ENG ENGLISH OWNER’S MANUAL MONITOR SIGNAGE Please read this manual carefully before operating the your set and retain it for future reference. MONITOR SIGNAGE MODELS 55WV70MS www.lg.
TABLE OF CONTENTS ENGLISH ENG CONTENTS 4 LICENSES 21 - Customizing sound options 21 Using additional options 21 - Adjusting aspect ratio 23 - Using the input list 5 ASSEMBLING AND PREPARING 5 Accessories 24 ENTERTAINMENT 6 Parts 7 To install in a Portrait Layout 24 - Connecting to a wired network 7 Remove L-brackets before Installation 25 - Network Status 8 STORAGE METHOD FOR PANEL 26 - Connecting USB storage devices 27 - Browsing files 29 - Viewing movies 32 - Viewin
LICENSES - RGB Cable 57 - DVI Cable 58 TROUBLESHOOTING 61 SPECIFICATIONS 63 IR CODES 64 CONTROLLING THE MULTIPLE PRODUCT 64 Connecting the cable 64 RS-232C Configurations 64 Communication Parameter 65 Command reference list 67 Transmission / Receiving protocol ENGLISH 57 3
LICENSES ENGLISH LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. ABOUT DIVX VIDEO: DivX is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified device that plays DivX video. Visit divx.
ASSEMBLING AND PREPARING 5 Accessories Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. CD (Owner's Manual, SuperSign Elite-w Program/SuperSign Manual) / Card Power Cord RGB Cable IR Receiver RS-232C Cable DVI Cable POWER ENERGY MONITOR INPUT OFF ON .
ASSEMBLING AND PREPARING Parts ENGLISH ENG USB DP /DVI DVI IN DVI OUT RGB /COMPONENT OUT AUDIO IN LAN COMPOSITE RGB /COMPONENT IN REMOTE CONTROL IN Connection panel (See p.54 to p.
ASSEMBLING AND PREPARING 7 To install in a Portrait Layout Remove L-brackets before Installation Remove the L-brackets from each corner of the monitor before installing it. NOTE Keep the removed L-brackets and use them when moving the monitor later. ENG ENGLISH When installing in a Portrait Layout, rotate the monitor clockwise 90 degrees (when facing the screen).
ASSEMBLING AND PREPARING STORAGE METHOD FOR PANEL PROTECTION ENGLISH ENG Correct Method Incorrect Method Panel Panel If the product needs to be set upright, hold both sides of the product, and tilt backward carefully for. Do not let the panel not to touch the floor. Panel If the product is tilted onto the bezel, the bottom of the panel may be damaged. Cushion Panel When laying down the product, lay a cushion on a flat floor. Put the product on it with the panel of the product facing down.
ASSEMBLING AND PREPARING Installing on a wall CAUTION 10 cm 20 cm 10 cm 10 cm Install the monitor at least 10 cm away from the wall and leave about 10 cm of space at each side of the monitor to ensure sufficient ventilation. Use the wall mount plate and screws that comply with the VESA standard. NOTE Do not install the product in a place with no ventilation (e.g., on a bookshelf or in a closet) or on a carpet or cushion.
ASSEMBLING AND PREPARING EXTERNAL EQUIPMENT SETUP ENGLISH ENG IR RECEIVER This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via an RS-232 cable.
ASSEMBLING AND PREPARING 11 Tiling Displays ENG ENGLISH How to Mount the Set *Example of 2 x 2 tiling * Using the screws for fixing the VESA wall mount, mount the set to the wall mount plate or the wall. Screws for fixing the VESA wall mount * The wall mount plate is shaded in gray in the illustration to help you see it.
ASSEMBLING AND PREPARING How to Join Sets ENGLISH ENG 1 Join other sets using screws for fixing the VESA wall mount in the same way as above. Set 4 joined to the rest of the sets (2 x 2 tiling) 2 After joining the sets, use the tiling guide to adjust the gap between the sets. 3 Now the 2 x 2 tiling is complete. You can tile in various combinations, such as 3 x 3. NOTE The load applied to each set should be supported by the wall mount plate or the wall using a VESA yy wall mount (600 x 400).
REMOTE CONTROL The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the Monitor set correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse. CAUTION Do not mix old and new batteries, as this yy may damage the remote control.
REMOTE CONTROL ENGLISH ENG POWER ENERGY MONITOR INPUT OFF ON 1 4 7 .,! GHI PQRS 1/a/A 2 5 8 0 SAVING TUV 3 6 9 -*# CLEAR ABC JKL DEF MNO WXYZ MARK ARC PSM POWER P BRIGHT A NESS G E MUTE MENU AUTO BACK TILE S.MENU OK ENERGY MONITOR MENU (See p.40) Accesses the main menus or saves your input and exit menus. .,! GHI PQRS 1/a/A TUV -*# CLEAR ABC JKL DEF MNO WXYZ ARC Navigation buttons Scrolls through menus or options.
.,! ABC DEF .,! ABC DEF REMOTE CONTROL 1/a/A 1/a/A CLEAR CLEAR Displaying the device name connected to an input port GHI JKL MNO GHI JKL MNO PQRS TUV WXYZ PQRS TUV WXYZ -*# -*# MARK MARK ARC ARC BRIGHT NESS P A G E MUTE Display which devices are connected to which external input ports. AUTO MENU S.MENU 1 Access the Input list screen and press the blue (input label) button onOKthe remote control.
USING THE MONITOR SET ENGLISH ENG USING THE MONITOR SET Connecting to a PC RGB connection Your Monitor set supports the Plug & Play* feature. Transmits the analog video signal from your PC to the Monitor set. Connect the PC and the Monitor set with the 15 pin signal cable as shown the following illustrations. Select RGB input. * Plug & Play: A PC will have a built-in driver for the monitor, no extra software is needed. Back of the product.
USING THE MONITOR SET HDMI connection Transmits the digital video signal from your PC to the Monitor set. Connect the PC and the Monitor set with the DVI cable as shown the following illustrations. Select DVI input. Transmits the digital video and audio signals from your PC to the Monitor set. Connect the PC and the Monitor set with the HDMI cable as shown in the following illustrations. Select HDMI input. IN DVI IN DVI IN AUDIO IN Back of the product.
USING THE MONITOR SET ENGLISH ENG DP connection IR Receiver connection Transmits the digital video and audio signals from your PC to the Monitor set. Connect the PC and the Monitor set with the DP cable as shown in the following illustrations. Select DP input. /DVI DP IN Allows the use of a wired remote or IR receiver extension. Back of the product. AUDIO IN Back of the product.
USING THE MONITOR SET Customizing image options Selecting an image mode Customize basic and advanced options of each image mode for the best screen performance. Display images in its optimized settings by selecting one of the preset image modes. 1 Press MENU to access the main menus. 1 Press MENU to access the main menus. 2 Press the Navigation buttons to scroll to PICTURE and press OK. 3 Press the Navigation buttons to scroll to Picture Mode and press OK.
USING THE MONITOR SET ENGLISH ENG Customizing PC display options Adjusting the sound Customize options of each image mode for the best image quality. This function works in the following mode: yy RGB[PC] mode. Selecting an sound mode 1 Press MENU to access the main menus. 1 Press MENU to access the main menus.
USING THE MONITOR SET Using additional options Customize options of each sound mode for the best sound quality. Adjusting aspect ratio 1 Press MENU to access the main menus. Resize the image to view the image at its optimal size by pressing ARC while you are watching Monitor set. 2 Press the Navigation buttons to scroll to AUDIO and press OK. 3 Press the Navigation buttons to scroll to Sound Mode and press OK. 4 Press the Navigation buttons to scroll to a sound mode you want and press OK.
USING THE MONITOR SET ENGLISH ENG - 16:9 : This selection will allow you to adjust the picture horizontally, in linear proportion, to fill the entire screen(useful for viewing 4:3 formatted DVDs). - 4:3 : This selection will allow you to view a picture with an original 4:3 aspect ratio, black bars will appear on both the left and right of the screen. - Just Scan : This Selection will allow you view the picture of best quality without loss of original picture in high resolution image.
USING THE MONITOR SET 23 Using the input list 1 Press INPUT to access the input source list. 2 Press the Navigation buttons to scroll to one of the input sources and press OK. Input source Description AV(CVBS) Watch video from a VCR or other external devices.
ENTERTAINMENT ENGLISH ENG ENTERTAINMENT Connecting to a wired network Connect the display to a local area network (LAN) via the LAN port as shown on the following illustration and set up the network settings. Only supports wired network connection. After making a physical connection, a small number of networks may require the display network settings to be adjusted. For most networks, the display will connect to automatically without any adjustments.
ENTERTAINMENT NOTE yy A DSL modem is required to use DSL service and a cable modem is required to use cable modem service. Depending on the access method of and subscriber agreement with your ISP, you may not be able to use the internet connection feature contained in this display or you may be limited to the number of devices you can connect at the same time. (If your ISP limits sub-scription to one device, this display may not be allowed to connect when a PC is already connected.
ENTERTAINMENT Connecting USB storage devices ENGLISH ENG Connect USB storage devices such as a USB flash memory, external hard drive to the display and use multimedia features (See "Browsing files" on page 27). Connect a USB flash memory or USB memory card reader to the Display as shown on the following illustration. The My media screen appears. Tips for using USB storage devices yy Only a USB storage device is recognizable.
ENTERTAINMENT yy Be sure to back up important files since data damaged. We will not be responsible for any data loss. yy If the USB HDD does not have an external power source, the USB device may not be detected. So be sure to connect the external power source. - Please use a power adaptor for an external power source. We do not guarantee an USB cable for an external power source. yy If your USB memory device has multiple Browsing files Access the photo, music, or movie lists and browse files.
ENTERTAINMENT Supported file format ENGLISH ENG Type Movie Supported file format DAT,MPG,MPEG,VOB,AVI,DIVX,MP4,MKV,TS,T RP,TP,ASF,WMV,FLV) Movie(*.mpg/*.mpeg/*dat/*.ts/*.trp/*.tp/*.vob/*. mp4/*.mov/*.mkv/*.divx/*.avi/*.asf/*.wmv/*.flv/*. avi(motion-jpeg)/*. mp4(motion-jpeg)/*.mkv(motion-jpeg))supporting file Video format : DivX3.11, DivX4.12, DivX5.x, DivX6, Xvid1.00, Xvid1.01, Xvid1.02, Xvid1.03, Xvid1.10 beta-1/beta-2, Mpeg-1, Mpeg-2, Mpeg-4, H.264/AVC, VC1, JPEG, Sorenson H.
ENTERTAINMENT Viewing movies 29 5 Play a movie. 1 Press the Navigation buttons to scroll to My Media and press OK. NOTE yy Non-supported files are displayed the preview image by icon only . yy Abnormal files are displayed in the form of bitmap . 2 Press the Navigation buttons to scroll to Movie List and press OK. 3 Press the Navigation buttons to scroll to a 6 Control playback by using the following buttons. folder you want and press OK.
ENTERTAINMENT Tips for using playing video files ENGLISH ENG yy Some user-created subtitles may not work properly. yy Some special characters are not supported in subtitles. yy HTML tags are not supported in subtitles. yy Subtitles in languages other than the supported languages are not available. yy The screen may suffer temporary interruptions (image stoppage, faster playback, etc.) when the audio language is changed.
ENTERTAINMENT When you select the Set Video Play, German, Italian, Portuguese, the Picture Size, Audio Language, Subtitle Language or Repeat. 2 Press the Navigation buttons to scroll to make appropriate adjustments.
ENTERTAINMENT When you select the Set Video, ENGLISH ENG 1 Press the Navigation buttons to scroll to make appropriate adjustments. Page 1/1 Photo List USB1 USB Drive 001 Drive1 002 010 011 Page 1/1 003 004 005 006 012 013 014 015 When you select the Set Audio, View Move Change Numbers To Music List 009 P Page Change Exit Mark Mode 1 Press the Navigation buttons to scroll to show the Sound Mode, Clear Voice II or Balance.
ENTERTAINMENT Using photo options Use the following options while viewing photos. Option Press the ENERGY SAVING button ) repeatedly to change the brightness of your screen. yy Slide Speed: Selects a slideshow speed (Fast, Medium, Slow). yy TransitionEffect: Set the view mode of the slideshow. yy BGM: Selects a music folder for the background music. NOTE yyYou cannot change the music folder while the background music is playing.
ENTERTAINMENT When you select the Set Photo View, ENGLISH ENG 1 Press the Navigation buttons to scroll to select Slide Speed,Transition Effect or BGM. 2 Press the Navigation buttons to scroll to make appropriate adjustments. Transition Effect Option Option Description Sliding Pushes the current slide out of view as it plays to the next slide. Stairs Pushes the current slide in a staircase shape as it plays to the next slide.
ENTERTAINMENT When you select the Set Video, 35 Listening to music appropriate adjustments. 1 Press the Navigation buttons to scroll to My Media and press OK. 2 Press the Navigation buttons to scroll to Music When you select the Set Audio, 1 Press the Navigation buttons to scroll to show the Sound Mode, Clear Voice II or Balance. 2 Press the Navigation buttons to scroll to make appropriate adjustments. List and press OK. 3 Press the Navigation buttons to scroll to a folder you want and press OK.
ENTERTAINMENT 6 Control playback by using the following buttons. ENGLISH ENG 3 file(s) Marked 004. - B04.mp3 00:00 Drive1 005. - B05.mp3 00:00 006. - B06.mp3 00:00 Page 1/1 007. - B07.mp3 00:00 005. - B05.mp3 NOTE 008. - B08.mp3 00:00 02:30 / 03:25 Play with Photo Button This unit cannot support the ID3 Tag yy embedded MP3 files. Page 1/1 Music List MENU Option Hide Exit Description Stops playing back the file and moves back to the music list.
ENTERTAINMENT Music options 2 Press the Navigation buttons to scroll to Set Audio Play or Set Audio and press OK. Viewing the Contents List Plays back the stored files using the Export option in SuperSign Manager. 1 Press the Navigation buttons to scroll to My Media and press OK. NOTE yy Option values changed in Movie List does not affect Photo List and Music List. yy Option value changed in Photo List and Music List are changed likewise in Photo List and Music List excluding Movie List.
ENTERTAINMENT DivX® VOD Guide ENGLISH ENG DivX® VOD Registration In order to play purchased or rented DivX® VOD contents, you should register your device with 10 digit DivX registration code from your device at www.divx.com/vod. DivX® VOD Deregistration You should deregister your device with 8 digit DivX deregistration code from your device at www.divx. com/vod. 1 Press MENU to access the main menus. 2 Press the Navigation buttons to scroll to MY MEDIA and press OK.
ENTERTAINMENT Using PIP/PBP 5 Select the PIP or PBP icon from the play list. ENG ENGLISH Displays videos or photos stored in the USB device on a single monitor by dividing it into the main and sub screens. (See p.50) 1 Press the MENU button to move to OPTION and press OK. 2 Press PIP/PBP to select PIP or PBP and then 01:02:30 / 02:30:25 press OK. MENU Exit Hide Option < Movie List > PIP/PBP Mode Move Pre. Off Position PIP Size PBP 3 Select Movie List or Photo List from My Media.
CUSTOMIZING SETTINGS ENGLISH ENG CUSTOMIZING SETTINGS Accessing main menus MARK ARC PSM 1 Press MENU to access the main menus. 2 P BRIGHT A NESS G E MUTE MENU Press the Navigation buttons to scroll to one of the following menus and press OK. S.MENU OK BACK 3 Press the Navigation buttons to scroll to the setting or option you want AUTO TILE EXIT ID ON OFF and press OK. 4 When you are finished, press EXIT. When you return to the previous menu, press BACK. PICTURE (See p.
CUSTOMIZING SETTINGS PICTURE settings PICTURE 2 Press the Navigation buttons to scroll to PICTURE and press OK. : 16:9 • : Off Energy Saving OK ENG ENGLISH 1 Press MENU to access the main menus. Move • Aspect Ratio 41 ꔋ • Smart Energy Saving : Off • Picture Mode : Standard • Backlight • Contrast 3 Press the Navigation buttons to scroll to the setting or 70 100 • Brightness 50 option you want and press OK. • Sharpness 50 - To return to the previous level, press BACK.
CUSTOMIZING SETTINGS Setting ENGLISH ENG SCREEN (In RGB Mode Only) Description Customizes the PC display options in RGB mode. Option Resolution Selects a proper resolution. See “Customizing PC display options”. Auto Configure Sets to adjust the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress.
CUSTOMIZING SETTINGS 43 Advanced Control Description Adjusts the contrast to keep it at the best level according to the brightness of the screen. The picture is improved by making bright parts brighter and dark parts darker. (This function can be used only under Component.) Dynamic Color Adjusts screen Colors so that they look livelier, richer and clearer. This feature enhances (Off/High/Low) hue, saturation and luminance so that red, blue, green and white look more vivid.
CUSTOMIZING SETTINGS AUDIO settings AUDIO ENGLISH ENG • Clear Voice II 1 Press MENU to access the main menus. Move • Balance 2 Press the Navigation buttons to scroll to AUDIO and press • Sound Mode OK : Off ꔋ 0 L R : Standard • Infinite Sound: Off OK. 3 Press the Navigation buttons to scroll to the setting or • Treble 50 • Bass 50 • Reset option you want and press OK. • Digital Audio Input • Speaker - To return to the previous level, press BACK.
CUSTOMIZING SETTINGS TIME settings TIME Move • Clock • Off Time : Off 2 Press the Navigation buttons to scroll to TIME and press • On Time : Off • Sleep Timer : Off • Power On Delay : Off • Auto Off : 15 min. OK. 3 Press the Navigation buttons to scroll to the setting or option you want and press OK. OK ꔋ • Automatic Standby : 4hours - To return to the previous level, press BACK. 4 When you are finished, press EXIT. When you return to the previous menu, press BACK.
CUSTOMIZING SETTINGS OPTION settings OPTION Move ENGLISH ENG 1 Press MENU to access the main menus. • Language • ISM Method : Normal 2 Press the Navigation buttons to scroll to OPTION and press • DPM Select : On • Fail Over : Off OK. OK ꔋ • Factory Reset 3 Press the Navigation buttons to scroll to the setting or option you want and press OK. • Set ID :1 • Tile Mode • PIP/PBP • Fan - To return to the previous level, press BACK. • Product/Service Info.
CUSTOMIZING SETTINGS Setting PIP/PBP Description Tile Mode To use this function - Must be displayed with various other products. - Must be in a function that can be connected to RGB Cable by distributor and RS-232C. Tile mode and choose Tile alignment and set the ID of the current product to set location. * Only after pressing the SET button the adjustments made to the settings will be saved. - Tile mode : column x row ( c = 1 to 15 r = 1 to 15) - 15 x 15 available.
CUSTOMIZING SETTINGS Setting Description Setting Mode This option indicates the monitor's internal temperature and controls the fan. • Auto: Switches the fan on and off according to the set temperature. • On: The fan is always switched on. • Manual: Switches the fan on and off according to user settings. Hysteresis The difference in temperature between when the fan is switched on and when it is off. Set Temperature Set the temperature at which the fan is switched on.
CUSTOMIZING SETTINGS 49 Tile Mode Off When the Tile Mode option is disabled 2X1 When using 2 monitors ID 1 3X3 When using 9 monitors 2X2 When using 4 monitors ID 2 ID 1 ID 2 ID 1 ID 2 ID 3 ID 3 ID 4 ID 4 ID 5 ID 6 ID 7 ID 8 ID 9 Tile ID 4X4 When using 16 monitors 5X5 When using 25 monitors ID 1 ID 2 ID 3 ID 4 ID 1 ID 2 ID 3 ID 4 ID 5 ID 5 ID 6 ID 7 ID 8 ID 6 ID 7 ID 8 ID 9 ID 10 ID 9 ID 10 ID 11 ID 12 ID 11 ID 12 ID 13 ID 14 ID 15 ID 13 ID 14 ID 15 ID 16
CUSTOMIZING SETTINGS PIP/PBP ENGLISH ENG Displays videos or photos stored in the USB device on a single monitor by dividing it into the main and sub screens. (See p.39) Mode *PIP(Picture In Picture): Displays the Sub screen in the main screen. *PBP(Picture By Picture): Displays the Sub screen next to the main screen. NOTE yyThe subscreen is only supported when using the USB device.
CUSTOMIZING SETTINGS 51 Picture ID 2 If you press the left/right buttons or press the ON button repeatedly, the Picture ID cycles through OFF and 1 to 4. Assign the ID you want.
CUSTOMIZING SETTINGS NETWORK settings NETWORK Move ENGLISH ENG • Player Name Setting 1 Press MENU to access the main menus. 2 Press the Navigation buttons to scroll to NETWORK and press OK. • Network Setting : None • Network Status : Not connected • Server IP Setting • Server IP Status : Not connected 3 Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. 4 When you are finished, press EXIT.
MAKING CONNECTIONS 53 MAKING CONNECTIONS 1 Find an external device you want to connect to your Monitor set shown on the following illustration. 2 Check the connection type of the external device. 3 Go to the appropriate illustration and check the connection details. HD Receiver HDMI - See p.54 DVI - See p.54 AV - See p.55 Component - See p.55 DVD HDMI - See p.54 DVI - See p.54 AV - See p.55 Component - See p.55 VCR AV - See p.55 Component - See p.55 Speaker USB Memory storage – See p.
MAKING CONNECTIONS ENGLISH ENG Connecting to a HD receiver, DVD, Camcorder, Camera, Gaming Device or VCR player HDMI connection Transmits the digital video and audio signals from an external device to the Monitor set. Connect the external device and the Monitor set with the HDMI cable as shown on the following illustration. Connect a HD receiver, DVD, or VCR player to the Monitor set and select an appropriate input mode. Back of the product.
MAKING CONNECTIONS Component connection RGB /COMPONENT OUT Transmits the analog video and audio signals from an external device to the Monitor set. Connect the external device and the Monitor set with the Composite cable as shown in the following illustration. Back of the product.
MAKING CONNECTIONS Connecting to the LAN Connecting to a USB ENGLISH ENG Connect a USB storage device such as s USB flash memory, external hard drive, MP3 player or a USB memory card reader to the Monitor set and access the USB menu to use various multimedia files. LAN connection A Using a router(Switch) LAN Switch Monitor Set PC Network B Using the Internet.
MAKING CONNECTIONS 57 Daisy Chain Monitors RGB Cable 15-pin D-Sub Signal Cable (Max 3m) RGB /COMPONENT OUT RGB /COMPONENT OUT RGB /COMPONENT OUT RGB /COMPONENT OUT RGB /COMPONENT OUT RGB /COMPONENT OUT RGB /COMPONENT OUT RGB /COMPONENT OUT RGB /COMPONENT IN RGB /COMPONENT IN RGB /COMPONENT IN RGB /COMPONENT IN RGB /COMPONENT IN RGB /COMPONENT IN RGB /COMPONENT IN RGB /COMPONENT IN Monitor SET 1 Monitor SET 2 Monitor SET 3 Monitor SET 4 DVI Cable DVI IN DVI IN DVI OUT DVI OUT DVI IN DVI IN
TROUBLESHOOTING ENGLISH ENG TROUBLESHOOTING No image is displayed Problem Resolution Is the product power cord connected? yy See if the power cord is properly connected to the outlet. ower is on, but the screen P appears extremely dark. Does the 'Invalid Format' message appear? yy Adjust brightness and contrast again. yy Backlight may need repair. yy The signal from the PC (video card) is out of the vertical or horizontal frequency range of the product.
TROUBLESHOOTING 59 The screen image looks abnormal. Resolution Is the screen position wrong? yy D-Sub analog signal - Press the "AUTO" button in the remote control to automatically select the optimal screen status that fits into the current mode. If adjustment is not satisfactory, use the Position OSD menu. yy See if the video card resolution and frequency are supported by the product. If the frequency is out of range, set to the recommended resolution in the Control Panel "Display" Setting menu.
TROUBLESHOOTING Screen color is abnormal. ENGLISH ENG Problem Resolution Screen has poor color resolution yy Set the number of colors to more than 24 bits (true color) Select (16 colors). Control Panel - Display - Settings - Color Table menu in Windows. Screen color is unstable or yy Check the connection status of the signal cable. Or, re-insert the PC mono-colored. video card.
SPECIFICATIONS LCD Panel Video Signal Screen Type 1387.80 mm Wide (54.6 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 1387.80 mm Pixel Pitch 0.630 mm (H) x 0.630 mm (V) Max. Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI/DP : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type.
SPECIFICATIONS DTV Mode RGB (PC) supported mode ENGLISH ENG Resolution Horizontal Vertical Frequency(kHz) Frequency(Hz) Resolution Component HDMI/DVI (DTV) 640 x 480 31.469 59.94 480i o x o x 1024 x 768 48.363 60 576i 1280 x 720 44.772 59.855 480p o o 1366 x 768 47.7 60 576p o o 1680 x 1050 65.290 59.954 720p o o 1920 x 1080 67.
IR CODES 63 IR CODES Code (Hexa) 95 08 Function Energy Saving ( ) POWER Note R/C BUTTON R/C BUTTON (ON/OFF) 0B INPUT R/C BUTTON C4 Monitor On R/C BUTTON C5 Monitor Off R/C BUTTON 43 MENU R/C BUTTON 40 Up ( ) R/C BUTTON 41 Down ( ) R/C BUTTON 07 Left ( ) R/C BUTTON 06 Right ( ) R/C BUTTON 44 OK( ) R/C BUTTON 28 BACK( 5B EXIT R/C BUTTON 4D PSM R/C BUTTON 02 Volume R/C BUTTON 03 Volume R/C BUTTON 09 MUTE E0 Bright (Page UP) R/C BUTTON E1 Bright (Page Down
CONTROLLING THE MULTIPLE PRODUCT ENGLISH ENG CONTROLLING THE MULTIPLE PRODUCT Use this method to connect several products to a single PC. You can control several products at a yy time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 255 without being duplicated. yy Connecting the cable Connect the RS-232C cable as shown in the picture. The RS-232C protocol is used for communication between the PC and product.
CONTROLLING THE MULTIPLE PRODUCT 65 Command reference list DATA (Hexadecimal) 2 01. Power k a 00H to 01H 02. Input Select x b Refer to ‘02. Input Select’ 03. Aspect Ratio k c Refer to ‘03. Aspect Ratio’ 04. Energy Saving j q Refer to ‘04. Energy Saving’ 05. Picture mode d x 00H to 04H 06. Contrast k g 00H to 64H 07. Brightness k h 00H to 64H 08. Sharpness k k 00H to 64H 09. Color k i 00H to 64H 10.
CONTROLLING THE MULTIPLE PRODUCT COMMAND ENGLISH ENG DATA (Hexadecimal) 1 2 41. Tile H Position d e 00H to 32H 42. Tile V Position d f 00H to 32H 43. Tile H Size d g 00H to 32H 44. Tile V Size d h 00H to 32H 45. Natural Mode (In Tile mode) d j 00H to 01H 46. Auto Switch Input Select d o 00H to 01H 47. FAN Fault check d w FFH 48. Temperature Value d n FFH 49. Key m c Refer to ‘49. Key’ 50.
CONTROLLING THE MULTIPLE PRODUCT 67 Transmission / Receiving protocol [Command1][Command2][ ][Set ID][ ][Data][Cr] or [Command1][Command2][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] or [Command1][Command2][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][ ][Data4][Cr] * [Command1]: First command to control the set. * [Command2]: Second command to control the set. * [Set ID]: Set ID with which you want to communicate. Etner [Set ID] = ‘00(0x00’ to communicate with all sets regardless of their Set ID numbers.
CONTROLLING THE MULTIPLE PRODUCT 01. Power (Command: k a) To control power On/Off the display. ENGLISH ENG Transmission [k][a][ ][Set ID][ ][Data][Cr] Data 00 : Power Off 01 : Power On FF : Check status Acknowledgement [a][ ][Set ID][ ][OK/NG][Data][x] * In a like manner, if other functions transmit ‘FF’ data based on this format, Acknowledgement data feedback presents status about each function. * Note: In this modes, display will send the acknowledgement after power on processing completion.
CONTROLLING THE MULTIPLE PRODUCT 07. Brightness (Command: k h) To adjust screen brightness. Data 00 to 64: Brightness 0 to 100 Acknowledgement [h][ ][Set ID][ ][OK/NG][Data][x] 08. Sharpness (Command: k k) To adjust screen sharpness. * Only available for AV/Component input. Transmission [k][k][ ][Set ID][ ][Data][Cr] Data 00 to 64: Sharpness 0 to 100 Acknowledgement [k][ ][Set ID][ ][OK/NG][Data][x] 09. Color (Command: k i) To adjust screen color. * Only available for AV/Component input.
CONTROLLING THE MULTIPLE PRODUCT ENGLISH ENG 13. V Position (Command: f r) To set the Vertical position. * Only available for Tile Off mode. Transmission [f][r][ ][Set ID][ ][Data][Cr] Data 23 to 41: Bottom Max(-15) to Top Max(15) Acknowledgement [r][ ][Set ID][ ][OK/NG][Data][x] 14. H Size (Command: f s) To set the Horizontal size. * Only available for Tile Off mode. Transmission [f][s][ ][Set ID][ ][Data][Cr] Data 00 to 64: Size -50 to 50 Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x] 15.
CONTROLLING THE MULTIPLE PRODUCT 19. Bass (Command: k s) To adjust bass. Data 00 to 64: Bass 0 to 100 Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x] 20. Speaker (Command: d v) To select speaker on/off. Transmission [d][v][ ][Set ID][ ][Data][Cr] Data 00: Speaker Off 01: Speaker On Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x 21. Volume Mute (Command: k e) To select screen mute on/off.
CONTROLLING THE MULTIPLE PRODUCT 25. Off Timer(Repeat Mode/ Time) (Command: f e) To set the Off Timer(Repeat mode/ Time) function. ENGLISH ENG Transmission [f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data1 00: Repeat Off 01: Repeat Once 02. Repeat Daily 03: Repeat from Monday to Friday 04: Repeat from Monday to Saturday 05: Repeat from Saturday to Sunday 06.
CONTROLLING THE MULTIPLE PRODUCT 30. Automatic Standby (Command: m n) To set the Automatic Standby function. Data 00: Off 01: 4 Hours Off Acknowledgement [n][ ][Set ID][ ][OK/NG][Data][x] Transmission [j][p][ ][Set ID][ ][Data][Cr] Data 01: Inversion 02: Orbiter 04: White Wash 08: Normal Acknowledgement [p][ ][Set ID][ ][OK/NG][Data][x] 31. Auto Off (Command: f g) To set the Auto Off function.
CONTROLLING THE MULTIPLE PRODUCT ENGLISH ENG 36. Fail Over Input Select (Command: m j) To select fail over mode. *Only available in Fail Over manual mode. Transmission [m][j][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data Data1 to 4(Priority 1 to 3) 60: RGB 70: DVI-D* 90: HDMI** C0: Display Port*** * Use 0x70 as data for DVI-D input, regardless DVID(PC) or DVI-D(DTV).
CONTROLLING THE MULTIPLE PRODUCT Transmission [d][e][ ][Set ID][ ][Data][Cr] Data 00 to 32: Left (-50) to Right (0) Acknowledgement [e][ ][Set ID][ ][OK/NG][Data][x] 42. Tile V Position (Command: d f) To set the Tile Vertical position. *Only available when Tile Natural Mode is off. Transmission [d][f][ ][Set ID][ ][Data][Cr] Data 0 to 32: Bottom (0) to Top (50) (*Bottom/Top values depend on Tile V size.) Acknowledgement [f][ ][Set ID][ ][OK/NG][Data][x] 43.
CONTROLLING THE MULTIPLE PRODUCT 47. FAN Fault Check (Command: d w) To set Fan control on/off. ENGLISH ENG Transmission [d][w][ ][Set ID][ ][Data][Cr] Data FF: Data should be always ff in hexadecimal. Acknowledgement [w][ ][Set ID][ ][OK/NG][Data][x] 48. Temperature Value (Command: d n) To read the inside temperature of the display. Transmission [d][n][ ][Set ID][ ][Data][Cr] Data FF: Data should be always ff in hexadecimal. Acknowledgement [n][ ][Set ID][ ][OK/NG][Data][x] 50.
CONTROLLING THE MULTIPLE PRODUCT 53. S/W Version (Command: f z) To read the software version. Data FF: Data should be always ff in hexadecimal. Acknowledgement [z][ ][Set ID][ ][OK/NG][Data][x] 54. White Balance Red Gain (Command: j m) To adjust white balance red gain. Transmission [j][m][ ][Set ID][ ][Data][Cr] Data 00 to FE: Red gain 0 to 254 Acknowledgement [m][ ][Set ID][ ][OK/NG][Data][x] 55. White Balance Green Gain (Command: j n) To adjust white balance green gain.
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http:// opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com.
