote control.
REMOTE CONTROL ENGLISH ENG POWER ENERGY MONITOR MENU (See p.41) Accesses the main menus or saves your input and exit menus. INPUT OFF ON .,! GHI PQRS 1/a/A SAVING TUV -*# CLEAR ABC JKL DEF MNO WXYZ MARK ARC Navigation buttons Scrolls through menus or options. PSM OK Selects menus or options and confirms your input. AUTO S.MENU S.MENU (SuperSign Menu Key) The current model does not support this function.
USING THE MONITOR 15 Connecting to a PC Your Monitor supports the Plug & Play* feature. * Plug & Play: This is the function that allows a PC to use the monitor without installing a driver. ENG ENGLISH USING THE MONITOR CAUTION Connect the yy signal input cable and tighten it by turning the screws clockwise. Do not press the screen with your finger for yy a long time as this may result in temporary distortion on the screen.
USING THE MONITOR ENGLISH ENG RGB connection DVI-D connection Transmits the analog video signal from your PC to the Monitor. Connect the PC and the Monitor set with the 15 pin signal cable as shown the following illustrations. Select RGB input source on the monitor. Transmits the digital video signal from your PC to the Monitor. Connect the PC and the Monitor set with the DVI cable as shown the following illustrations. Select DVI-D input source on the monitor.
USING THE MONITOR 17 Display Port connection Transmits the digital video and audio signals from your PC to the Monitor. Connect the PC and the Monitor with the HDMI cable as shown in the following illustrations. Select HDMI input source. Transmits the digital video and audio signals from your PC to the Monitor. Connect the PC and the Monitor with the Display Port cable as shown in the following illustrations. Select Display Port input source.
USING THE MONITOR IR Receiver connection ENGLISH ENG Allows the use of a wired remote or IR receiver extension. NOTE Make sure the power cable is disconnected.
USING THE MONITOR Customizing image options Selecting an image mode Customize basic and advanced options of each image mode for the best screen performance. Display images in its optimized settings by selecting one of the preset image modes. 1 Press MENU to access the main menus. 1 Press MENU to access the main menus. 2 Press the Navigation buttons to scroll to PICTURE and press OK. 3 Press the Navigation buttons to scroll to Picture Mode and press OK.
USING THE MONITOR ENGLISH ENG Customizing PC display options Adjusting the sound Customize options of each image mode for the best image quality. This function works in the following mode: yy RGB[PC] mode. Selecting an sound mode 1 Press MENU to access the main menus. 1 Press MENU to access the main menus.
USING THE MONITOR 21 Using additional options You may customize options of each sound mode for the best sound quality. Adjusting aspect ratio 1 Press MENU to access the main menus. Resize the image to view the image at its optimal size by pressing ARC while you are watching content. 2 Press the Navigation buttons to scroll to AUDIO and press OK. 3 Press the Navigation buttons to scroll to Sound Mode and press OK. 4 Press the Navigation buttons to scroll to a sound mode you want and press OK.
USING THE MONITOR ENGLISH ENG - 16:9 : This selection will allow you to adjust the picture horizontally, in linear proportion, to fill the entire screen(useful for viewing 4:3 formatted DVDs). - 4:3 : This selection will allow you to view a picture with an original 4:3 aspect ratio, black bars will appear on both the left and right of the screen. - Just Scan : This Selection will allow you view the picture of best quality without loss of original picture in high resolution image.
USING THE MONITOR 23 Using the input list 1 Press INPUT to access the input source list. - The connected device displays on each input source. 2 Press the Navigation buttons to scroll to one of the input sources and press OK. Input source Description AV(CVBS) Watch video from a VCR or other external devices. Component Watch content from a DVD or other external devices, or through a digital set-top box RGB Views the connected PC display on the screen.
ENTERTAINMENT ENGLISH ENG ENTERTAINMENT Connecting to a wired network (Depending on model) 1 Press MENU to access the main menus. Connect the display to a local area network (LAN) via the LAN port as shown on the following illustration and set up the network settings. This monitor only supports a wired network connection. After making a physical connection, a small number of home networks may require the display network settings to be adjusted.
ENTERTAINMENT NOTE Tips for Network setting yy Use a standard LAN cable with this display. Cat5 or better with a RJ45 connector. yy Many network connection problems during set up can often be fixed by re-setting the router or modem. After connecting the display to the home network, quickly power off and/or disconnect the power cable of the home network router or cable modem. Then power on and/or connect the power cable again.
ENTERTAINMENT Connecting USB storage devices ENGLISH ENG You can connect USB storage devices such as a USB flash memory, external hard drive to the display and use multimedia features . Connect a USB flash memory or USB memory card reader to the Display as shown on the following illustration. The My media screen appears.
ENTERTAINMENT yy It is recommended to use a certified USB storage device and cable. Otherwise, a USB storage device may not be detected or a playback error may occur. yy Only a USB memory stick can be used to play back the files distributed and stored by SuperSign Manager. A USB hard disk or multi-card reader will not work. yy Only an FAT 32 file formatted storage device can play back the files distributed and stored by SuperSign manager. yy A USB 3.0 storage device may not work.
ENTERTAINMENT Supported File Formats ENGLISH ENG File Extensions Photo JPEG Type Movie Supported file format DAT,MPG,MPEG,VOB,AVI,DIVX,MP4,MKV,TS,T RP,TP,ASF,WMV,FLV) JPG Video format : DivX3.11, DivX4, DivX5, DivX6, Xvid1.00, Xvid1.01, Xvid1.02, Xvid1.03, Xvid1.10 beta-1/beta-2, Mpeg-1, Mpeg-2, Mpeg-4, H.264/AVC, VC1, JPEG, Sorenson H.263 Audio format : Dolby Digital, AAC, Mpeg, MP3, LPCM, HE-AAC, ADPCM, WMA Bit rate : within 32 kbps to 320 kbps(MP3) External Subtitle format : *.smi/*.srt/*.
ENTERTAINMENT Viewing movies 29 5 Play a movie. 1 Press the Navigation buttons to scroll to My Media and press OK. NOTE yy Non-supported files are displayed the preview image by icon only . yy Abnormal files are displayed in the form of bitmap . 2 Press the Navigation buttons to scroll to Movie List and press OK. 3 Press the Navigation buttons to scroll to a folder you want and press OK. 6 Control playback by using the following buttons.
ENTERTAINMENT Tips for using playing video files ENGLISH ENG yy Some user-created subtitles may not work properly. yy Some special characters are not supported in subtitles. yy HTML tags are not supported in subtitles. yy Subtitles in languages other than the supported languages are not available. yy The screen may suffer temporary interruptions (image stoppage, faster playback, etc.) when the audio language is changed.
ENTERTAINMENT When you select the Set Video Play, the Picture Size, Audio Language, Subtitle Language or Repeat. 2 Press the Navigation buttons to scroll to make appropriate adjustments. Latin2 Latin4 Cyrillic Menu Picture Size Audio Language Subtitle Language Language Code Page Sync Position Size Repeat Description Selects your desired picture format during movie play. Changes the Language Group of the audio during movie play. Files with a single audio track cannot be selected.
ENTERTAINMENT When you select the Set Video, ENGLISH ENG 1 Press the Navigation buttons to scroll to make appropriate adjustments. Page 1/1 Photo List USB1 USB Drive 001 Drive1 002 010 011 Page 1/1 003 004 005 006 012 013 014 015 When you select the Set Audio, Move View Change Numbers To Music List 008 009 Page Change Mark Exit Mark Mode 1 Press the Navigation buttons to scroll to show the Sound Mode, Clear Voice II or Balance.
ENTERTAINMENT Using photo options ENERGY SAVING Press the ENERGY SAVING button repeatedly to change the brightness of your screen. yy Slide Speed: Selects a slideshow speed (Fast, Medium, Slow). yy TransitionEffect: Set the view mode of the slideshow. yy BGM: Selects a music folder for the background music. NOTE yyYou cannot change the music folder while the background music is playing. yyYou can only select the MP3 folder saved on the device that currently displays the photo.
ENTERTAINMENT When you select the Set Photo View, ENGLISH ENG 1 Press the Navigation buttons to scroll to select Slide Speed,Transition Effect or BGM. 2 Press the Navigation buttons to scroll to make appropriate adjustments. Transition Effect Option Option Description Sliding Pushes the current slide out of view as it plays to the next slide. Stairs Pushes the current slide in a staircase shape as it plays to the next slide.
ENTERTAINMENT When you select the Set Video, 35 Listening to music appropriate adjustments. 1 Press the Navigation buttons to scroll to My Media and press OK. 2 Press the Navigation buttons to scroll to Music When you select the Set Audio, 1 Press the Navigation buttons to scroll to show the Sound Mode, Clear Voice II or Balance. 2 Press the Navigation buttons to scroll to make appropriate adjustments. List and press OK. 3 Press the Navigation buttons to scroll to a folder you want and press OK.
ENTERTAINMENT 6 Control playback by using the following buttons. ENGLISH ENG This unit doesn't support the ID3 Tag yy embedded MP3 files. Page 1/1 Music List 3 file(s) Marked Tips for playing music files Drive1 Page 1/1 NOTE 004. - B04.mp3 00:00 005. - B05.mp3 00:00 006. - B06.mp3 00:00 007. - B07.mp3 00:00 005. - B05.mp3 02:30 / 03:25 Play with Photo Button 008. - B08.mp3 00:00 Option Hide Exit Description Stops playing back the file and moves back to the music list.
ENTERTAINMENT Music options 2 Press the Navigation buttons to scroll to Set Audio Play. or Set Audio. and press OK. NOTE yy Option values changed in Movie List does not affect Photo List and Music List. yy Option value changed in Photo List and Music List are changed likewise in Photo List and Music List excluding Movie List. When you select the Set Audio Play, Viewing the Contents List Plays back the stored files using the Export option in SuperSign Manager.
ENTERTAINMENT DivX® VOD Guide ENGLISH ENG DivX® VOD Registration In order to play purchased or rented DivX® VOD contents, you should register your device with 10 digit DivX registration code from your device at www.divx.com/vod. 1 Press MENU to access the main menus. 2 Press the Navigation buttons to scroll to MY MEDIA and press OK. 3 Press the Blue button. 4 Press the Navigation buttons to scroll to DivX Reg. Code and press OK. 5 View the registration code of your display.
ENTERTAINMENT DivX® VOD Deregistration 1 Press MENU to access the main menus. Using PIP/PBP Videos or pictures stored on the USB device can be displayed on a single monitor by dividing them into the main and subscreens. (See p.51) 2 Press the Navigation buttons to scroll to MY MEDIA and press OK. 1 Press the MENU button to move to OPTION 3 Press the Blue button. 4 Press the Navigation buttons to scroll to Deactivation and press OK. 5 Press the Navigation buttons to select Yes to and press OK.
ENTERTAINMENT 4 Select a file you want and then press OK. 6 For sound select either Main or Sub. You must ENGLISH ENG to select the output sound before running the PIP or PBP function. Page 1/1 Movie List Drive1 USB1 USB Drive 001 002 005 006 Page 1/1 003 004 051. Apple_ ... 02:30:25 Select the sound path. Main Move Change Numbers To Photo list Play Page Change Sub Mark Exit Mark Mode 7 The sub screen is displayed on the main screen.
CUSTOMIZING SETTINGS Accessing Main Menus MARK ARC PSM 1 Press MENU to access the main menus. 2 P BRIGHT A NESS G E MUTE MENU Press the Navigation buttons to scroll to one of the following menus and press OK. S.MENU OK BACK 3 Press the Navigation buttons to scroll to the setting or option you want AUTO TILE EXIT ID ON OFF and press OK. 4 When you are finished, press EXIT. When you return to the previous menu, press BACK. PICTURE (See p.42) Adjusts the image size, quality, or effect.
CUSTOMIZING SETTINGS PICTURE settings PICTURE Move ENGLISH ENG 1 Press MENU to access the main menus. Aspect Ratio 2 Smart Energy Saving : Off Energy Saving Press the Navigation buttons to scroll to PICTURE and press OK. Picture Mode : 16:9 : Off : Standard Backlight 3 Press the Navigation buttons to scroll to the setting or OK 70 Contrast 100 option you want and press OK. Brightness 50 Sharpness 50 - To return to the previous level, press BACK.
CUSTOMIZING SETTINGS Setting Description Customizes the PC display options in RGB mode. Option Resolution Selects a proper resolution. See “Customizing PC display options”. Auto Config. Adjusts the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress. Position/Size/ Phase Adjusts the options when the picture is not clear, especially when characters are shaky. Run Auto Config. before adjusting these.
CUSTOMIZING SETTINGS Advanced Control ENGLISH ENG Setting Description Dynamic Contrast (Off/High/Medium/Low) Adjusts the contrast to keep it at the best level according to the brightness of the screen. The picture is improved by making bright parts brighter and dark parts darker. (Function works in the following mode - AV(CVBS), Component, HDMI-DTV, Display Port-DTV ) Dynamic Color (Off/High/Low) Adjusts screen Colors so that they look livelier, richer and clearer.
CUSTOMIZING SETTINGS AUDIO settings AUDIO Clear Voice II 2 Press the Navigation buttons to scroll to AUDIO and press Sound Mode : Off Balance OK. OK 0 L R : Standard Infinite Sound : Off Treble 50 3 Press the Navigation buttons to scroll to the setting or Bass option you want and press OK. 50 Reset - To return to the previous level, press BACK. 4 When you are finished, press EXIT. Digital Audio Input : Audio In Speaker : On When you return to the previous menu, press BACK.
CUSTOMIZING SETTINGS TIME settings TIME Move ENGLISH ENG 1 Press MENU to access the main menus. Clock 2 Press the Navigation buttons to scroll to TIME and press Off Time : Off On Time : Off Sleep Timer : Off Power On Delay : Off Auto Off : 15 min. Automatic Standby : Off OK. 3 Press the Navigation buttons to scroll to the setting or option you want and press OK. OK - To return to the previous level, press BACK. 4 When you are finished, press EXIT.
CUSTOMIZING SETTINGS OPTION settings OPTION Move Language 2 Press the Navigation buttons to scroll to OPTION and press ISM Method : Normal DPM Select : On Fail Over : Off OK. Factory Reset 3 Press the Navigation buttons to scroll to the setting or option Set ID you want and press OK. Tile Mode - To return to the previous level, press BACK. PIP/PBP 4 When you are finished, press EXIT. When you return to the previous menu, press BACK.
CUSTOMIZING SETTINGS Setting ENGLISH ENG Tile Mode Description Tile Mode To use this function - Must be displayed with various other products. - Must be in a function that can be connected to RGB Cable by distributor and RS-232C. Tile mode and choose Tile alignment and set the ID of the current product to set location. * Only after pressing the SET button the adjustments made to the settings will be saved. - Tile mode : column x row ( c = 1 to 15 r = 1 to 15) - 15 x 15 available.
CUSTOMIZING SETTINGS Setting 49 Description Key input does not work. This prevents invalid key input. Interface Select RS232C Communicates with the connected PC in serial mode. PC Power Control The current model does not support this function. USB Content Recovery Replays the content in a USB when the power is back on if it is turned off during playing a content. (This function operates the same when a USB is disconnected and connected again.) Product/Service Info.
CUSTOMIZING SETTINGS Tile Mode Tile Mode - Natural mode ENGLISH ENG This monitor can be tiled with additional monitors to create a large tiled display. Off When the Tile Mode option is disabled When active, the part of the image that would normally be displayed in the gap between the monitors is omitted.
CUSTOMIZING SETTINGS PIP/PBP NOTE yyThe subscreen is only supported when using the USB device. Sub Mode USB *PIP(Picture In Picture): Displays the Sub screen in the main screen. *PBP(Picture By Picture): Displays the Sub screen next to the main screen. Sub screen Main screen PIP PBP Position Adjusts the position of the subscreen (top left, bottom left, top right, bottom right) top left top right bottom left bottom right Size Adjusts the size of the subscreen (Size 0-10).
CUSTOMIZING SETTINGS Picture ID ENGLISH ENG Picture ID is used to change the settings of a specific display using a single IR receiver for multivision. Communication is possible between a set with an IR receiver and other sets using audio cables. Each set is identified by a set ID. If you assign the Picture ID using the remote control, only displays with the same Picture ID and Set ID can be controlled remotely.
CUSTOMIZING SETTINGS NETWORK settings NETWORK Move Player Name Setting 2 Press the Navigation buttons to scroll to NETWORK and Network Setting : None Network Status : Not connected press OK. 3 Press the Navigation buttons to scroll to the setting or option Server IP Setting Server IP Status : Not connected you want and press OK. - To return to the previous level, press BACK. 4 When you are finished, press EXIT. When you return to the previous menu, press BACK.
MAKING CONNECTIONS MAKING CONNECTIONS ENGLISH ENG Connect various external devices to the ports on the Monitor’s back panel. 1 Find an external device you want to connect to your Monitor shown on the following illustration. 2 Check the connection type of the external device. 3 Go to the appropriate illustration and check the connection details. HD Receiver HDMI - See p.55 Component - See p.55 AV(CVBS) - See p.56 DVD HDMI - See p.55 Component - See p.55 AV(CVBS) - See p.
MAKING CONNECTIONS Connect a HD receiver, DVD, or VCR player to the Monitor and select an appropriate input mode. Component connection Transmits the analog video and audio signals from an external device to the Monitor. Connect the external device and the Monitor with the 15 pin signal to RCA cable as shown on the following illustration. To display images by using progressive scan, make sure to use the component cable.
MAKING CONNECTIONS Connecting to a USB Transmits the analog video and audio signals from an external device to the Monitor. Connect the external device and the Monitor with the 15 pin signal to RCA cable as shown on the following illustration. Connect a USB storage device such as s USB flash memory, external hard drive, MP3 player or a USB memory card reader to the Monitor and access the USB menu to use various multimedia files.
MAKING CONNECTIONS 57 Connecting to the LAN ENG ENGLISH A Connect PC to Monitor directly. LAN Monitor PC B Using a router(Switch) LAN Monitor Switch Network PC C Using the Internet.Network LAN Network Monitor PC NOTE Using LAN establishes communication yy between your PC and the monitor and enables to use the OSD menus on the PC as well as on the monitor.
MAKING CONNECTIONS Daisy Chain Monitors ENGLISH ENG Use this function to share the RGB video signal with other monitors without having to use a separate signal splitter box.
TROUBLESHOOTING 59 No image is displayed Problem Is the product power cord connected? Does the 'Out of range' message appear? oes the 'Check signal cable' D message appear? Resolution yy See if the power cord is properly connected to the outlet. yy The signal from the PC (video card) is out of the vertical or horizontal frequency range of the product. Adjust the frequency range by referring to the Specifications in this manual.
TROUBLESHOOTING 'Key Lock On' message appears. ENGLISH ENG Problem The 'Key Lock On' message appears when pressing the Menu button. Resolution The Lock function prevents the OSD settings from being changed inadvertently. To release the lock, go to Menu and Option and disable the Key Lock option. The screen image looks abnormal.
TROUBLESHOOTING 61 The audio function does not work. No sound? Resolution Sound is too dull. yy See if the audio cable is connected properly. yy Adjust the volume. yy See if the sound is set properly. yy Adjust the Clear Voice ll, Treble and Bass appropriately. Sound is too low. yy Adjust the volume. Screen color is abnormal. Problem Resolution Screen has poor color resolution yy Set the number of colors to more than 24 bits (true color) Select (16 colors).
SPECIFICATIONS ENGLISH ENG SPECIFICATIONS 42WS50MW LCD Panel Screen Type Video Signal Pixel Pitch Max. Resolution 1067.31 mm Wide (42 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1067.31 mm 0.4845 mm (H) x 0.4845 mm (V) RGB : 1920 X 1080 @60 Hz HDMI,DVI-D, Display Port : 1920 X 1080 @60 Hz - It may not be supported depending on the OS or video card type.
SPECIFICATIONS ENG ENGLISH Dimensions (Width x Height x Depth) / Weight 961.6 mm x 554.5 mm x 31.9 mm / 13.6 kg 961.6 mm x 628.9 mm x 298.3 mm / 15 kg 961.6 mm x 554.5 mm x 81.5 mm / 14.4 kg 961.6 mm x 628.9 mm x 298.3 mm / 15.8 kg * Applicable only for models that support the speakers Audio 63 RMS Audio Output Input Sensitivity Speaker Impedance 10 W + 10 W (R + L) 0.7 Vrms 8Ω Product specifications shown above may be changed without prior notice due to upgrade of product functions.
SPECIFICATIONS ENGLISH ENG 47WS50MW LCD Panel Screen Type Video Signal Pixel Pitch Max. Resolution 1192.87 mm Wide (47 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1192.87 mm 0.5415 mm (H) x 0.5415 mm (V) RGB : 1920 X 1080 @60 Hz HDMI,DVI-D, Display Port : 1920 X 1080 @60 Hz - It may not be supported depending on the OS or video card type.
SPECIFICATIONS ENG ENGLISH Dimensions (Width x Height x Depth) / Weight 1071.8 mm x 616 mm x 31 mm / 15.6 kg 1071.8 mm x 690.4 mm x 298.3 mm / 16.9 kg 1071.8 mm x 616 mm x 80.6 mm / 16.5 kg 1071.8 mm x 690.4 mm x 298.3 mm / 17.8 kg * Applicable only for models that support the speakers Audio 65 RMS Audio Output Input Sensitivity Speaker Impedance 10 W + 10 W (R + L) 0.7 Vrms 8Ω Product specifications shown above may be changed without prior notice due to upgrade of product functions.
SPECIFICATIONS Dimensions ENGLISH ENG The illustrations in this manual may differ from the actual product and accessories. Please see the "Mounting on a wall" section for sizes of screws. ( See p.11 ) (Unit : mm) 42WS50MW 47WS50MW A 961.6 1071.8 B 11.5 11.5 C 11.5 11.5 D 554.5 616 E 628.9 690.4 F 11.5 11.5 G 85.9 85.9 H 706 804 I 280.8 335.9 J 77.3 108 K 400 400 L 400 400 M 81.5 80.6 N 52.6 52.6 O 31.9 31.0 P 134.7 135.6 Q 298.3 298.
SPECIFICATIONS 67 DTV Mode RGB (PC) supported mode Horizontal Vertical Frequency(kHz) Frequency(Hz) Resolution Component HDMI,Display Port (DTV) 640 x 350 31.469 70.8 480i o x o x 720 x 400 31.468 70.8 576i 640 x 480 31.469 59.94 480p o o 640 x 480 37.5 75 576p o o 800 x 600 37.879 60.317 720p o o 800 x 600 46.875 75 1080i o o 832 x 624 49.725 74.55 1080p o o 1024 x 768 48.363 60 1024 x 768 60.123 75.029 1280 x 720 44.772 59.855 1366 x 768 47.
IR CODES IR CODES ENGLISH ENG All models do not support the HDMI/USB function. yy Some key codes are not supported depending on the model.
CONTROLLING THE MULTIPLE PRODUCT Use this method to connect several products to a single PC. You can control several products at a yy time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 255 without being duplicated. yy Connecting the cable Connect the RS-232C cable as shown in the picture. The RS-232C protocol is used for communication between the PC and product. You can turn the yy product on/off, select an input source or adjust the OSD menu from your PC.
CONTROLLING THE MULTIPLE PRODUCT Command reference list ENGLISH ENG COMMAND DATA (Hexadecimal) 1 2 01. Power k a 00 to 01 02. Input Select x b Refer to ‘Input Select.’ 03. Aspect Ratio k c Refer to ‘Aspect Ratio.’ 04. Energy Saving j q Refer to ‘Energy Saving.’ 05. Picture mode d x Refer to ‘Picture mode.’ 06. Contrast k g 00 to 64 07. Brightness k h 00 to 64 08. Sharpness k k 00 to 64 09.
CONTROLLING THE MULTIPLE PRODUCT COMMAND 2 m j Refer to ‘Fail Over Input Select.’ 38. Reset f K 00 to 03 39. Tile Mode d d 00 to FF 40. Tile Mode Check d z FF 41. Tile ID d i Refer to ‘Tile ID.’ 42. Tile H Position d e 00 to 32 43. Tile V Position d f 00 to 32 44. Tile H Size d g 00 to 32 45. Tile V Size d h 00 to 32 46. Natural Mode (In Tile mode) d j 00 to 01 47.
CONTROLLING THE MULTIPLE PRODUCT Transmission / Receiving protocol ENGLISH ENG Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command1]: First command to control the set. * [Command2]: Second command to control the set. * [Set ID]: Set ID with which you want to communicate. Enter [Set ID] = ‘00(0x00’ to communicate with all sets regardless of their Set ID numbers. * [Data]: Information passed to the set. * [Data1]: Information passed to the set. * [Data2]: Information passed to the set.
CONTROLLING THE MULTIPLE PRODUCT 01. Power (Command: k a) To control the Power On/Off the display. Data 00 : Off 01 : On Acknowledgement [a][ ][Set ID][ ][OK/NG][Data][x] * Only when the monitor set is fully powered on, the Acknowledgement signal is returned properly. * There may be a certain time of delay between the Transmission and Acknowledgement signals. 04. Energy Saving (Command: j q) To set the Energy Saving function.
CONTROLLING THE MULTIPLE PRODUCT 07. Brightness (Command: k h) To adjust the screen brightness. ENGLISH ENG Transmission [k][h][ ][Set ID][ ][Data][Cr] Data 00 to 64: Brightness 0 to 100 Acknowledgement [h][ ][Set ID][ ][OK/NG][Data][x] 08. Sharpness (Command: k k) To adjust the screen sharpness. * This function is available only in AV/Component input. Transmission [k][k][ ][Set ID][ ][Data][Cr] Data 00 to 64: Sharpness 0 to 100 Acknowledgement [k][ ][Set ID][ ][OK/NG][Data][x] 09.
CONTROLLING THE MULTIPLE PRODUCT Transmission [f][r][ ][Set ID][ ][Data][Cr] 16. Balance (Command: k t) To adjust the sound balance. Transmission [k][t][ ][Set ID][ ][Data][Cr] Data 00 to 64: Left 50 to Right 50 Acknowledgement [t][ ][Set ID][ ][OK/NG][Data][x] 00 to 64: min. -50 (Bottom) to max. 50 (Top) Acknowledgement [r][ ][Set ID][ ][OK/NG][Data][x] 14. H Size (Command: f s) To adjust the screen Horizontal Size. * This function is available only when the Tile Mode is set to Off.
CONTROLLING THE MULTIPLE PRODUCT 19. Bass (Command: k s) To adjust the Bass values. ENGLISH ENG Transmission [k][s][ ][Set ID][ ][Data][Cr] Data 00 to 64: Bass 0 to 100 Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x] 20. Speaker (Command: d v) To select the speaker on/off. Transmission [d][v][ ][Set ID][ ][Data][Cr] Data 00: Off 01: On Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x] 22. Volume Control (Command: k f) To set the playback volume.
CONTROLLING THE MULTIPLE PRODUCT 77 26. On Timer(Repeat Mode/ Time) (Command: f d) To set the On Timer(Repeat mode/ Time) function. Transmission [f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Transmission [f][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data1 1.
CONTROLLING THE MULTIPLE PRODUCT ENGLISH ENG 27. On Timer Input (Command: f u) To select an external input for the current On Time setting and add a new schedule or change the existing schedule. Transmission [f][u][ ][Set ID][ ][Data1][Cr] [f][u][ ][Set ID][ ][Data1][Data2][Cr] Data (Add schedule) 20: Input (AV) 40: Component 60. RGB 70: DVI-D 90: HDMI (HDMI1) C0: Display Port 91: HDMI2/SDI B0:SuperSign Data1 (Change schedule) 1.
CONTROLLING THE MULTIPLE PRODUCT 31. Auto Off (Command: f g) To set the Auto Off function. Data 00: Off (No off after 15 minutes) 01: 15 min.(Off after 15 minutes) Acknowledgement [g][ ][Set ID][ ][OK/NG][Data][x] 32. Language (Command: f i) To set the language for OSD.
CONTROLLING THE MULTIPLE PRODUCT ENGLISH ENG 37. Fail Over Input Select (Command: m j) To select the input source for auto switch. * This command is only available when the fail over (auto) mode is set to Custom. Transmission [m][j][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] [ ][Data4][ ][Data5][Cr] Data 1 to 5 (Priority 1 to 5) 60: RGB 70: DVI-D 90: HDMI(HDMI1) C0: Display Port 91: HDMI2/SDI * The number of data items differs depending on the model. 40.
CONTROLLING THE MULTIPLE PRODUCT Transmission [d][f][ ][Set ID][ ][Data][Cr] Data 0 to 32: 0 (Bottom) to 50 (Top) * Bottom/Top values depend on Tile Vertical size. ** It may not be supported depending on the model. Acknowledgement [f][ ][Set ID][ ][OK/NG][Data][x] 44. Tile H Size (Command: d g) To adjust the Tile Horizontal Size. *Set Tile H Position to 0x32 before setting Tile H Size. * This function is available only when the Natural option of the Tile Mode is set to Off while the Tile Mode set to On.
CONTROLLING THE MULTIPLE PRODUCT 49. FAN Fault Check (Command: d w) To check the fan errors. ENGLISH ENG Transmission [d][w][ ][Set ID][ ][Data][Cr] Data FF: Read the status Acknowledgement [w][ ][Set ID][ ][OK/NG][Data][x] Data 00: Fan fault 01: Fan OK 02: Model without a Fan 50. Temperature Value (Command: d n) To check the inside temperature value.
CONTROLLING THE MULTIPLE PRODUCT 55. Serial No.Check (Command: f y) To check the Serial Numbers. Data FF: Check the product Serial Number Acknowledgement [y][ ][Set ID][ ][OK/NG][Data][x] 58. White Balance Green Gain (Command: j n) To set the White Balance Green Gain. Transmission [j][n][ ][Set ID][ ][Data][Cr] Data 00 to FE: Green Gain 0 to 254 Acknowledgement [n][ ][Set ID][ ][OK/NG][Data][x] * Data is ASCII code. 56. S/W Version (Command: f z) To check the Software Version.
CONTROLLING THE MULTIPLE PRODUCT ENGLISH ENG 61. PC Power Control (Command: d t) To control the PC power if the PC and the monitor are synchronized. Transmission [d][t][ ][Set ID][ ][Data][Cr] Data 00: Synchronized (When the monitor is off, the PC is also turned off.) 01: Not synchronized (The monitor is off but the PC is on.) ** It may not be supported depending on the model. Acknowledgement [t][ ][Set ID][ ][OK][Data][x] Data 00: Synchronized (When the monitor is off, the PC is also turned off.
Make sure to read the Safety Precautions before using the product. Keep the Owner's Manual(CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service. MODEL SERIAL To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http:// opensource.lge.com.
