LG EASY GUIDE NOTEBOOK 14T90P Series www.lg.com Copyright © 2020 LG Electronics Inc. All rights reserved.
Introduction / Important Safety Precautions Introduction / Important Safety Precautions ENGLISH Using LG Easy Guide, LG TroubleShooting LG Electronics Inc. provides LG Easy Guide (User's Guide) and LG TroubleShooting (TroubleShooting Guide) to users for their easy and convenient use of the product. • Press [ ], select [LG Software], and run [LG Easy Guide] or [LG TroubleShooting].
Introduction / Important Safety Precautions 3 Information/Precautions Before Using • This LG Easy Guide has been written for the Windows 10 operating system. • The screen and menu configurations may differ from this manual depending on the status of the Windows and software update. • Representative images are used in LG Easy Guide. Product purchased may differ in appearance and color. • LG Easy Guide includes instruction about optional products.
Introduction / Important Safety Precautions ENGLISH TIP Indicates that the following information is added to help the user utilize the machine more conveniently. OPTION The Option symbol indicates that the concerned device is not included in the product package and thus has to be purchased separately, or the device may not be applied to the user's machine depending on model type. Manufacturer and Copyright Microsoft™, MS™, WinPE™, and Windows® are the registered trademarks of Microsoft Corporation™.
Introduction / Important Safety Precautions 5 The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. LG Easy Guide may contain undetectable errors despite our dedicated efforts to provide users with reliable information. We ask for your understanding. The illustrated figures in LG Easy Guide may differ in appearance with the actual products.
Introduction / Important Safety Precautions Information on Hard Drive / Memory Capacity ENGLISH Information on Hard Drive (HDD, SSD, eMMC) Capacity The hard drive capacity shown by Windows is lower than that stated by the hard drive manufacturer due to a difference in calculation. Manufacturer Hard drive manufacturers use a decimal definition of 1 KB = 1,000 Bytes.
Introduction / Important Safety Precautions 7 Important Safety Precautions The warranty does not cover any damage resulting from reckless use or use in undesirable environments. ENGLISH Please use the machine in the proper environment to extend the machine's lifespan. Use the machine in a safe and stable place.
Introduction / Important Safety Precautions Product Installation/Usage Precautions ENGLISH CAUTION Place the machine in a safe place so it does not fall. • If dropped, the machine may be damaged or cause an injury. Use the product in a clean, dust-free environment. • Otherwise, the system may not function properly. Do not place any objects within 15 cm of the PC. • Lack of ventilation may overheat the PC from inside and put users at risk of burn injuries.
Introduction / Important Safety Precautions 9 Ensure the power is off before shutting the LCD. Do not impose excessive force on the LCD screen or drop it. • You may break the LCD glass panel. Do not lean the LCD screen backward too much. Do not apply too much force to the LCD screen. • The LCD screen or the moving parts may be damaged. To clean the LCD screen, use designated agents and soft cloth and rub the screen in one direction. • Too much force may damage the LCD screen.
Introduction / Important Safety Precautions Turn off the PC if you are not going to use it for an extended period of time. ENGLISH • It may overheat the battery. Make sure that the memory cover is securely closed before turning on the PC. • Do not use the machine when the memory cover is open. It may damage the machine. Please use parts certified by LG Electronics Inc. • Otherwise, a fire or product damage may occur. If there is a problem with peripheral devices, contact the device manufacturer.
Introduction / Important Safety Precautions 11 WARNING • The desiccating agent and plastic wrap may cause suffocation. Do not use the machine in damp places like a laundry room or bathroom. • Moisture may cause a glitch or electric shock. • Please use the machine within the appropriate temperature range (10 °C to 35 °C) and humidity range (20 % RH to 80 % RH). Clean the PC with a proper agent and dry it completely before using it again. • If the PC is wet while used, an electric shock or fire may occur.
Introduction / Important Safety Precautions Do not put your finger or an object into PC ports. ENGLISH • An injury or electric shock may occur. Ask one of our engineers to run a safety check after your computer has been repaired. • Otherwise, an electric shock or fire may occur. For minors, we recommend a program that blocks access to illegal or pornographic web sites. • Minors' exposure to adult-only contents may inflict psychological instability or even trauma.
Introduction / Important Safety Precautions 13 If you dissemble the PC, connect the power after reassembly is done. Do not put in metal items such as coins, hair pin or other irons or inflammables such as paper or matches. Especially, ensure that children will not do so. • There is a risk of product damage, fire, or electric shock. • If any foreign substance gets in the product, unplug the product and contact the local service center.
Introduction / Important Safety Precautions WARNING ENGLISH During air travel, follow the directions of flight attendants. • Using the PC during flight may cause an aircraft accident. When leaving the machine in a car, avoid exposure to direct sunlight. • The product may get deformed or catch on fire due to a temperature rise. Do not put any heavy object on the power cable and AC adapter, and avoid damage from impacts. • A malfunction or fire may occur.
Introduction / Important Safety Precautions 15 Battery and AC Adapter Precautions When the PC is not used for an extended period of time, keep the battery level at about 50 %. • Do not leave the product with discharged battery for an extended period of time. It may damage the battery. Charge the battery only with the provided instrument. • Otherwise, the battery may be damaged presenting a risk of fire. Do not throw or disassemble the battery.
Introduction / Important Safety Precautions • It may explode or cause a fire. ENGLISH • Disposal methods may differ by country and region. Dispose of spent batteries in accordance with the laws and safety rules of the country and region you reside in. If you find leakage or smell bad odor from the battery, remove the battery and contact the local service center. • It may explode or cause a fire. Do not store in places with temperatures above 60 °C and high humidity (in cars or saunas).
Introduction / Important Safety Precautions 17 Connect the power plug properly by pushing it to the end. Do not bend the power cable for AC adapter too much or get stamped by a sharp object. • The wires inside the cable may break and cause electric shock or fire. Do not use loose plugs or damaged power cords. • An electric shock or fire may occur. Do not touch the power cord with your hands wet. • Otherwise, an electric shock may occur.
Introduction / Important Safety Precautions Always keep the AC adapter and power outlet clean. ENGLISH • A fire may occur. Keep children and pets from damaging the power cord. • It may cause a fire or an electric shock. Disconnect the PC completely before cleaning it. • Otherwise, an electric shock or impairment may occur. If the power/AC adapter or the product is soaked, disconnect the battery, power/AC adapter, and all other lines before contacting the local service center.
Introduction / Important Safety Precautions 19 • External shocks are inflicted on the machine while disassembling or installing it. • The PC is infected with a virus, tainting the data irrecoverably. • Abrupt turning-off of the PC can damage the PC. • If the product is moved, shaken or exposed to external shock while the storage device is running, file damage or bad sectors may occur. To minimize data loss resulting from storage device damage (HDD, SSD, eMMC), frequently back up important data.
Introduction / Important Safety Precautions ENERGY STAR® ENGLISH ENERGY STAR® ENERGY STAR® Specifications • LG Electronics Inc. participates in ENERGY STAR® and the energy efficiency of this product complies with the specifications of ENERGY STAR®. • ENERGY STAR® is a set of regulations that encourages manufacturers of electronic devices to create more energy efficient products. • The energy consumption of this product was decreased along with the cost. Also, it helps preserve natural resources.
Introduction / Important Safety Precautions 21 ENGLISH • Turn off the display: If the PC is not used for a predefined time, the screen turns off. • Put the computer to sleep: If the PC is not used for a predefined time, it enters the Sleep mode.
Introduction / Important Safety Precautions Regulatory Notices ENGLISH
Introduction / Important Safety Precautions 23 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 25 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 27 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 29 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 31 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 33 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 35 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 37 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 39 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 41 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 43 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 45 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 47 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 49 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 51 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 53 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 55 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 57 ENGLISH
Introduction / Important Safety Precautions ENGLISH
Introduction / Important Safety Precautions 59 ENGLISH
Introduction / Important Safety Precautions Product Specifications ENGLISH PC Specifications Display 35.5cm IPS LCD with Pen Touch The display resolution may differ by model. CPU Intel®Core™ i7 / i5 / i3 processor The CPU differs depending on model type and cannot be replaced by the user. GPU Intel®Iris® Xe Graphics or Intel® UHD Graphics When processing large graphic data, it utilizes dynamically allocated system memory. The size of the allocated memory depends on the system memory size.
Introduction / Important Safety Precautions 61 Wireless LAN Specifications (Europe Only) Output Power (Max) (2400 – 2483.5 MHz) IEEE802.11 b/g/n/ax mode 20 dBm EIRP max (100 mW) (5150 – 5725 MHz) IEEE802.11 a/n/ac/ax mode 23 dBm EIRP max (200 mW) The Low band 5.15-5.35 GHz is for in-door use only. (5745 – 5875 MHz) IEEE802.11 a/n/ac/ax mode 13.98 dBm EIRP Max (25 mW) (2400 – 2483.5 MHz) Bluetooth 13 dBm EIRP max (20 mW) Power Supply and Environments AC Adapter (Free Voltage) Power Rating: 65.
Using Windows 10 Using Windows 10 ENGLISH Start Menu A New Start Menu The Start menu in Windows 10 has been changed so you can use Windows quickly and easily. Press the [ ] button in the lower-left corner of the screen to display the Start menu. TIP Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
Using Windows 10 63 ENGLISH 1 Expand: Displays the names of all menu items. 2 User Account: Displays the current user's information. You can use functions such as Change Account Settings, Lock or Logout. 3 Document: Opens the default document folder in Windows. 4 Pictures: Opens the default photo folder in Windows. 5 Settings: You can set up the system including the network settings. 6 Power: Sleep, System Shutdown, and Restart menus are available. 7 App List: Displays the app list.
Using Windows 10 Desktop Apps and Windows Apps ENGLISH The Desktop apps remain unchanged from the previous Windows apps, but Windows apps have been changed to include various functions. The Windows apps provide easy-to-use menus according to the window size and a variety of convenient functions such as Update and Alarm.
Using Windows 10 65 Using Apps Run apps that were not added to the Start menu or apps that were installed on the system using the following method: 1 Press the [ ] button and select and run the app you want from the app list. TIP Press the [ ] key or [Ctrl] + [Esc] to display the Start menu. 2 To exit an app, press the [ ] button on the top of the app screen. Deleting Apps You can delete apps from the Start menu tiles or the app list.
Using Windows 10 1 Click the [ ] button to display the Start menu. ENGLISH TIP Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
Using Windows 10 67 2 Go to the Start menu app tiles or the app list and right-click the app you wish to delete.
Using Windows 10 3 When the pop-up menu appears, select [Uninstall]. ENGLISH TIP If you are deleting a desktop app, the [Programs and Features] window appears. Right-click the app you wish to delete and press the [Uninstall/Change] button.
Using Windows 10 69 4 When prompted to confirm the deletion, click the [Uninstall] button to delete the app. ENGLISH Adding Apps to Start Menu/Taskbar You can add frequently used apps on the Start menu and taskbar for easy and quick access.
Using Windows 10 1 Press the [ ] button to display the Start menu. ENGLISH TIP Press the [ ] key or [Ctrl] + [Esc] to display the Start menu.
Using Windows 10 71 2 Right-click the app you want from the app list, and then click [Pin to Start] or [More] > [Pin to Taskbar]. ENGLISH 3 The selected app is added to the Start menu or taskbar.
Using Windows 10 Toggling and Adding Apps/Desktops ENGLISH In Windows 10, you can toggle the running apps easily and quickly, and add desktops to use them like multiple PCs. TIP For an app that does not allow multitasking, you may be switched to the desktop where the app was executed, or you may have an error message. 1 In the taskbar, press [ ].
Using Windows 10 73 2 The screen to switch between apps and desktops appears and the running apps are displayed in the preview. ENGLISH TIP Press the [ ] button of an app in the preview to exit the app. You can use the timeline displayed on the Desktop screen to check the history of PC usage.
Using Windows 10 3 Click the [New Desktop] tile. ENGLISH 4 [Desktop 1] and [Desktop 2] are created.
Using Windows 10 75 5 Select an app in the preview or desktop. ENGLISH 6 The screen is toggled to the selected app or desktop.
Using Windows 10 TIP ENGLISH Press the [ ] button in the app preview to exit the app. In the desktop preview, press the [ to another desktop.
Using Windows 10 77 Using Shortcut Keys Shortcut Keys Description [Alt] + [Tab] Hold down the [Alt] key and press the [Tab] key to view the running apps in the preview. Press [Tab] repeatedly to select the app you wish to switch to and then release the [Alt] key. [Alt] + [Ctrl] + [Tab] The running apps on the screen are displayed in the preview. Select and switch to an app. [ If the desktop toggling screen appears, select an app or desktop you wish to switch to.
Using Windows 10 Splitting the App Screen ENGLISH In Windows 10, you can easily adjust window sizes and split windows if necessary. TIP Some apps that cannot adjust the window size do not support the screen split.
Using Windows 10 79 Full Screen 2 Drag and drop the app again to a different location to return to its original size. ENGLISH 1 Drag and drop an app to the top end of the screen to change the app to the full screen size.
Using Windows 10 Screen Split into Two ENGLISH 1 Drag and drop an app to the right end or left end to reduce the size by half. TIP The screen is split according to the guideline.
