Operating Instructions LVC-C500 LVC-C503 LVC-C510 LVC-C513 LVC-C530 LVC-C533 LVC-C553 Before installing and using the camera, please read these instructions thoroughly and retain them for later reference.
Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
Contents and Features Contents Features Contents and Features . . . . . . . . . . . . . . . . . . . . . . . . .3 Cautions for Safe Operation . . . . . . . . . . . . . . . . . . . . . .4 Operating Controls and Their Functions . . . . . . . . . . .5 Power IN / CONTROL / External Key(A/D IN) . . . . .6-14 MENU DESCRIPTIONS . . . . . . . . . . . . . . . . . . . . . . . . .15 CAMERA ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 FOCUS MODE SET . . . . . . . . . . . . . . . . . . . . . . .
Cautions for Safe Operation Power Supply This camera must always be operated a 12V DC power supply. Handling of the unit Be careful not to spill water or other liquids on the unit, or to get combustible or metallic material inside the body. If used with foreign matter inside, the camera is liable to fail, or to be a cause of fire or electric shock. Operating and storage location Avoid viewing a very bright object (such as light fittings) for an extended period.
Operating Controls and Their Functions Model: LVC-C500, LVC-C503, LVC-C510, LVC-C513 1 2 1. Tripod adapter This adapter can also be attached on the bottom of the camera. 2. Lens mount cap 3. TELE Key When push the TELE KEY, picture is telephoto 4. WIDE Key When push the WIDE KEY, picture is wide angle 5. Focus Near Key In a manual situation, focus get near. 6. Focus Far Key In a manual situation, focus get far. 7. Menu Key If you want to set up a diverse function, you can push this button. 8.
Power In / Control Model: LVC-C500, LVC-C503, LVC-C510, LVC-C513 1 2 3 You can adjust focus and zoom by a pin terminal on the back side of the camera. 6 5 4 * is the color of the cable.
External Key (A/D IN) Model: LVC-C500, LVC-C503, LVC-C510, LVC-C513 Schematic diagram of wired remote-control 7
Operating Controls and Their Functions Model: LVC-C530, LVC-C533 1. Tripod adapter This adapter can also be attached on the bottom of the camera. 2. Lens mount cap 3. TELE Key 1 2 When push the TELE KEY, picture is telephoto 4. WIDE Key When push the WIDE KEY, picture is wide angle 5. Focus Near Key In a manual situation, focus get near. 6. Focus Far Key In a manual situation, focus get far. 7. Menu Key If you want to set up a diverse function, you can push this button. 8.
Power In / Control Model: LVC-C530, LVC-C533 You can adjust focus and zoom by a pin terminal on the back side of the camera. * is the color of the cable.
Power In / Control Model: LVC-C530, LVC-C533 10
External Key (A/D IN) Schematic diagram of wired remote-control Model: LVC-C530, LVC-C533 11
Operating Controls and Their Functions 1. Tripod adapter Model: LVC-C553 This adapter can also be attached on the bottom of the camera. 2. Lens mount cap 3. TELE Key 1 2 When push the TELE KEY, picture is telephoto 4. WIDE Key When push the WIDE KEY, picture is wide angle 5. Menu Key If you want to set up a diverse function, you can push this button. 6. Control JACK (RJ45) Connect RS-422 interface 7. Focus Far Key In a manual situation, focus get far. 8.
Connections Model: LVC-C553 1 Power Connection 2 1 3 2 1. Remove the insulation on the power cable as illustrated. 2. Attach the terminal tips. 3. Connect to the 12V DC UL Listed, Class 2 Power Supply only on the camera. Connection the monitor 1. To VIDEO OUT 2.
Control Model: LVC-C553 Remote Control Lines are connected to RJ-45 socket as shown below.
MENU DESCRIPTIONS Using TELE, WIDE, F. NEAR, F. FAR button • TELE and WIDE are used for UP and DOWN. • FOCUS+ and FOCUS- are used for INCREASE and DECREASE the data.
CAMERA ID 1. CAMERA ID To connect a large number of camera , It can be assigned to identification number to each camera for camera control easily. (OFF, 0 - 255: total numbers of ID are 256) • It only can be set this function using ID commend. To transfer ID Code of camera , In first byte at PC control. Set the ID number of camera , and then the ID number display continuously.
FOCUS MODE SET 2. Focus Set: 2-1. Focus Mode Set This function is for focus mode setting A) Set up “FOCUS SET” in main menu using Tele/Wide key. Select the “FOCUS MODE” in submenu using Tele/Wide key. And then set the mode (Auto, Push auto, or Manual) using Focus key. 2-2. Focus Distance Set This function is for selection of minimum shooting distance. A) Select the “FOCUS DIST” in submenu using Tele/Wide key. B) Set the focus distance mode from 1cm to 5M. (1cm, 10cm, 50cm, 1M, 3M, 5M) using Focus key.
FOCUS MODE SET 2-4. ZOOM END Set This function is for selection of zoom end position. A) Select the “ZOOM END” in submenu using Tele/Wide key. B) Set the Zoom end mode using Focus key. LVC-C503/C513/C533/C553: from (Zoom Start + 1) to X54 LVC-C500/C510: from (Zoom Start + 1) to X324 2-5. ZOOM SPEED Set This function is for selection of zoom speed. A) Select the “ZOOM SPEED” in submenu using Tele/Wide key. B) Set the Zoom speed, Slow, Middle , Quick using Focus key. 2-6.
FOCUS MODE SET 2-7. INITIAL SET If initial mode set to ON, All FOCUS SET function is changed to the factory setting. A) Select the “INITIAL SET” in submenu using Tele/Wide key. B) Set the initial set mode to ON or OFF using Focus key. 2-8. RETURN TO MAIN MENU This function is exit to main menu. A) Select the “RETURN” in submenu using Tele/Wide key. B) Set the return mode using Focus key.
AWB SET (Auto White Balance) 3. AWB SET 3-1. WB Mode Set This function is for changing the WB mode. AWB WBC MODE RED ADJUST BLUE ADJUST INITIAL SET RETURN AUTO NOT USE NOT USE ON A) Set up “AWB SET” in main menu using Tele/Wide key. B) Select the “WB MODE” in submenu using Tele/Wide key. C) Set the mode Auto, Push auto , Manual, Outdoor, Indoor using Focus key. *WBC MODE: Use for changing White Balance Mode . 1) AUTO: WB Range 2500°K ~ 9500°K .
AWB SET (Auto White Balance) AWB WBC MODE RED ADJUST BLUE ADJUST INITIAL SET RETURN AUTO NOT USE NOT USE ON 3-3. BLUE ADJUST Set This function is available for Manual WB mode. This mode is the adjustment of user option for special color. A) Select the “BLUE ADJUST” in submenu using Tele/Wide key. B) Adjust the level from (0-255 MANUAL) using Focus key. 3-4. PUSH AUTO In case of PUSH AUTO WB mode. Adjust the push auto mode ON, WB act automatically. 3-5.
AE SET (Auto Exposure) 4. AE SET 4-1. AE Mode Set This function is for changing to AE mode. A) Set up “AE SET” in main menu using Tele/Wide key. B) Select the “AE MODE” in submenu using Tele/Wide key. C) Set the mode auto, IRIS MAN, SLOW MAN, SHUTTER MAN, Auto using Focus key Note: SLOW MAN option is not available for LVC-C500, LVC-C510, and LVC-C530. 4-2. IRIS ADJUST Set This function is available for IRIS MAN mode. A) Select the “IRIS ADJUST” in submenu using Tele/Wide key.
AE SET (Auto Exposure) 4-4. BRIGHTNESS ADJUSTMENT Set This function is available for AUTO mode. A) Select the “BRIGHTNESS” in submenu using Tele/Wide key. B) Adjust the level from 0 to 255 using Focus key. 4-5. BACKLIGHT Set Note: WDR option is not available for LVC-C500, LVC-C510, and LVC-C530. 4-6. E SENSITIVE This function is available for SLOW mode / AUTO mode. Area1 Area2 Area0 Area4 Auto BLC A) Select the “BACKLIGHT” in submenu using Tele/Wide key.
AE SET (Auto Exposure) 4-7. FLICKERLESS Set This function is available for AUTO mode. A) Select the “FLICKERLESS” in submenu using Tele/Wide key. B) Set the mode OFF, ON using Focus key. * FLICKERLESS: Use for removing the flicker of picture ON: Remove the flicker (In case of PAL System: Shutter Speed 1/120 sec). 4-8. SHUTTER SPEED Set This function is available for AUTO mode / SHUTTER mode. A) Select the “SHUTTER” in submenu using Tele/Wide key. B) • Set the mode NORMAL, 1/120 - 1/50000 using Focus key.
AE LEVEL (Auto Exposure) 5-1. BLC LEVEL Set This function is for change to BLC LEVEL. A) Select the “BLC LEVEL” in submenu using Tele/Wide key. B) Adjust the level from 0 to 255 using Focus key. 5-2. WDR LEVEL SET This function is for change to WDR LEVEL. A) Select the “WDR LEVEL” in submenu using Tele/Wide key. B) Adjust the level from 0 to 15 using Focus key. 5-3. INITIAL SET A) Select the “INITIAL SET” in submenu using Tele/Wide Command, B) Set the initial set mode to ON or OFF using Focus key. 5-4.
SPECIAL SET 6. SPECIAL SET 6-1. User Title Set This function is for custom title on screen display. A) Set “SPECIAL SET” in main menu using Tele/Wide key. B) Select the “USER TITLE” in submenu using Tele/Wide key. C) Set the position of title and set data using Tele/Wide, Focus key. 6-2. SHARPNESS ADJUST Set A) Select the “SHARPNESS” in submenu using Tele/Wide key. B) Adjust the level from 0 to 255 using Focus key. 6-3. COLOR Set This mode is for B/W mode.
SPECIAL SET 6-5. D EFFECT Set This function is to scroll to mirror relevanced function. A) Select the “D EFFECT” in submenu using Tele/Wide key. B) Set the mode, none, mirror, v-flip, rotation using Focus key. 6-6. INITIAL SET If initial mode set to ON, All SPECIAL functions are changed to the factory setting A) Select the “INITIAL SET” in submenu using Tele/Wide key. B) Set the initial set mode to ON or OFF Using Focus key. 6-7. RETURN TO MAIN MENU This function is exit to main menu.
MOTION DET 7. MOTION DETECTION SET 7-1. DETECTION Mode Set A) Set “MOTION” in main menu using Tele/Wide key. B) Select the “DETECTION” in submenu using Tele/Wide key. C) Set the mode ON, OFF using Focus key. 7-2. LEVEL ADJUST Set This function is available for DETECTION mode. A) Select the “LEVEL SET” in submenu using Tele/Wide key. B) Adjust the level from 0 to 21 using Focus key. 7-3. DAY/NIGHT Set This function is available for DETECTION mode. A) Select the “DAY/NIGHT” in submenu using Tele/Wide key.
F OSD DISP (Function On Screen Display) 8. F OSD DISP 8-1. FUNCTION Set A) Set “F OSD” in main menu using Tele/Wide key. B) Select the mode what you want in submenu using Tele/Wide key. C) Set the display mode of OSD ON, OFF using Tele/Wide, FOCUS key. *INITIAL SET and RETURN are the same as before procedure.
P MASKING (Privacy Masking) P MASKING AREA SEL MASKING P MODE SET MOVE PT SEL MOVE PT CNT PM SET END INI COLOR COLOR INITIAL SET RETURN NONE OFF OFF NONE 0 OFF I COLOR 1 COLOR 1 ON 9. P MASKING 9-1.AREA SEL This function is to selecting to privacy masking area. A) Set “P MASKING” in main menu using Tele/Wide key. B) Select the “AREA SEL” in submenu using Tele/Wide key. C) Select the area from area 1 to area 8 using Focus key. 9-2. Masking This function is available for MASKING mode.
P MASKING (Privacy Masking) P MASKING AREA SEL MASKING P MODE SET MOVE PT SEL MOVE PT CNT PM SET END INI COLOR COLOR INITIAL SET RETURN NONE OFF OFF NONE 0 OFF I COLOR 1 COLOR 1 ON 9-5. MOVE PT CNT This function is available to move selected point in the MOVE PT SEL. A) When MOVE PT SEL is selected ALL* : Available to move area. B) When MOVE PT SEL is selected LEFT* or RIGHT* : Change the size of the area 9-6. PM SET END Privacy Masking setting function is available to set OFF.
P MASKING (Privacy Masking) 9-9. INITIAL SET : P MASKING AREA SEL MASKING P MODE SET MOVE PT SEL MOVE PT CNT PM SET END INI COLOR COLOR INITIAL SET RETURN 32 NONE OFF OFF NONE 0 OFF I COLOR 1 COLOR 1 ON A) Select the “INITIAL SET” in submenu using Tele/Wide Command, B) Set the initial set mode to ON or OFF using Focus key. 9-10. RETURN TO MAIN MENU : This function is exit to main menu. A) Select the “RETURN “ in submenu using Tele/Wide key. B) Set the return mode using Focus key.
On Screen Display Some of these functions will be displayed every time the camera is operated and then disappeared after 5 seconds. 1 2 3 6 FUNCTION OSD Format 1. Focus Mode Non display Description Auto Mode Manual / push Auto Mode 2. Back Light 3. Shutter Speed Non display Back Light OFF “BL”display BLC ON / Auto BLC Mode Non display Normal Shutter (PAL: 1/50) “Ff”display Flickerless Mode 1/120 * 10 variable steps. 1/50,000 4.
On Screen Display FUNCTION OSD Format 6. WBC Mode Description White Balance AUTO WB Preset for INDOOR (3200°K) Wb Preset for OUTDOOR (5100°K) M W P W 7. ZOOM Display 34 Manual WB Adjustment: In manual mode the HUE control is available (0 ~ 255). Push Auto White Balance: Turn this mode ON, the white trace automatically. Turn this mode OFF, preserve the white of final auto tracing action (Manual).
Specifications Image device 1/4" EXVIEW HAD CCD NTSC, High resolution : 811(H) X 508(V) 410K Horizontal resolution PAL, High resolution : 795 (H) X 596 (V) 470K Approx. 520 TV Line. Lens X 27 Zoom (F 1.5 (W), F 3.8 (T) f= 3.25 ~ 88.0 mm), Video AF Digital Zoom Ratio X 2: Basic (OFF at WDR mode) X 12: Basic (LVC-C500, LVC-C510, LVC-C530) Minimum illumination Normal Mode : 1 Lux (F 1.5, Normal Shutter) (1/3 output) Electronic Shutter Speed Mode : 0.
Specifications Focal Length 3.24mm (WIDE), 86mm (TELE) OSD(On Screen Display) English Power requirement DC 12V Video output Composite Output 75Ω Terminated / Y,C Separated Power consumption 5.4W: LVC-C503, LVC-C513, LVC-C533, LVC-C553 5.1W: LVC-C500, LVC-C510, LVC-C530 operating temperature 0°C - 45°C Operating Humidity 0% RH - 60% RH Storage temperature -20°C - 60°C, 0% RH - 85% RH Dimensions 57mm(W) X 62.4mm(H) X 98.
ݷᔫᒎฉ LVC-C500 LVC-C503 LVC-C510 LVC-C513 LVC-C530 LVC-C533 LVC-C553 在您使用此摄像机之前,请完整阅读此操 作指南以供参考。
வস ቃቦ 电击危险请勿打开 ቃቦ : 为了减少电击的危险 请勿拆下前 盖 或后盖 内部没有任何用户可以维修 的零部件 如需维修 请联系专业维修人员 此符号用于警示用户,产品外壳存在 未绝缘的危险电压,会产生对人身造 成电击的危险。 为了防止电击事故,请不要将该产品暴露在雨中或潮湿的环境中。 为了避免电击的危险,请不要打开机壳,如需维修,请联系专业维 修人员。 接线方法应该符合美国国家电气规程 ANSI/NFPA 70 之规定 ਖࢾဉී U.S.
ดྏਜ਼ᄂ࢛ ഺ ᄂ࢛ ดྏਜ਼ᄂ࢛ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 ڔཝݷᔫᓖፀူሲ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 ݷᔫ఼ᒜૺถ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 ࢟Ꮞၒྜྷ / ఼ᒜ / ᅪݝ (A/D IN) . . . . . . . . . . . . . . . .6-14 ݩႁී . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 摄像机 ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 对焦模式设置 . . . . . . . . . . . . . . . . . . . . .
ڔཝݷᔫᓖፀူሲ ࢟Ꮞ 此摄像机必须始终使用 12V DC 电源 ۃᏥስ૦ 请注意不要将水或其它液体溅到摄像机内部 也不 要让可燃性物品或金属物品掉入摄像机内 如果摄 像机内部有杂质 则可能会导致摄像机故障或引发 火灾或电击 ဧਜ਼ࡀह࢛ 不要长时间观看过于明亮的物体 以下环境中使用或存放此设备 • • • • • 如灯具 避免在 过热或过冷的地方 工作温度 0°C-45°C) 潮湿或有灰尘的地方 有雨的地方 有强烈振动的地方 靠近有强电磁辐射的地方 如收音机或电视发射 机附近 4 ስ૦ۣዸ • 使用吹风机将表面的灰尘或脏物吹掉 • 请使用软布清洁机身 如果太脏 请使用带有少 量中性清洁剂的软布清洁 然后擦干 • 请不要使用挥发性溶剂 如稀释剂 酒精 苯和 杀虫剂 们会损坏表面或机身
ݷᔫ఼ᒜૺถ ቯ: LVC-C500, LVC-C503, LVC-C510, LVC-C513 1 2 1. ྯ୭ଦᓞ 此转接器还可以安装到摄像机的底部 2. ᄿڔᓤঙ 3. TELE 当按 TELE KEY 时 图像为远距拍摄 4. WIDE 当按 WIDE KEY 时 图像为广角拍摄 5. ౯தୡ௦ 在手动操作时 将焦距拉近 6. ౯Ꮠୡ௦ 在手动操作时 将焦距拉远 7. ݩ 如果您要设置不同的功能 8. ၁ຫၒ߲ 可按此键 S-Video ቯ 连接到监视器的 S-Video 输入接口 9. ስ૦఼ᒜ JACK ా 6 ᑣ DIN JACK ቯ • 连接到外部电压控制器 • 您可以通过此接口为摄像机供电 10.
࢟Ꮞၒྜྷ0఼ᒜ ቯ: LVC-C500, LVC-C503, LVC-C510, LVC-C513 您可以通过摄像机背面的针形端子调节焦距和变焦。 变焦 & 焦距 DC 控制 1 2 3 6 5 4 A/D KEY 1 输入 共地变焦 & 对焦 通用地 电源输入 12V * 为电缆颜色。(如果提供) 调节管脚 1 和管脚 2 的电压 6
ᅪݝ (A/D IN) ቯ: LVC-C500, LVC-C503, LVC-C510, LVC-C513 线控示意图 7
ݷᔫ఼ᒜૺถ ቯ: LVC-C530, LVC-C533 1. ྯ୭ଦᓞ 此转接器还可以安装到摄像机的底部 2. ᄿڔᓤঙ 3. TELE 1 2 当按 TELE KEY 时 图像为远距拍摄 4. WIDE 当按 WIDE KEY 时 图像为广角拍摄 5. ౯தୡ௦ 在手动操作时 将焦距拉近 6. ౯Ꮠୡ௦ 在手动操作时 将焦距拉远 7. ݩ 如果您要设置不同的功能 8. ၁ຫၒ߲ 可按此键 S-Video ቯ 连接到监视器的 S-Video 输入接口 9. ስ૦఼ᒜ JACK ా 12 ᑣ DIN JACK ቯ • 连接到外部电压控制器 • 您可以通过此接口为摄像机供电 10.
࢟Ꮞၒྜྷ0఼ᒜ ቯ: LVC-C530, LVC-C533 您可以通过摄像机背面的针形端子调节焦距和变焦。 用于 RS-232C 发送端口 用于 RS-232C 接收端口 变焦 & 焦距 DC 控制 通用地 遥控输入 用于运动检测脉冲输出 电源输入 12V A/D KEY 1 输入 A/D KEY 2 输入 A/D KEY 3 输入 * 为电缆颜色。(如果提供) 9
࢟Ꮞၒྜྷ0఼ᒜ ቯ: LVC-C530, LVC-C533 • RS232S ೌ • ܤୡ & ୡ௦ DC ఼ᒜೌ ၃Ꮔ / ఼ᒜ • ۨவၒ߲ Ꮵࣅଶހၒ߲ Ꮵࣅଶހ 10 ൴ߡᄟୈ
ᅪݝ (A/D IN) 线控示意图 ቯ: LVC-C530, LVC-C533 镜像 11
ݷᔫ఼ᒜૺถ 1. ྯ୭ଦᓞ ቯ: LVC-C553 此转接器还可以安装到摄像机的底部 2. ᄿڔᓤঙ 3. TELE 1 2 当按 TELE KEY 时 图像为远距拍摄 4. WIDE 当按 WIDE KEY 时 图像为广角拍摄 5. ݩ 如果您要设置不同的功能 可按此键 6. ఼ᒜ( ރRJ45) 连接 RS-422 接口 7. ౯Ꮠୡ௦ 在手动操作时 将焦距拉远 在手动操作时 将焦距拉近 8. ౯தୡ௦ 9. DC 12V ൛ႋ࣡ᔇ 连接到 DC 12V 外部电源 10. ེ 使用此键切换白天 & 黑夜模式 11.
ೌ ቯ: LVC-C553 1 ࢟Ꮞೌ 2 3 1. 如图所示去掉电源线外面的绝缘层 2. 装上端子头 3. 连接 12V DC UL Listed Class 2 电源到摄像机 ೌପ၁ 1 2 1. 到 VIDEO OUT 2.
఼ᒜ ቯ: LVC-C553 遥控线连接到下面的 RJ-45 插孔 对于 RS-485 接口 基本 T+ T- CONTROL 7 T- 8 T+ RR+ 控制器 控制输出 对于变焦/对焦 DC 控制接口 可选 4 5 PIN 8 PIN 1 6 接收器/控制器 电压范围 14 + Vcom + (+5~15V) - Vcom - (+5~15V)
ݩႁී ဧ TELE WIDE F. NEAR F.
ስ૦ ID 1.
࣪ୡෝါᒙ 2. ࣪ୡᒙǖ 2-1. ࣪ୡෝါᒙ ࠥถ᎖ᒙ࣪ୡෝါ A)使用 Tele/Wide 键在主菜单中设置 FOCUS SET 使用 Tele/Wide 键选择子菜单中的 FOCUS MODE 然后 使用对焦键设置模式 Auto(自动) Push auto(强制自动) Manual (手动)) 2-2. ࣪ୡ௦ಭᒙ ࠥถ᎖ኡᐋᔢቃ௦ಭ A) 使用 Tele/Wide 键选择子菜单中的 FOCUS DIST B) 使用对焦键在 1cm 到 5M 之间设置对焦距离模式 (1cm, 10cm, 50cm, 1M, 3M, 5M) 2-3.
࣪ୡෝါᒙ 2-4. ܤୡஉၦᒙ ࠥถ᎖ኡᐋܤୡஉၦᆡᒙă A) 使用 Tele/Wide 键选择子菜单中的 ZOOM END B) 使用对焦键设置变焦结束模式 LVC-C503/C513/C533/C553:从 变焦开始 + 1 到 X54 LVC-C500/C510:从 变焦开始 + 1 到 X324 2-5. ܤୡႥࣞᒙ ࠥถ᎖ኡᐋܤୡႥࣞă A) 使用 Tele/Wide 键选择子菜单中的 ZOOM SPEED B) 使用对焦键设置变焦速度 Slow 低 Middle 中 2-6.
࣪ୡෝါᒙ 2-7. ߱ဪᒙ ྙਫ߱ဪෝါᆐ ON ఎ ถۻখޣ߲ࡵܤᒙ Ⴥᎌ FOCUS SET ࣪ୡᒙ A) 使用 Tele/Wide 键选择子菜单中的 ININTIAL SET B) 使用对焦键将初始模式设为 ON 或 OFF 2-8.
AWB ᒙ ᔈࣅڹຳੰ 3. ᔈࣅڹຳੰᒙ 3-1. ڹຳੰෝါᒙ ࠥถ᎖ኀখڹຳੰෝါ AWB WBC MODE RED ADJUST BLUE ADJUST INITIAL SET RETURN AUTO NOT USE NOT USE ON A) 使用 Tele/Wide 键在主菜单中设置 AWB SET B) 使用 Tele/Wide 键选择子菜单中的 WB MODE C) 使用对焦键设置模式 Auto(自动) Push auto(强制自动) Manual(手动) Outdoor(室外) Indoor(室内) *WBC MODE: ᎖ኀখڹຳੰෝါ 1) AUTO 白平衡范围 2500 °K ~ 9500 °K 2) PUSH AUTO 将 AWB 模式设为 Push Auto 强制自动 平衡模式会自动调整 3-2.
AWB ᒙ ᔈࣅڹຳੰ 3-3. ౸ྻࢯᑳᒙ ࠥถ᎖ Manual WB ၄ࣅڹຳੰ ࠥෝါဵ࣪ᄂၐዕྻઓኡሲࡼࢯᑳ AWB WBC MODE RED ADJUST BLUE ADJUST INITIAL SET RETURN AUTO NOT USE NOT USE ON ෝါ A) 使用 Tele/Wide 键选择子菜单中的 BLUE ADJUST B) 使用对焦键调节值大小 0-255 MANUAL 3-4. PUSH AUTO ༓ᒜᔈࣅ Ᏼ PUSH AUTO WB ෝါሆ ༓ᒜᔈࣅෝါᆐ ON WB ્ᔈࣅᒊቲ 3-5. ߱ဪᒙ ྙਫ߱ဪෝါᆐ ON ఎ Ⴥᎌ AWB ᔈࣅڹຳੰ ถۻখޣ߲ࡵܤᒙ A) 使用 Tele/Wide 键选择子菜单中的 ININTIAL SET B) 使用对焦键将初始模式设为 ON 或 OFF 3-6.
AE ᒙ ᔈࣅ໎ 4. ᔈࣅੰᒙ 4-1. ᔈࣅੰෝါᒙ ࠥถ᎖ኀখᔈࣅੰෝါă A) 使用 Tele/Wide 键在主菜单中设置 AE SET B) 使用 Tele/Wide 键选择子菜单中的 AE MODE C) 使用对焦键设置模式为 IRIS MAN SLOW MAN SHUTTER MAN 注意 SLOW MAN 选项不适用于 LVC-C500 LVC-C510 和 LVC-C530 4-2. མࢯᑳᒙ ࠥถ᎖ IRIS MAN ෝါ A) 使用 Tele/Wide 键选择子菜单中的 IRIS ADJUST B) 使用对焦键在 0 到 255 中调整设置 4-3.
AE ᒙ ᔈࣅ໎ 4-4. ೡࣞࢯᑳᒙ ࠥถ᎖ AUTO (ᔈࣅ) ෝါ A) 使用 Tele/Wide 键选择子菜单中的 BRIGHTNESS B) 使用对焦键在 0 到 255 中调整设置 4-5. ۳ᒙ 注意 WDR 选项不适用于 LVCC500 LVC-C510 和 LVC-C530 Area1 Area2 Area0 Area3 A) 使用 Tele/Wide 键选择子菜单中的 BACKLIGHT B) 使用对焦键设置模式为 OFF ON 或 ATUO, WDR * WDR 宽动态范围 用来捕捉高亮度或低亮度物体 * ᔈࣅ BLC ᔈࣅ۳ޡݗ W当区域 1 区域 2 区域 3 或区域 4 中的背光满足条件时 可使用背光补偿 当此区域中的背光条件消失时 BLC 自动 停用 如果不需要此模式 将其设为 OFF 4-6.
AE ᒙ ᔈࣅ໎ 4-7. ᇄ࿑ႄᒙ ࠥถ᎖ AUTO (ᔈࣅ) ෝါ A) 使用 Tele/Wide 键选择子菜单中的 FLICKERLESS B) 使用对焦键设置模式为 OFF ON * FLICKERLESS ᇄ࿑ႄ ᎖ሿ߹ᅄስ࿑ႄ ON 开 去除闪烁 对于 PAL 制式 快门速度 1/120 秒 4-8. ඡႥࣞᒙ ࠥถ᎖ AUTO ෝါ / SHUTTER ෝါ A) 使用 Tele/Wide 键选择子菜单中的 SHUTTER B) • 使用对焦键设置模式为 NORMAL, 1/120 - 1/50000 • 使用对焦键设置模式为 NORMAL, 1/125 - 1/50000 4-9. ߱ဪᒙ A) 使用 Tele/Wide 键选择子菜单中的 ININTIAL SET B) 使用对焦键将初始模式设为 ON 或 OFF 4-10.
AE ܰ ᔈࣅ໎ 5-1. ۳ܰޡݗᒙ ࠥถ᎖ኀখ BLC LEVEL A) 使用 Tele/Wide 键选择子菜单中的 B) 使用对焦键在 0 到 255 之间设置 BLC LEVEL 5-2. ࣅზपᆍܰᒙ ࠥถ᎖ኀখ WDR LEVEL A) 使用 Tele/Wide 键选择子菜单中的 B) 使用对焦键在 0 到 15 之间设置 WDR LEVEL 5-3. ߱ဪᒙ A) 使用 Tele/Wide 键选择子菜单中的 INITIAL SET B) 使用对焦键将初始模式设为 ON 或 OFF 5-4.
ᄂၐᒙ 6. ᄂၐᒙ 6-1. ઓܪᄌᒙ ࠥถ᎖Ᏼືᒦመာᔈࢾፃܪᄌ A) 使用 Tele/Wide 键在主菜单中设置 SPECIAL SET B) 使用 Tele/Wide 键选择子菜单中的 USER TITLE C) 使用 Tele / Wide 和对焦键设置标题位置和数据 6-2. ༹ᇠࣞࢯᑳᒙ A) 使用 Tele/Wide 键选择子菜单中的 SHARPNESS B) 使用对焦键在 0 到 225 之间设置 6-3. ዕྻᒙ ࠥෝါ᎖੨ڹෝါ A) 使用 Tele/Wide 键选择子菜单中的 COLOR B) 使用对焦键设置模式为 ON OFF 6-4.
ᄂၐᒙ 6-5. D ਫᒙ ᄰਭࠥถਦࣅጲመာሤਈถ A) 使用 Tele/Wide 键选择子菜单中的 D EFFECT B) 使用对焦键设置 mode none mirror v-flip rotation 6-6. ߱ဪᒙ ྙਫ߱ဪෝါᆐ ON ఎ ถۻখޣ߲ࡵܤᒙ Ⴥᎌ SPECIAL ᄂၐ A) 使用 Tele/Wide 键选择子菜单中的 ININTIAL SET B) 使用对焦键将初始模式设为 ON 或 OFF 6-7.
Ꮵࣅଶހ 7. Ꮵࣅଶހᒙ 7-1. ଶހෝါᒙ A) 使用 Tele/Wide 键在主菜单中设置 MOTION B) 使用 Tele/Wide 键选择子菜单中的 DETECTION C) 使用对焦键设置模式为 ON OFF 7-2. ܰࢯᑳᒙ ࠥถ᎖ DETECTION ON ෝါ A) 使用 Tele/Wide 键选择子菜单中的 B) 使用对焦键在 0 到 21 之间设置 LEVEL SET 7-3.ڹᄖ/ᅵᒙ ࠥถ᎖ DETECTION ෝါ A) 使用 Tele/Wide 键选择子菜单中的 DAY/NIGHT B) 使用对焦键选择一种模式 (AUTO, DAY, NIGHT) 注意 在 LVC-C500/C503 型号中 此功能固定为 DAY 7-4. ߱ဪᒙ ྙਫ߱ဪෝါᆐ ON ఎ ۻখޣ߲ࡵܤᒙ Ⴥᎌ MOTION Ꮵࣅ A) 使用 Tele/Wide 键选择子菜单中的 ININTIAL SET B) 使用对焦键将初始模式设为 ON 或 OFF 7-5.
F OSD መာ ືመာถ 8. F OSD መာ 8-1.
P MASKING ۣමዚঙ P MASKING AREA SEL MASKING P MODE SET MOVE PT SEL MOVE PT CNT PM SET END INI COLOR COLOR INITIAL SET RETURN NONE OFF OFF NONE 0 OFF I COLOR 1 COLOR 1 ON 9. ۣමዚঙ 9-1.ཌᎮኡᐋ 此功能用于选择保密掩盖区域 A) 使用 Tele/Wide 键在主菜单中设置 P MASKING B) 使用 Tele/Wide 键选择子菜单中的 AREA SEL C) 使用对焦键在区域 1 到区域 8 中选择区域 9-2. ዚঙ 此功能用于 MASKING 模式 A) 使用 Tele/Wide 键选择子菜单中的 MASKING B) 使用对焦键设置模式为 ON OFF 9-3. ۣමෝါᒙ 此功能可转到 PRIVACY MASKING SETTING 盖设置 模式 保密掩 A) 使用 Tele/Wide 键选择子菜单中的 P MODE SET B) 如果 PM SET END 模式转为 ON 此菜单自动转为 OFF 9-4.
P MASKING ۣමዚঙ P MASKING AREA SEL MASKING P MODE SET MOVE PT SEL MOVE PT CNT PM SET END INI COLOR COLOR INITIAL SET RETURN NONE OFF OFF NONE 0 OFF I COLOR 1 COLOR 1 ON 9-5. MOVE PT CNT 此功能可移动 MOVE PT SEL 中的选定点 A) 当 MOVE PT SEL 选择为 ALL* 时 可移动区域 B) 当 MOVE PT SEL 选择为 LEFT* 或 RIGHT* 时 改变区域 大小 9-6. ۣමዚঙᒙஉၦ 保密掩盖设置功能可设为 OFF A) 使用 Tele/Wide 键选择子菜单中的 PM SET END B) 如果 PM SET END 模式转为 ON 则 P MODE SET 自动 转为 OFF 9-7. ߱ဪዕྻ 此功能用于选择初始掩盖的颜色 A) 使用 Tele/Wide 键选择子菜单中的 INI COLOR B) 使用对焦键从颜色 1 到颜色 8 中选择模式 9-8.
P MASKING ۣමዚঙ 9-9. ߱ဪᒙ : P MASKING AREA SEL MASKING P MODE SET MOVE PT SEL MOVE PT CNT PM SET END INI COLOR COLOR INITIAL SET RETURN 32 NONE OFF OFF NONE 0 OFF I COLOR 1 COLOR 1 ON A) 使用 Tele/Wide 键选择子菜单中的 INITIAL SET B) 使用对焦键将初始模式设为 ON 或 OFF 9-10.
ືݩመာ (OSD) 以下某些功能在操作摄像机时 会在屏幕上显示 5 秒钟后消 失 ถ OSD ৃါ ႁී 1. 对焦模式 无显示 自动模式 ☞ 2. 背光 1 2 3 6 3. 快门速度 手动 / 强制自动模式 无显示 背光关闭 “BL”显示 背光补偿开 / 自动背光补偿模式 无显示 普通快门 (PAL: 1/50) “Ff”显示 无闪烁模式 1/120 * 10 步 1/50,000 5 7 4 4. 待机 在电源打开过程中摄像机处于待机状态 5.
ືݩመာ (OSD) ถ OSD ৃါ 6. 白平衡控 ႁී 自动白平衡 制模式 室内白平衡预设 (3200°K) 室外白平衡预设 (5100°K) 7.
ਖৃ ߅ስ۸ 1/4" EXVIEW HAD CCD NTSC, 高分辨率 : 811(H) X 508(V) 410K ၺຳॊܦൈ 大约 .520 TV Line PAL, 高分辨率 : 795 (H) X 596 (V) 470K ᄿ X 27 变焦 (F 1.5 (W), F 3.8 (T) f= 3.25 ~ 88.0 mm), Video AF ၫ൩ܤୡ X 2: 基本 (WDR 模式下 OFF) X 12: 基本 (LVC-C500, LVC-C510, LVC-C530) ᔢቃᑍී 普通模式 : 1 Lux (F 1.5, 普通快门) (1/3 ၒ߲) 电子快门速度模式 : 0.01 Lux (X20 场积累) ቧᐅ܈ 大于 48dB ྸහᇹᄻ ྸහຫൈ (H) ྸහຫൈ (V) ۣමཌᎮ 2:1 隔行 白天模式 : 0 Lux (红外开) 15.734 kHz (NTSC), 15.
ਖৃ ୡ௦ 3.24mm (广角), 86mm (远景) ືݩመာ (OSD) 英语 ࢟Ꮞገཇ DC 12V ၁ຫၒ߲ 复合输出75Ω 电阻 / Y,C 独立 5.4W: LVC-C503, LVC-C513, LVC-C533, LVC-C553 5.1W: LVC-C500, LVC-C510, LVC-C530 ᔫᆨࣞ 0°C - 45°C ᔫဘࣞ 0% RH - 60% RH ࡀᆨࣞ -20°C - 60°C, 0% RH - 85% RH ߛࡁ 57mm(W) X 62.4mm(H) X 98.
