ENGLISH OWNER’S MANUAL LED LCD TV Please read this manual carefully before operating the your TV and retain it for future reference. LED LCD TV MODEL M2255D M2755D www.lg.
TABLE OF CONTENTS TABLE OF CONTENTS ENGLISH 3 LICENSES 33 REMOTE CONTROL 4 INSTALLATION PROCEDURE 35 CUSTOMIZING SETTINGS 35 Accessing main menus 36 USING THE USER GUIDE 36 36 36 Accessing User Guide menu.
LICENSES 3 LICENSES Manufactured under license from Dolby Laboratories. “Dolby “and the double-D symbol are trademarks of Dolby Laboratories. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.
INSTALLATION PROCEDURE INSTALLATION PROCEDURE ENGLISH 1 Open the package and make sure all the accessories are included. 2 Attach the stand to the TV. 3 Connect an external device to the TV. NOTE Image shown may differ from your TV. yy Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. yy The available menus and options may differ from the input source or product model that you are yy using. New features may be added to this TV in the future.
ASSEMBLING AND PREPARING 5 ASSEMBLING AND PREPARING ENGLISH Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. NOTE The accessories supplied with your product may vary depending on the model.
ASSEMBLING AND PREPARING M2255D M2755D ENGLISH Remote control. Batteries (AAA). CD (Owner's Manual). Cards. (See p.33, See p.34) RGB Cable. (See p.32) Power Cord. AC-DC Adapter. Cable Tie. (See p.13) (See p.13) (See p.14) Stand Base. - M2255D: See p.9, See p. 15 - M2755D: See p.11, See p. 16 Stand Body. (Only M2255D model) Stand Body. (Only M2755D model) (See p.9, See p.15) (See p.11, See p.16) Screws for Assembly. 2 EA (Only M2755D model) (See p.11, See p.
ASSEMBLING AND PREPARING 7 Parts and buttons ENGLISH Remote Control Sensor Standby Light yyLighting On: Turned off yyLighting Off: Turned on Touch Buttons Connection panel (See p.21) Touch button Description Scrolls through the saved programmes. Adjusts the volume level. OK Selects the highlighted menu option or confirms an input. SETTINGS Accesses the main menus, or saves your input and exits the menus. INPUT Changes the input source. /I Turns the power on or off.
ASSEMBLING AND PREPARING Lifting and moving the TV ENGLISH When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for save transportation regardless of its type and size. When holding the TV, the screen should face yy away from you to prevent the screen from scratches. CAUTION Avoid touching the screen at all times, as this may result in damage to the screen or some of the pixels used to create images.
ASSEMBLING AND PREPARING Setting up the TV 3 Attach the Stand Base from the Stand Body by Attaching the Stand If you are not mounting the TV to a wall, use the following instructions to attach the stand. 1 Place the TV with the screen side down on a flat and cushioned surface. CAUTION Lay a foam mat or soft protective cloth yy on the surface to protect the screen from damage.
ASSEMBLING AND PREPARING CAUTION ENGLISH Do not carry the monitor upside-down yy as this may cause it to fall off its stand, resulting in damage or injury. The illustration shows a general example yy of installation and may look different from the actual product. Do not carry the monitor upside-down by yy holding the stand body as this may cause it to fall off, resulting in damage or injury. The illustration shows a general example yy of installation and may look different from the actual product.
ASSEMBLING AND PREPARING 11 3 Secure the TV and the Stand Body with the M2755D If you are not mounting the TV to a wall, use the following instructions to attach the stand. 1 Place the TV with the screen side down on a flat and cushioned surface. WARNING If you don`t fasten the screw tightly, TV will fall down and get damaged. 4 Attach the Stand Base from the Stand Body by 2 Attach the Stand Body from the TV. turning the screw to the right with a Coin.
ASSEMBLING AND PREPARING CAUTION ENGLISH Do not carry the monitor upside-down yy as this may cause it to fall off its stand, resulting in damage or injury. The illustration shows a general example yy of installation and may look different from the actual product. Do not carry the monitor upside-down by yy holding the stand body as this may cause it to fall off, resulting in damage or injury. The illustration shows a general example yy of installation and may look different from the actual product.
ASSEMBLING AND PREPARING Mounting on a table 13 WARNING table. Leave a 10 cm (4 inches) (minimum) space from the wall for proper ventilation. When you adjust the angle, do not hold the buttom of the TV frame as shown on the following illustration, as may injure your fingers. 10 cm 10 cm 10 cm 10 cm CAUTION Disconnect the power cord first, and then move or install the TV. Otherwise electric shock may occur. 2 Connect the AC-DC Adapter and Power Cord to a wall outlet.
ASSEMBLING AND PREPARING Using the Kensington security system NOTE ENGLISH Tilt from +20 to -5 degrees up or down to adjust the angle of the TV to suit your view. -5 +20 The Kensington security system connector is located at the back of the TV. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com . Connect the Kensington security system cable between the TV and a table.
ASSEMBLING AND PREPARING Detaching the Stand 1 Place the TV with the screen side down on a flat and cushioned surface. CAUTION Lay a foam mat or soft protective cloth yy on the surface to protect the screen from damage. When detaching the stand to the TV, yy place the screen facing down on a cushioned table or flat surface to protect the screen from scratches. 2 Turn the screw to the left, and then pull out the Stand Base from the Stand Body. 3 Pull out the Stand Body from the TV.
ASSEMBLING AND PREPARING M2755D ENGLISH 1 Place the TV with the screen side down on a flat and cushioned surface. CAUTION Lay a foam mat or soft protective cloth yy on the surface to protect the screen from damage. When detaching the stand to the TV, yy place the screen facing down on a cushioned table or flat surface to protect the screen from scratches. 2 Turn the screw to the left, and then pull out the Stand Base from the Stand Body. 3 Remove 2 screws and pull out the Stand Body from the TV.
ASSEMBLING AND PREPARING Mounting on a wall 17 5 Please use VESA standard as below. VESA (A x B) Standard screw Number of screws Wall mount bracket (optional) 10 cm 10 cm 784.8 mm (30.9 inch) and under yy * Wall Mount Pad Thickness : 2.6 mm * Screw : Φ 4.0 mm x Pitch 0.7 mm x Length 10 mm 787.4 mm (31.0 inch) and above yy * Please use VESA standard wall mount pad and screws.
ASSEMBLING AND PREPARING CAUTION ENGLISH Disconnect the power cord first, and then yy move or install the TV. Otherwise electric shock may occur. If you install the TV on a ceiling or slanted yy wall, it may fall and result in severe injury. Use an authorized LG wall mount and yy contact the local dealer or qualified personnel. Do not over tighten the screws as this may yy cause damage to the TV and void your warranty. Use the screws and wall mounts that meet yy the VESA standard.
WATCHING TV 19 WATCHING TV When you access the TV for the first time, the initial setting screen appears. Select a language and customize the basic settings. 1 Connect the power cord to a power outlet. 2 Press on the TV or power button on the remote control to turn the TV on. The Standby Light is turned off. NOTE When the TV is in Power saving mode, the Standby Light turns amber. 3 The initial setting screen appears if you access the TV for the first time.
WATCHING TV NOTE ENGLISH For those countries without confirmed DTV broadcasting standards, some DTV features might not yy work, depending on the DTV broadcasting environment. When France is selected for Country, the initial password is not ‘0’, ‘0’, ‘0’, ‘0’ but ‘1’, ‘2’, ‘3’, ‘4’. yy To display images in the best quality for your home environment, select Home Use mode. yy Store Demo mode is suitable for the retail environment.
MAKING CONNECTIONS 21 MAKING CONNECTIONS NOTE If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input yy cable to the TV through a DVD recorder or VCR. For more information about recording, refer to the manual supplied with the connected device. The external device connection may differ from the model. yy Connect external devices to the TV regardless of the order of the TV port.
MAKING CONNECTIONS Connecting to a HD receiver, DVD, VCR player or Gaming device ENGLISH Connect a HD receiver, DVD, VCR player or Gaming device to the TV and select an appropriate input mode. HDMI connection HDMI is the best way to connect a device. Transmits the digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown on the following illustration. NOTE Use a High Speed HDMI™ Cable.
MAKING CONNECTIONS 23 HDMI to DVI connection NOTE If you do not use an optional external speaker, connect the external device to the TV with the optional audio cable. (Not Provided) (Not Provided) DVD / Blu-Ray / HD Cable Box / HD STB / Gaming device ENGLISH Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the HDMI to DVI cable as shown in the following illustration. To transmit an audio signal, connect an optional audio cable.
MAKING CONNECTIONS Component connection ENGLISH Transmits the analog video and audio signals from an external device to the TV. Connect the external device and the TV with the component cable as shown on the following illustration. To display images by using progressive scan, make sure to use the component cable. NOTE If cables are installed incorrectly, it could case the image to display in black and white or with distorted yy color.
MAKING CONNECTIONS 25 Composite connection NOTE Check to ensure the cable are matched with the corresponding color connection. (Not Provided) DVD / Blu-Ray / HD Cable Box / HD STB / Gaming device ENGLISH Transmits the analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown on the following illustration.
MAKING CONNECTIONS Euro Scart connection ENGLISH Transmits the video and audio signals from an external device to the TV. Connect the external device and the TV with the Euro Scart cable as shown on the following illustration. To display images by using progressive scan, make sure to use the Euro Scart cable. Output Type AV1 (TV Out1) Current input mode AV1 (When DTV scheduled recording is in progress using recording equipment.
MAKING CONNECTIONS 27 Connecting to an audio system ENGLISH Use an optional external audio system instead of the built-in speaker. Headphone connection Transmits the headphone signal from the TV to an external device. Connect the TV with the headphone as shown on the following illustration. NOTE AUDIO menu items are disabled when connecting a headphone. yy When changing AV MODE with a headphone connected, the change is applied to video but not to yy audio.
MAKING CONNECTIONS Connecting to a USB ENGLISH Connect a USB storage device such as s USB flash memory, external hard drive, MP3 player or a USB memory card reader to the TV and access the USB menu to use various multimedia files. or USB (Not Provided) Connecting to a CI Module View the encrypted (pay) services in digital TV mode. This feature is not available in all countries. NOTE Check if the CI module is inserted into the PCMCIA card slot in the right direction.
MAKING CONNECTIONS 29 Connecting to a PC * Plug & Play: The function when a PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention. NOTE It is recommended to use the TV with the HDMI connection for the best image quality. yy If you do not use an optional external speaker, connect the PC to the TV with the optional audio yy cable. If you turn the TV on when the set becomes cold, the screen may flicker. This is normal.
MAKING CONNECTIONS HDMI connection ENGLISH Transmits the digital video and audio signals from your PC to the TV. Connect the PC and the TV with the HDMI cable as shown in the following illustrations. You should set PC as an input label to connect the PC to the TV with an HDMI connection. NOTE Use a High Speed HDMI™ Cable. yy High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher. yy If you want to use HDMI-PC mode, you must set the input label to PC mode.
MAKING CONNECTIONS 31 HDMI to DVI connection NOTE If you want to use HDMI-PC mode, you must set the input label to PC or DVI mode. yy If you do not use an optional external speaker, connect the PC to the TV with the optional audio cable. yy (Not Provided) (Not Provided) PC ENGLISH Transmits the digital video signal from your PC to the TV. Connect the PC and the TV with the HDMI to DVI cable as shown the following illustrations. To transmit an audio signal, connect an optional audio cable.
MAKING CONNECTIONS RGB connection ENGLISH Transmits the analog video signal from your PC to the TV. Connect the PC and the TV with the D-sub 15 pin cable as shown the following illustrations. To transmit an audio signal, connect an optional audio cable. NOTE If you do not use an optional external speaker, connect the PC to the TV with the optional audio cable.
REMOTE CONTROL 33 REMOTE CONTROL M2755D The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse. CAUTION Do not mix old and new batteries, as this may damage the remote control.
REMOTE CONTROL ENGLISH FAV Displays the selected favourite programme. AD Switches the Audio Description On or Off. PIP Turns the PIP mode on or off. (VOLUME) Adjusts the volume level. Coloured buttons These buttons are used for teletext (on TELETEXT models only), Programme edit. USB Menu control buttons USB menu(Photo List and Music List or Movie List). Programme Selects a programme. PAGE Moves to the previous or next screen. MUTE Mutes all sounds.
CUSTOMIZING SETTINGS 35 CUSTOMIZING SETTINGS ENGLISH Accessing main menus 1 Press SETTINGS to access the main menus. 2 Press the Navigation buttons to scroll to one of the following menus and press OK. 3 Press the Navigation buttons to scroll to the setting or option you want and press OK. 4 When you are finished, press EXIT. (BACK). When you return to the previous menu, press PICTURE Adjusts the image size, quality or effect. AUDIO Adjusts the sound quality, effect or volume level.
USING THE USER GUIDE ENGLISH USING THE USER GUIDE Accessing User Guide menu. Using the TV menu Image shown may differ from your TV. yy User Guide 3 2 To use input device 1 Press SETTINGS to access the main menus. 2 Press the RED button to access the Customer Support menus. 3 Press the Navigation button to scroll to User To use Energy Saving feature PROGRAMME Setting option you want and press OK. 5 When you are finished, press EXIT. When you return to the previous menu, press (BACK).
MAINTENANCE 37 MAINTENANCE Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. yy When the TV is left unattended and unused for a long time, disconnect the power cord from the wall yy outlet to prevent possible damage from lightning or power surges. Screen and frame To remove dust, wipe the surface with a dry and soft cloth.
MAINTENANCE Preventing “Image burn” or “Burn-in” on your TV screen ENGLISH If a fixed image displays on the TV screen for a long period of time, it will be imprinted and become yy a permanent disfigurement on the screen. This is “image burn” or “burn-in” and not covered by the warranty. If the aspect ratio of the TV is set to 4:3 for a long period of time, image burn may occur on the yy letterboxed area of the screen.
TROUBLESHOOTING 39 TROUBLESHOOTING ENGLISH General Problem Resolution Cannot control the TV with the remote control. yy Check the remote control sensor on the product and try again. yy Check if there is any obstacle between the product and the remote control. yy Check if the batteries are still working and properly installed ( to , to ). No image display and no sound is produced. yy Check if the product is turned on. yy Check if the power cord is connected to a wall outlet.
SPECIFICATIONS SPECIFICATIONS ENGLISH M2255D Panel Video Signal Screen Type 546.1 mm Wide (21.5 inch) Visible diagonal size : 546.1 mm Pixel Pitch 0.25 mm (H) x 0.25 mm (V) Max.
SPECIFICATIONS ENGLISH M2755D Panel Video Signal Screen Type 685.65 mm Wide (27 inch) Visible diagonal size : 685.65 mm Pixel Pitch 0.31 mm (H) x 0.31 mm (V) Max.
SPECIFICATIONS RGB (PC) / HDMI (PC) supported mode Component supported mode ENGLISH Resolution Horizontal Frequency(kHz) Vertical Frequency(Hz) Resolution Horizontal Frequency(kHz) Vertical Frequency(Hz) 720 x 400 31.468 70.080 720 x 480 15.730 59.940 640 x 480 31.469 59.940 720 x 480 15.750 60.000 640 x 480 37.500 75.000 720 x 576 15.625 50.000 800 x 600 37.879 60.317 720 x 480 31.470 59.940 800 x 600 46.875 75.000 720 x 480 31.500 60.000 1024 x 768 48.363 60.
SPECIFICATIONS 43 NOTE ENGLISH Avoid keeping a fixed image on the set’s screen for prolonged periods of time. The fixed image may yy become permanently imprinted on the screen. Use a screen saver when possible. There may be interference relating to resolution, vertical pattern, contrast or brightness in PC mode. yy Change the PC mode to another resolution or change the refresh rate to another rate or adjust the brightness and contrast on the menu until the picture is clear.
UK Only
Make sure to read the Safety Precautions before using the product. Keep the Owner’s Manual (CD) in an accessible place for future reference. The model and serial number of the TV is located on the back and one side of the TV. Record it below should you ever need service. MODEL SERIAL To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http:// opensource.lge.com.
