ENGLISH OWNER’S MANUAL SMART CAR AUDIO Please read this manual carefully before operating your set and retain it for future reference.
Getting Started Safety Information CAUTION 1 RISK OF ELECTRIC SHOCK DO NOT OPEN or any functions. Pull over in a safe and legal manner before attempting such operations. Do not use for many hours at extremely low or high temperature. (-10 °C to 60 °C) Getting Started CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Table of Contents Disposal of your old appliance 1.When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. Table of Contents 1 Getting Started 2. All electrical and electronic products shall be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. 2 4 4 3.
Getting Started g Display window Front panel h USB port (LCS320UB/LCS321UB only) [LCS321UB/LCS320UB] i AUX If connected to other portable player, you can enjoy music from it on the unit. 1 Getting Started j t Numeric buttons (1 to 6) Selects a numbered preset station in TUNER. u 6 Opens the front panel. Remote control (Optional) Returns to the previous step. k FUNC In each mode, sets playback items. l Y/U Skip / Search / Seek / Tune [LCS120AX] m MENU Activates setting menu.
Connecting g VOLUME W / S Adjusts volume level. h c/v Skip / Search / Seek / Tune i DISP • Press it, you can check the clock time. • Press and hold it, you can turn on/ off the display window and the light of LED buttons. Installation Type 1 Basic Installation Before installing, make sure that the ignition-switch is set to OFF and remove the terminal of the car battery to avoid short-circuiting. ISO-DIN Installation Bend the claws according to the thickness of the dashboard.
Connecting About detachable control panel Detaching the control panel 1. Press the 6 to open the control panel. Attaching the control panel 2. Lift the control panel slightly. 3. Push the control panel to right. 2 Connecting 1. Align the left side of the panel with the stopper. 2. Push the right side of panel into the unit until it clicks. 5 6 4. Pull the control panel out of the unit. > Caution The control buttons may not work properly if the control panel is not attached properly.
Connecting 7 Connection Connecting to a car Before installing, make sure that the ignition-switch is set to OFF and remove the terminal of the car battery to avoid short-circuiting. Wired remote input (Black): Hard-wired control adapter can be connected. (Optional) To Audio out (Optional) 2 Front Left Front Right Amplifier ab c d ab c d e f g h e f g h Power Antenna > Caution Control Relay When being connected in a wrong way, the unit displays as follows.
Operating Operation Basic operations 1. Turn the unit on by pressing any key on the unit. 2. Select a source by pressing SRC. 3. Rotate the volume knob to adjust the volume on the unit. Or press VOLUME W / S on the remote control. Turning off the sound temporarily 1. Press MUTE to mute your unit. Or press MUTE on the remote control. 2. Press it again to cancel 3 Using EQ (Equalizer) Operating EQ is to increase or decrease the signal strength of audio frequencies.
Operating For [LIGHT] setting You can adjust the light effects by adjusting DIM, or DIM LV. DIM (Dimmer) OFF / ON : You can change the brightness of the display window during the power-on status. Settings Description DIM ON The display window becomes dark. DIM OFF The display window becomes bright. DIM LV (Dimmer Level) : When you set DIM to ON, you can adjust the dimmer level. (-2, -1, 0, +1, +2) AUX (Auxiliary) ON / OFF It is possible to use auxiliary equipment with this unit.
Operating Using the FUNC button On the unit 1. Press FUNC. 2. Rotate the volume knob to select an item and press it. 3. Rotate the volume knob to select the option. 4. Press the volume knob to set the option. If you want to return to the previous step, press . On the Remote Control 3 Operating 1. Press FUNC / • MENU. 2. Press w / s to select an item and press it. 3. Press w / s to select the option. 4. Press ENTER to set the option. If you want to return to the previous step, press .
Operating , Note When a station is stored on the preset numbers on which another station of the same band has already been preset, the previously preset station is automatically erased. Listening to a preset station 1. Press BAND repeatedly to select a desired band. 2. Press the volume knob on the unit. Or press ENTER on the remote control. 3. Rotate the volume knob to select a preset station. Or press w / s on the remote control. 4. Press the volume knob. Or press ENTER on the remote control.
Operating Using an USB device (LCS320UB/LCS321UB only) 1. Open the USB cover. 2. Connect the USB device. 3. Press SRC repeatedly to select a source to USB. Moving to another drive 3 Playable USB device Requirement Do not extract the USB device during operation (play, etc.). An USB device which requires additional programme installation when you have connected it to a computer, is not supported.
Troubleshooting 13 Troubleshooting Symptoms Cause Solution Power doesn't turned on. Leads and connectors are not properly. Confirm once more that all connections are correct. The fuse is blown. Rectify the problem that caused the fuse to blow, and then replace it. Be very sure to install the correct fuse with the same rate. Noise and other factors are causing the built in microprocessor to operate incorrectly. Turn the unit off and then on again. Cables are not connected correctly.
Appendix Specifications CD Frequency Response : 20 Hz to 20 kHz General S / N Ratio : 80 dB Output Power : 53 W x 4 CH (Max.) Distortion : 0.12 % Power Source : DC 12 V Channel Separation (1 kHz) : 55 dB Speaker impedance : 4 Ω Ground System : Negative Dimensions (W x H x D) : (178 x 50 x168) mm (without Control Panel) Net Weight : 1.32 kg TUNER FM Tuning Range : 87.5 MHz to 108.0 MHz S / N Ratio : 55 dB Distortion : 0.
