Specification

HOME APPLIANCES
© 2018 LG Electronics USA, Inc. All rights reserved. "LG Life’s Good" is a registered trademark of LG Corp. All other product and brand names are trademarks or registered trademarks of their respective owners. Design, features and specifications are subject to
change without notice. Non-metric weights and measurements are approximate. Some features may require Internet access. Content and services may vary by product and are subject to change without notice. 3/19/18
LG LAUNDRY
WT7200C_
5.0 cu.ft. Capacity Top Load Washer
LG LAUNDRY
DLEX3700_/DLGX3701_
7.4 cu. ft. Front Load Dryer
PRODUCT FEATURES
7.4 cu. ft. Capacity
12 Dryer Programs
ENERGY STAR® Qualied
SmartThinQ® Technology
SmartDiagnosis™
TurboSteam™
Wi-Fi Connectivity
KEY FE ATURES
SUMMARY
Capacity 7.4 cu. ft.
Matching Washer WM3700HWA
Sensor Dry Yes
Steam Yes
Colors White (W), Graphite Steel (V),
Wild Cherry Red (R)
APPEARANCE
Intelligent Electronic Controls
with LED Display
Yes
Dial-A-Cycle™ Yes
Touch Buttons Yes
ENERGY
ENERGY STAR® Qualied Yes
DRYER PROGRAMS
No. of Programs 12
Normal, Heavy Duty, Bedding,
Anti Bacterial, SteamSanitary™,
SteamFresh™, Perm. Press,
Delicates, Towels, Speed Dry
(Manual Dry), Air Dry (Manual
Dry), Downloaded
DRYER OPTIONS
No. of Options 12
More Time, Less Time, Damp Dry
Signal, Wrinkle Care, Control
Lock, Custom Program, PGM
Save, Wi-Fi Connect, Energy
Saver, TurboSteam™, Reduce
Static, Remote Start
Temperature Settings High, Medium High, Medium, Low,
Ultra Low
Drying Levels Very Dry, More Dry, Normal Dry,
Less Dry, Damp Dry
Manual Dry Times 60 min., 50 min., 40 min., 30 min.,
20 min., More Time/Less Time
FABRIC CARE FEATURES
Sensor Dry Yes
Precise Temperature Control with
Variable Heater
Yes
Steam TurboSteam™
CONVENIENCE FEATURES
3 Minute Installation Check Yes
LoDecibel™ Quiet Operation Yes
End of Cycle Signal Yes
Drum Light Yes
Reversible Door Yes
FlowSense™ Duct Clogging
Indicator
Yes
Wrinkle Care Option Yes
Child Lock Yes
Venting Option Electric: 4 Way Venting / Gas: 3
Way Venting
4 Adjustable Legs Yes
Remaining Time Display/Status
Indicator(s)
Yes
SMARTTHINQ® TECHNOLOGY
SmartDiagnosis™ Yes
Wi-Fi Yes
Voice Activation Yes
Works with Google Assistant
Remote Control and Cylce
monitor
Yes
Energy Monitoring Yes (Wi-Fi)
ENERGY
ENERGY STAR® Qualied Yes
MATERIALS AND FINISHES
Aluminized Alloy Steel Drum Yes
Tub Rear Painted
Cabinet Painted Steel
Door Round w/ Chrome trim
All Available Colors White (W), Graphite Steel (V),
Wild Cherry Red (R)
POWER SOURCE
Ratings CSA Listed
Electrical Requirements 120V, 15 Amps (Gas) / 240V 30
Amps (Electric)
Type Electric (DLEX3700_)
Gas (DLGX3701_)
BTU Rating 10,000 Feet
OPTIONS/ACCESSORIES
LP Conversion Kit 383EEL3002D
Side Venting Kit 383EEL9001B
Pedestal WDP4W
Pedestal (WxHxD) 27 x 14 1/8 x 30 3/4 (50 1/2 D
with door open)
DIMENSIONS
Product (WxHxD) 27" x 38 11/16" x 30"
Depth with Door Open 51"
Carton (WxHxD) 29 7/10" x 43 1/5" x 31 3/10"
Weight (Product/Carton) Electric 123
Weight (Product/Carton) Gas 136.2
WARRANTY
Parts and Labor 1 Year
WARRANTY
DLEX3700W 048231024969
DLGX3701W 048231024976
WM3700HWA 048231024624
WM3700HVA 048231024600
DLEX3700V 048231024921
DLGX3701V 048231024938
WDP4W (Pedestal) 048231011211
WD100CW (LG SideKick™) 048231015172
SMART APPLIANCE
Enjoy new ways to control your
home with LG smart appliances
• Get an alert when kids forget to close the door
• Make more ice while you’re at work
• Works with LG SmartThinQ® app
