DP271B-P_AA6PLLW_ENG Portable DVD Player Owner’s Manual Model: DP271/DP271B Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.
Safety Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: This product employs a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Should the unit require maintenance, contact an authorized service center. Use of controls, adjustments or the performance of procedures other than those specified herein may result in hazardous radiation exposure.
Safety Precautions (continued) Most appliances recommend they be placed upon a dedicated circuit; That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain. Disposal of your old appliance 1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2.
Contents Playing an Audio CD or MP3/WMA file . . . . . . . . . . . . . . . . . . . . . . . 28 Programmed Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Repeat Programmed Tracks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Erasing a Track from Program List . . . . . . . . . . . . . . . . . . . . . . . . 29 Erasing the Complete Program List. . . . . . . . . . . . . . . . . . . . . . . . 29 Viewing a JPEG file . . . . . . . . . . . . . . . . . . . . . . . . .
Before Use Notes on Discs Handling Discs Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the disc. This manual provides information on the operation and maintenance of your unit. Should the unit require service, contact an authorized service location.
Before Use (continued) Maintenance and Service Maintaining the Unit Refer to the information in this chapter before contacting a service technician. The DVD player is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. Handling the Unit Depending on the operating environment, regular inspection and maintenance are recommended after every 1,000 hours of use.
Before Use (continued) DVD (8 cm / 12 cm disc) Video CD(VCD) (8 cm / 12 cm disc) Regional Code This unit has a regional code printed on the rear of the unit. This unit can play only DVD discs labelled same as the rear of the unit or “ALL”. Audio CD (8 cm / 12 cm disc) In addition, this unit plays DVD±R/RW and CD-R/RW, SVCD, USB that contains audio titles, DivX, MP3, WMA, and/or JPEG files.
Identification of Controls a LCD screen Main Unit b Speaker c LCD MODE: NORMAL → 4:3 Mode → OFF d Function Buttons • • • • • DISPLAY: Accesses On-Screen display. MODE: Selects a mode among DISC, AV IN or USB. SETUP: Accesses or removes setup menu. MENU: Accesses menu on a DVD disc. COLOR/BRIGHT: Selects the mode of LCD adjustment Brightness → Color → OFF • FLIP: Rotates the screen. a b e Menu Control Buttons • b B v V (left/right/up/down) Selects an item in the menu. • b B: Adjusts the COLOR/BRIGHT.
Identification of Controls (continued) a Volume Control b Earphones jacks c COAXIAL jack d AV IN/OUT jack NOTE a b c d If the VIDEO IN signal is not connected in AV IN mode, this unit will automatically power off in 10 minutes to prevent battery discharge. e e DC IN Connect the AC adapter or Automotive adapter. f Remote sensor Receive the signal from the Remote Control for operation. g Battery charge indicator h (POWER): Switches the player ON or OFF.
Identification of Controls (continued) a Remote Control a b c c POWER: Switches DVD Player ON or OFF. AUDIO: Selects an audio language. SUBTITLE: Selects a subtitle language. ANGLE: Selects a DVD camera angle, if available. Reverse SKIP/SEARCH ( . ): Search backward*/ go to beginning of current chapter or track or go to previous chapter or track. Forward SKIP/SEARCH ( > ): Search forward*/ go to next chapter or track. * Press and hold button for about two seconds.
Identification of Controls (continued) Insert the battery (Lithium battery) NOTES • Replace Remote Control unit battery with 3V micro lithium cells such as CR. 2025 or its equivalent. • Dispose of battery safety in accordance with local laws. Do not dispose of in fire. Warning : The battery used in this device may present a fire or chemical burn hazard if mistreated. Do not recharge, disassemble, incinerate, or heat above 100 °C (212 °F). Replace the battery with Matsushita Elec. Ind. Co., Ltd.
Power Connections Caution Connect the AC adapter. • Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire or electric shock. • Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock. • Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player. AC adapter • This AC adapter operates on 100-240V~ 50/60Hz 1.5A.
Power Connections (continued) This unit and its automotive adapter are designed for use in vehicles that have 8.5-16 volt, negative ground electrical systems. (This is standard for most vehicles.) If your vehicle has a different type of electrical system, the DC power system cannot be used. a Cigarette lighter socket b Examples include: - Inside a car with the windows closed and in direct sunshine. - Near a heating appliance. a Connect the automotive adapter to the DC IN the unit.
Power Connections (continued) Battery Pack NOTES Charge the battery pack before using it for the first time. • Do not detach the battery pack during playback. • Be careful not to drop the battery pack. A Detaching the battery pack a Press the PUSH knob. Attaching the battery pack a Match the hooks of the battery pack into the holes on the bottom of the player. A b Pull the battery pack until the hooks click. b Press and slide the battery pack until the hooks click.
Power Connections (continued) Player A Recharging and play times Recharging without Playback Approx. 3 hour Battery Pack Play time LCD On LCD Off Approx. Approx. 3.5 hours* 4 hours * When Brightness control is set to initial mode. - using the headphones and volume center. Connect the AC adapter cord Charge indicator A Press “Display” to display the battery status on the screen. 3. During recharging, charge indicator is red. If recharging is complete, charge indicator changes to green color.
Rotating the LCD After rotating LCD completely, you can fold the LCD screen as shown above. You can rotate LCD clockwise an angle of 180 degrees. However, if you turn it by force, it can cause serious damage.
Playing a Disc Select a MODE 2. Open the outer cover and press POWER button. Selects a mode among DISC, AV IN or USB. 3. Press OPEN to open the disc lid and insert a disc with the side you want to play label up. Close the disc lid by hand. 1. Press MODE button on the unit. The mode selection menu appears on the screen. • If the disc is placed in upside down (and it is a single-sided disc), “CHECK DISC” or “DISC ERROR” appears on the screen.
On-Screen Display Displaying Disc Information on-screen Initial Settings You can display various information about the disc loaded on-screen. By using the Setup menu, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup menu, among other things. For details on each Setup menu item, see pages 19 to 23. 1. Press DISPLAY to show various playback information. The items displayed differ depending on the disc type or playing status.
Initial Settings DISPLAY Menu Language TV Aspect Select a language for the Setup menu and on-screen display. 4:3: Select when a standard 4:3 TV is connected. Disc Audio / Subtitle / Menu 16:9: Select when a 16:9 TV is connected. Select the language you prefer for the audio track (disc audio), subtitles and the disc menu. NOTE If the TV Aspect option is set to 16:9, the Display Mode setting is automatically set to Widescreen. Original: Refers to the original language in which the disc was recorded.
Initial Settings (continued) AUDIO Sample Freq. (Frequency) Each DVD disc has a variety of audio output options. Set the player’s AUDIO options according to the type of audio system you use. If your receiver or amplifier is NOT capable of handling 96 kHz signals, select 48 kHz. When this choice is made, this unit automatically converts any 96 kHz signals to 48 kHz so your system can decode them. If your receiver or amplifier is capable of handling 96 kHz signals, select 96 kHz.
Initial Settings (continued) LOCK (Parental Control) 3. Select a rating from 1 to 8 using the v / V buttons. Unlock: If you select unlock, parental control is not active and the disc plays in full. NOTE If you set a rating for the unit, all disc scenes with the same rating or lower are played. Higher rated scenes are not played unless an alternate scene is available on the disc. The alternative must have the same rating or a lower one. If no suitable alternative is found, playback stops.
Initial Settings (continued) Password Area Code You can enter or change password. Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 41. 1. Select Password on the LOCK menu then press B. 2. To make a new password: Press ENTER when the “New” option is highlighted. Enter a new password using the numbered buttons then press ENTER. Enter the password again to verify. 1. Select “Area Code” on the LOCK menu then press B. 2.
Initial Settings (continued) DivX(R) VOD We provide you the DivX® VOD (Video On Demand) registration code that allows you to rent and purchase videos using the DivX® VOD service. For more information, visit www.divx.com/vod. The PBC, DivX(R) VOD settings can be changed. 1. Select “DivX(R) VOD” option then press B. 2. Press ENTER while “Select” is selected and the registration code will appear. Use the registration code to purchase or rent the videos from DivX® VOD service at www.divx.com/vod.
General Features If a menu screen is displayed Moving to another TITLE When a disc has more than one title, you can move to another title. Press DISPLAY during playback or resume play then the appropriate number (0-9) or use b / B to move to another title. DVD Use the b B v V buttons to select the title/chapter you want to view, then press ENTER to start. Press TITLE or MENU to return to the menu screen. Moving to another CHAPTER/TRACK VCD ALL During playback, press SKIP/SEARCH (.
General Features (continued) Still Picture and Frame-by-Frame Playback ALL During playback, press REPEAT repeatedly to select a desired repeat mode. ALL During playback, press PAUSE/STEP(X) to pause playback. DVD Video Discs: Chapter/Title/Off DVD VCD DivX Video CDs, Audio CD, DivX/MP3/WMA discs: Track/All/Off Press PAUSE/STEP(X) repeatedly to play Frame-by-Frame. ( Remote Control Only ) To exit still motion mode, press PLAY(N).
General Features (continued) Title Menu Subtitles DVD DVD DivX If the current DVD title has a menu, the title menu appears on the screen. Otherwise, the disc menu may appears. Press SUBTITLE repeatedly during playback to see the different subtitle languages. Disc Menu NOTE DVD If there is no information or there is a code that can not read in the DivX file, “ 1 ” etc are displayed. Press MENU and the disc menu is displayed. Press MENU again to exit.
Additional features DVD VCD Last Scene Memory DivX To enter a Marker DVD ACD VCD1.1 This unit memorizes last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the unit or switch off the unit. If you load a disc that has the scene memorized, the scene is automatically recalled. You can start playback from up to nine memorized points. To enter a marker, press MARKER at the desired point on the disc.
Playing an Audio CD or MP3/WMA file MP3 / WMA file compatibility with this unit is limited as follows: • Sampling frequency: within 8 - 48 kHz (MP3), within 32 - 48kHz (WMA) This unit can play Audio CDs or MP3/WMA files. MP3/ WMA/ Audio CD Once you insert an MP3/WMA files recorded media or Audio CD, a menu appears on the TV screen. Press v / V to select a track/file then press PLAY(N) or ENTER and playback starts. You can use variable playback functions. Refer to page 24-25.
Programmed Playback Repeat Programmed Tracks Press REPEAT to select a desired repeat mode. • Track: repeats the current track • All: repeats all the tracks on programmed list. • Off(No display): does not play repeatedly. 1. Insert an Audio CD or MP3/WMA files recorded media. AUDIO CD or MUSIC menu appears. 2. Press PROG. The E mark will appear NOTE NOTE Press PROG. again, then the Program Edit mode. E If you press > once during Repeat Track playback, the repeat playback cancels.
Viewing a JPEG file This unit can play JPEG files. TIPS 1. Insert a JPEG files recorded media. The PHOTO menu appears on the TV screen. • Press MENU to move to the next page. • There are three Slide Speed options : >>> (Fast), >> (Normal) and > (Slow). Use v V b B to highlight the . Then, use b / B to select the option you want to use. • On a CD with MP3/WMA, JPEG and MOVIE file, you can switch MUSIC, PHOTO and MOVIE menu. Press TITLE and MUSIC, PHOTO and MOVIE word on top of the menu is highlighted.
Viewing a JPEG file (continued) Moving to another file Press SKIP/SEARCH (. or >) or cursor (b or B) once while viewing a picture to advance to the next or previous file. • Depending upon the size and number of JPEG files, it could take a long time for the unit to read the disc’s contents. If you don’t see an on-screen display after several minutes, some of the files may be too large — reduce the resolution of the JPEG files to less than 2M pixels as 2760 x 2048 pixels and burn another disc.
Playing a DVD VR format Disc This unit will play DVD-RW discs recorded using the Video Recording (VR) format. 1. Insert a disc and close the tray. The DVD-VR menu appears on the screen. 2. Press v / V to select a track then press PLAY(N) or ENTER and playback starts. 3. Press MENU to move to the list menu. NOTES • This unit will play DVD-R/RW disc that is recorded using the DVD-Video format that have been finalized using a DVD-recorder. Unfinalized DVDR/RW discs cannot be played in this unit.
Playing a DivX Movie file (continued) 1. Insert a DivX file recorded media. The MOVIE menu appears on the screen. TIPS • Press MENU to move to the next page. • On a CD with MP3/WMA, JPEG and MOVIE file, you can switch MUSIC, PHOTO and MOVIE menu. Press TITLE and MUSIC, PHOTO and MOVIE word on top of the menu is highlighted. • The disc subtitle may not be displayed properly, if a DivX subtitle is downloaded through the internet. 2. Press v / V to select a folder, and press ENTER.
Playing a DivX Movie file (continued) DivX disc compatibility with this unit is limited as follows: Playable DivX file • Available resolution size of the DivX file is under 720x576 (W x H) pixel. ".avi ", ".mpg ", ".mpeg " Playable Subtitle format • The file name of the DivX subtitle is limited to 56 characters. SubRip(*.srt/*.txt) SAMI(*.smi) SubStation Alpha(*.ssa/*.txt) MicroDVD(*.sub/*.txt) SubViewer 2.0(*.sub/*.txt) TMPlayer(*.txt) Dvd Subtitle System(*.txt) VobSub (*.
Playing an USB Flash Drive • Do not extract the USB Flash Drive in operating. • Music files (MP3/WMA), image files (JPEG) and DivX files can be played. • The total number of files in a USB Flash Drive should be less than 650 files. • Some USB Flash Drive is not supported on this unit. • This unit supports only USB Flash Drive. • This unit can support USB1.1. 1. Connect the USB Flash Drive to the USB port on the unit after power is on. 2. Press MODE on the unit.
Setting up the Player The picture and sound of a nearby TV, VCR, or radio may be distorted during playback. If this occurs, position the player away from the TV, VCR, or radio, or turn off the unit after removing the disc. Rear of TV AV output Connections Depending on your TV and other equipment there are various ways you can connect the unit. Please refer to the manuals of your TV, stereo system or other devices as necessary for additional connection information.
Setting up the Player (continued) AV input Connections to Your unit Connect the input jacks (Audio/Video) on the unit to the audio/video out jacks on your external device, using audio/video cables. 1. Set the Mode selection menu to “AV IN” mode. 2. Connect the black end of supplied AV cable to the AV IN/OUT jack on the unit. 3. Connect the yellow end of supplied AV cable to the VIDEO Output jack on your external device. External Device 4.
Setting up the Player (continued) Amplifier equipped with 2-channel analog stereo or Dolby Pro Logic ll / Pro Logic: Connect the AV IN/OUT jacks on the unit to the audio left and right IN jacks on your amplifier, receiver, or stereo system, using the audio cables. Audio Connection to Optional Equipment Connect the unit to your optional equipment for audio output. You must set the Mode selection menu to “USB” or “ DISC” mode.
Troubleshooting No picture on the LCD or TV (including video from another unit). • • • • The The The The Cause power cord is disconnected. battery is discharged. video cable is not connected securely. MODE selection is not set correctly. • LCD mode is set to OFF. • The TV is not set to receive DVD signal output. No sound. The unit does not start playback. No response when buttons are pressed. The Remote Control does not work properly.
Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu.
Area Codes Choose an area code from this list.
Specifications General Liquid Crystal Display Power supply: DC 9.5V (AC adapter terminal), DC 7.4V (Battery) Panel size: 7 inches wide (diagonal) Projection system: R.G.B. stripe Power consumption: 12W with battery Driving system: TFT active matrix Net Weight: 1.60 lbs (0.73 kg) (without battery pack) Resolution: 234 x 480 x 3 (effective pixel rate: more than 99.99%) External dimensions (W x H x D): 7.6 x 1.5 x 6.7 inches (195 x 38.5 x 172.
DP271B-P_AA6PLLW_POR LEITOR DE DVD PORTÁTIL MANUAL DO PROPRIETÁRIO Modelo: DP271/DP271B Leia este manual atentamente antes de iniciar a operação do aparelho. Guarde-o em local fácil de ser encontrado, para futuras consultas.
Instruções de Segurança CUIDADO NÃO ABRA. RISCO DE CHOQUE CUIDADO: Este produto utiliza um Sistema Laser. Para garantir a utilização correcta deste produto, por favor leia cuidadosamente este manual de instruções e conserve-o para futura referência. Se a unidade requerer manutenção, contacte um centro de assistência autorizado. O uso de controlos, ajustamentos ou procedimentos que não estejam aqui especificados pode resultar numa exposição perigosa à radiação.
Instruções de Segurança (Continuação) É recomendável para a maioria dos aparelhos a sua instalação num circuito dedicado; Trata-se de um circuito com uma tomada individual que fornece energia apenas a esse aparelho e que não possui saídas adicionais ou circuitos ramificados. Consulte a página de especificações deste manual do proprietário em caso de dúvidas. Eliminação do seu antigo aparelho 1.
Conteúdo Sobre a visualização do símbolo .......................5 Símbolos utilizados neste Manual . . . . . . . . . . . . . . . . . . . . . . . . . 5 Observações sobre os Discos . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Manutenção e Assistência . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Tipos de Discos Reproduzíveis . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Código Regional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antes de usar Observações sobre os Discos Manipular os Discos Não toque no lado de reprodução do disco. Segure no disco pelas extremidades para que as suas impressões digitais não atinjam a superfície. Nunca cole papel ou fita no disco. Este manual fornece informações sobre o funcionamento e a manutenção do seu leitor de DVD. Se a unidade necessitar de manutenção, contacte um centro de assistência autorizado.
Antes de usar (Continuação) Manutenção e Assistência Conservar a Unidade Consulte as informações deste capítulo antes de contactar um técnico de assistência. O leitor de DVD é um dispositivo de alta tecnologia e precisão. Se as lentes de captação óptica e as componentes da unidade do disco estiverem sujas ou gastas, a qualidade da imagem pode ser reduzida. Manipular a Unidade Dependendo do ambiente operativo, recomenda-se uma inspecção e manutenção regulares após cada 1,000 horas de utilização.
Antes de usar (Continuação) CD Áudio (disco 8 cm / 12 cm) Código Regional DVD (disco 8 cm / 12 cm) Esta unidade tem um código regional impresso na parte posterior. Esta unidade apenas é capaz de reproduzir discos de DVD rotulados da forma indicada na parte posterior da unidade ou “ALL (Tudo)”. Além disso, esta unidade reproduz DVD±R/RW e CD-R/RW, USB discos de dupla camada, USB com títulos de áudio, DivX, MP3, WMA e/ou ficheiros JPEG.
Identificação dos Controles a Tela do LCD Principal Unidade b Alto-falante c LCD MODE : NORMAL → Modo 4:3 → OFF d Botões de função • DISPLAY : Acede ao menu On-Screen. • MODE : Seleccione um modo entre DISCO, ENTRADA DE AV ou USB. a • SETUP : Acede ou remove o menu de configuração. • MENU :Acede ao menu de um disco DVD. • COR/LUMINOSIDADE : Selecciona o modo de regulação do LCD Luminosidade → Cor → DESLIGADO • FLIP: rotação do ecrã.
Identificação dos Controles (continuação) a Controle de volume b Tomada para fone de ouvido c Tomada COAXIAL d Tomada AV IN/OUT NOTA a b c d Se o sinal de ENTRADA DE VÍDEO não estiver ligado no modo de ENTRADA DE AV, esta unidade desliga-se automaticamente ao fim de 10 minutos para evitar descarregar a bateria. e e DC IN Liga o adaptador de CA ou o adaptador do automóvel. f Sensor Remoto Capta os sinais oriundos do Controlo Remoto para as operações.
Identificação dos Controles (continuação) Controlo Remoto a b c d a c POWER: LIGA e DESLIGA a unidade. AUDIO: Selecciona uma linguagem áudio (DVD). SUBTITLE: Selecciona um idioma de legendagem. ANGLE: Selecciona um ângulo de câmara de DVD, se este estiver disponível. Inverso SKIP/SEARCH ( . ): Procurar para trás * / ir para o início do capítulo ou faixa que está sendo reproduzido ou capítulo/faixa anterior. Para a frente SKIP/SEARCH ( > ): Procurar e avançar* / ir para o próximo capítulo ou faixa.
Identificação dos Controles (continuação) Coloque a bateria (Bateria de Lithium) NOTAS • Substitua a bateria da unidade de controle remoto com células de 3V micro lithium como CR. 2025 ou equivalente. • A bateria deve ser jogada fora de acordo com as leis locais. Tenha cuidado ao fazê-lo. Não jogue no fogo. Advertência : A bateria usada neste produto pode apresentar fogo ou perigo de queimadura química se tratada indevidamente. Não recarregue, incinere ou aqueça acima de 100 °C.
Ligações Eléctricas CUIDADO • Não conecte o cabo de rede na tomada se a voltagem for diferente da indicada na etiqueta, isto pode causar risco de fogo ou choque elétrico. • Não conecte ou desconecte o plugue com as mãos molhadas. Isto pode causar um choque elétrico. • Não use outro adaptador AC a não ser o especificado. Isto pode causar incêndio ou danificar o a arelho Ligar o transformador AC Adaptador AC • Este adaptador AC opera em AC entre 100V e 240V~ 50-60Hz 1.5A.
Ligações Eléctricas (continuação) CUIDADO • Para evitar choques eléctricos e possíveis danos no seu leitor de DVD ou veículo, desligue sempre o adaptador automóvel da tomada de isqueiro antes de retirar a ficha do seu leitor DVD. • Está instalado um fusível de A3 amp. 250V para protecção no adaptador automóvel. • Quando o motor estiver a arrancar, desligue o adaptador automóvel da tomada de isqueiro do veículo. • Não ligue o seu leitor de DVD se a bateria do automóvel estiver descarregada.
Ligações Eléctricas (continuação) Conjunto de Bateria NOTAS Carregando o conjunto de baterias pela primeira vez. • Não desmonte a bateria durante a reprodução. • Tenha cuidado para não deixar cair a bateria. Desmontagem da bateria a Prima o botão de deslocamento. A Prendendo o conjunto de baterias a Unir os ganchos do conjunto de baterias com os furos na parte traseira do leitor de DVD. A b Puxe a bateria até os ganchos emitirem um clique.
Ligações Eléctricas (continuação) Player A Recarregando Sem reprodução Aprox. 3 horas Conjunto de bateria Ligar o cabo do transformador AC. LCD Lig Aprox. 3.5 horas* Tempo LCD Deslig Aprox. 4 horas * Quando o controlo de Luminosidade está definido para o modo inicial. - Utilizar os auriculares e o centro de volume. Indicador de carga A 3. Enquanto estiver carregando a bateria, o indicador acende em vermelho. Ao completar, o indicador mudará para verde.
Rodar o LCD Pode rodar o LCD no sentido dos ponteiros do relógio até um ângulo de 180 graus. Contudo, se exercer força para rodar o ecrã, poderá causar sérios danos. Depois de rodar completamente o LCD, pode integrar o ecrã LCD da forma apresentada acima.
Reproduzindo um Disco Seleccione um MODO 2. Abra a tampa exterior e prima o botão POWER. Seleccione um modo entre DISCO, ENTRADA DE AV ou USB. 3. Pressione OPEN para abrir a tampa do disco e coloque um disco com o lado que deseja tocar para baixo. Feche a tampa do disco com a mão. 1. Prima o botão MODO na unidade. O menu de selecção de modo aparece no ecrã.
Instruções no ecrã (On-Screen) Apresentar as Informações do Disco no ecrã Definições Iniciais Pode fazer com que sejam apresentadas no ecrã várias informações sobre o disco introduzido. Ao utilizar o menu de configuração (Setup), pode efectuar vários ajustamentos em itens como imagem e som. Pode, ainda, definir um idioma para as legendas e o menu de configuração, entre outras coisas. Para mais pormenores sobre cada item do menu de configuração, consulte as páginas 19 a 23. 1.
Regulagens Iniciais EXPOSIÇÃO Idioma Formato Da Ecrã Operações Avançadas LÍNGUA Seleccione um idioma para o menu de configuração e para as instruções no ecrã. 4:3: Seleccionar quando estiver ligado um televisor padrão 4:3. 16:9: Seleccionar quando estiver ligado um televisor de ecrã panorâmico 16:9. Áudio / Legendas / Menu Do Disco NOTA Seleccione o idioma que prefere para a faixa áudio (disco áudio), as legendas e o menu do disco.
Regulagens Iniciais (continuação) AUDIO Frequência Cada disco de DVD possui uma variedade de opções de saída áudio. Defina as opções ÁUDIO do leitor de acordo com o tipo de sistema áudio que utiliza. Se o receptor ou amplificador NÃO for capaz de processar sinais de 96 kHz, seleccione 48 kHz. Quando esta opção é feita, esta unidade converte automaticamente quaisquer sinais 96 kHz para 48 kHz, para que o seu sistema possa descodificá-los.
Regulagens Iniciais (continuação) Censura 1-8: A classificação um (1) tem o maior número de restrições e a classificação oito (8) é a menos restritiva. Desbloqueado Se seleccionar Unlock (desbloquear), o controlo parental é desactivado e o disco é reproduzido na totalidade. NOTA Se seleccionar uma classificação para o leitor, todas as cenas do disco com a mesma classificação ou inferior são reproduzidas. As cenas com classificação acima não são reproduzidas, salvo se o disco tiver uma cena alternativa.
Regulagens Iniciais (continuação) Senha Código Do País Pode inserir ou alterar a palavra-passe. Introduza o código da zona cujos padrões foram utilizados para classificar o disco de vídeo de DVD, tendo por base a lista da página 41. 1. Seleccione a opção Senha no menu BLOCO e prima B. 2. Como criar uma palavra-passe nova: Prima ENTER quando a opção “Nova Senha” se encontrar destacada. Introduza uma nova palavra-passe utilizando os botões numéricos e prima ENTER.
Regulagens Iniciais (continuação) As definições PBC e DivX(R) VOD podem ser alteradas. 1. Seleccione a opção “DivX(R) VOD” e depois prima B. 2. Prima ENTER com a opção “Seleccionar” seleccionada para fazer aparecer o código do registo. Utilize o código do registo para adquirir ou alugar vídeos através do serviço DivX® VOD, recorrendo ao site da Internet www.divx.com/vod. Siga as instruções e efectue a transferência do vídeo para um disco para ser posteriormente reproduzido nesta unidade.
Funções Gerais Se o ecrã de um menu for apresentado Passar para outro TÍTULO DVD Quando um disco tem mais do que um título, pode deslocar-se para outro título. Prima DISPLAY (VISUALIZAR) durante a reprodução ou retome a reprodução e, de seguida, reproduza o número adequado (0-9) ou utiliz b / B para se deslocar para outro título. DVD Use os botões b B v V para seleccionar o título/capítulo que deseja visualizar. A seguir, prima ENTER para inicia. Prima TITLE ou MENU para voltar ao ecrã do menu.
Funções Gerais (continuação) Imagem Fixa e Reprodução Frame-by-Frame Durante a reprodução, prima repetidamente REPEAT para seleccionar o modo de repetição pretendido. ALL Durante a reprodução, prima PAUSE/STEP(X) para fazer uma pausa na reprodução. DVD VCD Discos Vídeo DVD - Capítulo/Título/Desligado CD Vídeo, CD Áudio, discos de DivX/MP3/WMA: Faixas/Tudo/Desligado DivX Prima repetidamente PAUSE/STEP(X) para fazer a reprodução imagem a imagem.
Funções Gerais (continuação) Menu do Título Legendas DVD Se o título de DVD actual tiver um menu, o menu do título é apresentado no ecrã. Caso contrário, o menu do disco pode ser apresentado. Menu do Disco NOTA Se não existir informação ou se existir um código que não possa ler no ficheiro DivX, “ 1 ” etc é visualizado. Prima MENU para visualizar o menu do disco. Prima novamente MENU para sair.
Opções Adicionais DVD VCD Memória da Última Cena DivX Para introduzir um Marcador DVD ACD VCD1.1 Este aparelho memoriza a última programação do disco que você assistiu. Mesmo que remova o disco ou desligue o aparelho. Se você repor outro disco e ajustar a memória, a última programação é automaticamente remembrada. Pode iniciar a reprodução a partir de até nove pontos memorizados. Para inserir um marcador, prima MARKER no ponto desejado do disco.
Reproduzir um CD de Áudio ou um ficheiro de MP3/WMA Esta unidade é capaz de reproduzir CDs de Áudio ou ficheiros em formato MP3/WMA. A compatibilidade dos discos MP3 / WMA com este leitor está limitada ao seguinte: • Frequência de amostragem: 8-48kHz (MP3), de 32-48 kHz (WMA) MP3/ WMA/ CD de Áudio Após introduzir o suporte material dos ficheiros em formato MP3/ WMA ou o CD de Áudio, é apresentado um menu no ecrã de TV.
Reprodução Programada Repetir Faixas Programadas Prima REPEAT para seleccionar o modo de repetição desejado. • Faixa : repete a faixa actual • Tudo : repete todas as faixas da lista programada. • Desligar : Sem visualização : não reproduz repetidamente. 1. Introduza um CD de Áudio ou um suporte material de ficheiros gravados em formato de MP3/WMA. Será apresentado o menu do AUDIO CD ou de MUSIC. 2. Prima PROG. O marcador E será apresentado.
Ver um ficheiro em formato JPEG Esta unidade consegue reproduzir ficheiros JPEG. CONSELHOS 1. Introduza um suporte físico de ficheiros em formato JPEG. O menu PHOTO aparece no ecrã do televisor. • Prima MENU para aceder à página seguinte. • Existem quatro opções de velocidade da apresentação (Slide Speed) : >>> (Baixo), >> (Normal) e > (Alto). Utilize v V b B para realçar o . A seguir, utilize b / B para seleccionar a opção que pretende utilizar.
Visualizar um Disco JPEG (continuação) Prima uma vez SKIP/SEARCH (. ou >) ou o cursor (b ou B) ao visualizar uma imagem para avançar para o ficheiro seguinte ou anterior. • Dependendo do tamanho e número de ficheiros JPEG, pode demorar algum tempo para o leitor de DVD ler o conteúdo do disco.
Reproduzir um disco de formato DVD VR Esta unidade reproduz discos DVD-RW gravados através do formato Video Recording (VR). 1. Insira um disco e feche o tabuleiro. O menu DVD-VR aparece no ecrã. 2. Prima v / V para seleccionar uma faixa e prima PLAY(N) ou ENTER para iniciar a reprodução. 3. Prima o botão MENU para aceder ao menu de listagem. NOTAS • Esta unidade lê apenas discos DVD-R/RW gravados no formato DVDVideo que tenham sido finalizados utilizando um gravador de DVD.
Reproduzir um ficheiro de Filme DivX Sugestão para a apresentação das legendas de DivX 1. Introduza um suporte físico com ficheiros em formato DivX. O menu MOVIE aparece no ecrã do televisor. Se as legendas não forem correctamente apresentadas, prima e mantenha premida a tecla SUBTITLE durante cerca de 3 segundos, e depois prima b / B para seleccionar diferentes códigos de idiomas, até as legendas serem adequadamente apresentadas. CONSELHOS • Prima MENU para aceder à página seguinte.
Reproduzir um ficheiro de Filme DivX (continuação) A compatibilidade dos discos DivX com este leitor está limitada ao seguinte: Ficheiros DivX reproduzíveis • O tamanho da resolução disponível do ficheiro DivX é inferior a 720x576 (L x A) pixel. Formatos de Legendagem Reproduzíveis ".avi ", ".mpg ", ".mpeg " SubRip(*.srt/*.txt) SAMI(*.smi) SubStation Alpha(*.ssa/*.txt) MicroDVD(*.sub/*.txt) SubViewer 2.0(*.sub/*.txt) TMPlayer(*.txt) Sistema de Legendagem de Dvd(*.txt) VobSub (*.
Reproduzir uma unidade USB Flash • Não extraia a unidade USB Flash a funcionar. • Ficheiros de imagens (JPEG), ficheiros de músicas (MP3 e WMA) e ficheiros Divx podem ser tocados. • O número total de ficheiros contidos na unidade USB Flash deverá ser inferior a 650 ficheiros. • Algumas unidades USB Flash não são suportadas nesta unidade. • Esta unidade suporta apenas a unidade USB Flash. • Esta unidade pode suportar USB 1.1. 1.
Configurar o Leitor A imagem e o som de um televisor, vídeo ou rádio novo podem sair distorcidos durante a reprodução. Se tal ocorrer, posicione o leitor afastado do televisor, vídeo ou rádio, ou desligue a unidade antes de remover o disco. Painel traseiro do televisor Ligações de saída AV Dependendo do seu televisor e de outros equipamentos, existem várias formas de ligar o leitor.
Configurar o Leitor (continuação) Ligações de entrada AV à unidade. Ligue as fichas de entrada (Áudio/Vídeo) na unidade às tomadas de saída de áudio/vídeo existentes no dispositivo externo, através da utilização dos cabos de áudio/vídeo. 1. Definir o menu de selecção do modo para o modo “AV IN”. 2. Ligue a extremidade preta do cabo AV fornecido à tomada AV IN/OUT da unidade. 3. Ligue a extremidade amarela do cabo AV fornecido à tomada de saída VIDEO do dispositivo externo. Dispositivo externo 4.
Configurar o Leitor (continuação) Amplificador equipado com modo estéreo analógico de 2 canais ou Dolby Pro Logic ll / Pro Logic: Ligue os conectores AV IN/OUT do leitor de DVD aos conectores áudio IN esquerdo e direito do seu amplificador, receptor ou sistema estéreo, utilizando os cabos áudio. Ligação Áudio a Equipamento Opcional Ligue o leitor de DVD ao seu equipamento opcional para saída de áudio. Tem de definir o menu de selecção de Modo para o modo “USB” ou “ DISC”.
Resolução de problemas Causa • O cabo de rede está desconetado. • A bateria está descarregada. Não há imagem no LCD • O cabo de vídeo não está conectado direito. ou TV (incluindo video da outra unidade). • A selecção do MODO não está correctamente definida. • LCD está no modo OFF. • O TV não está ajustado para recever sinal de DVD. • O equipamento conectado com o cabo de áudio não está ajustado para recever sinal de DVD. • Os cabos de áudio não estão conectados adequadamente.
Códigos do Idioma Use esta lista para inserir o seu idioma escolhido para as seguintes definições iniciais: Sistema Áudio, Legendas, Menu Do Disco.
Códigos Nacionais Use esta lisa para inserir o seu país.
Especificações Geral Visor de cristal líquido Fonte de alimentação : DC 9.5 V (terminal adaptador AC), DC 7.4 V (Bateria) Dimensão do painel : 7 polegadas de largura (diagonal) Sistema de projeção : faixa R.G.B. Consumo de energia: 12 W com bateria Driving system : TFT active matrix Peso: 1.60 lbs (0.73 kg) (sem pilhas) Resolução: 234 x 480 x 3 (taxa efetiva dos pixels: mais do que 99.99%) Dimensões (L x A x P): 7.6 x 1.5 x 6.7 polegadas (195 x 38.5 x 172.
