OWNER’S MANUAL NEW TYPE CYCLONE VACUUM CLEANER This information contains important instructions for the safe use and maintenance of the vacuum cleaner. Especially, please read all of the information on page 3, 4, 5 for your safety. Please keep this manual in an easily accessible place and refer to it anytime. VB-7320HRF VB-7320HTS VB-7320HPL www.lg.
Table of contents Important safety instructions ........................................................................ 3~5 How to use .................................................................................................... 6~15 Assembling vacuum cleaner ........................................................................................................... 6 Operating vacuum cleaner ............................................................................................................
IMPORTANT SAFETY INSTRUCTIONS Read and follow all instructions before using your vacuum cleaner to prevent the risk of fire, electric shock, personal injury, or damage when using the vacuum cleaner. This guide do not cover all possible conditions that may occur. Always contact your service agent or manufacturer about problems that you do not understand. This appliance complies with the following EC Directives :-2006/95/EC Low Voltage Directive -2004/108/EC EMC Directive. This is the safety alert symbol.
IMPORTANT SAFETY INSTRUCTIONS WARNING • Do not plug in if control knob is not in OFF position. Personal injury or product damage could result. • Keep children away and beware of obstructions when rewinding the cord to prevent personal injury The cord moves rapidly when rewinding. • Disconnect electrical supply before servicing or cleaning the unit or when cleaner is not in use. Failure to do so could result in electrical shock or personal injury.
IMPORTANT SAFETY INSTRUCTIONS CAUTION • Do not put any objects into openings. Failure to do so could result in product damage. • Do not use with any opening blocked: keep free of dust, lint, hair, and anything that may reduce air flow. Failure to do so could result in product damage. • Do not use vacuum cleaner without the dust tank and/ or filters in place. Failure to do so could result in product damage.
How to use Assembling vacuum cleaner Hose handle Spring latch Telescopic pipe (depend on model) ➊ Carpet and floor nozzle Push the telescopic pipe into the nozzle. 6 (depend on model) ➋ Telescopic pipe • Push the hose handle firmly into the telescopic pipe. • Grasp the spring latch to expand. • Pull out the pipe to desired length.
Click! Button Fitting pipe Flexible hose Attachment point ➌ Connecting the hose to the vacuum cleaner Push the fitting pipe on the flexible hose into the attachment point on the vacuum cleaner. To remove the flexible hose from the vacuum cleaner, press the button situated on the fitting pipe, then pull the fitting pipe out of the vacuum cleaner.
How to use Operating vacuum cleaner Plug Cord reel button Regulator MAX line ➊ How to operate • Pull out the power cord to the desired length and plug into the socket. • Place the control knob of the hose handle to the required position. • To turn off, slide control knob to OFF position. • Press the cord reel button to rewind the power cord after use. WARNING ➋ Emptying the dust tank • Always empty the dust tank when the dust tank level reaches the MAX line. No liquid suction.
How to use Using carpet and floor nozzle / Suction Hole for device protection Carpet Pedal Floor Suction Hole for Device Protection Extension Pipe for Lenght Adjustment ➊ Carpet and floor nozzle(depend on model) • The 2 position nozzle This is equipped with a pedal which allows you to alter its position according to the type of floor to be cleaned. • Carpet or rug position Press the pedal ( ) to lower brush. • Hard floor position (tiles, parquets floor) ) to lift the brush up.
How to use Using 2 in 1 nozzle Upholstery nozzle Dusting brush 3 4 ➌ Upholstery nozzle(depend on model) ➍ Dusting brush(depend on model) Upholstery nozzle is for vacuuming upholstery, mattresses etc. Push the button Dusting brush is for vacuuming picture frames, furniture frames, books and other irregular surfaces.
How to use Using accessory nozzles Crevice tool 5 Upholstery nozzle Dusting brush 6 7 ➎C revice tool(depend on model) ➏ U pholstery nozzle(depend on model) ➐ D usting brush(depend on model) Crevice tool is for vacuuming in those nomally hard-to-reach place such as reaching cobwebs or between the cushios of sofa. Upholstery nozzle is for vacuuming upholstery, mattresses etc. The thread collectors help to plck up the tnreads and fluff.
How to use Emptying dust tank Tank separation button ① Push the button ② Pull out MAX line Tank handle Dust tank cap The dust tank needs emptying when the dust tank level reaches the MAX line. • Turn off the vacuum cleaner and unplug it. • Grasp the handle of the tank and then press the tank separation button. • Pull out the dust tank. • Empty the tank and then assemble the dust tank as shown.
How to use Cleaning dust tank Tank separation button ① Push the button ② Pull out Tank handle • Press tank separation button and pull out the dust tank. • Raise the dust tank cap. • Wash the dust tank. • Dry fully in shade so that moisture is entirely removed. NOTICE If suction power decreases after cleaning the dust tank, clean the air filter and the motor safety filter.
How to use C leaning dust separator - Inside of dust separator, air filter, motor safety filter Dust separator Air filter cover Guide cove Air filter cover lever Guide cover lever Air filter Motor safety filter The air filter and the motor safety filter are located on the top of the vacuum cleaner as above the figure. • Open the vacuum cleaner cover by pushing the button. • Grasp the handle of the dust separator and take out it.
How to use Cleaning exhaust filter Exhaust filter cover Exhaust filter Button Lever Exhaust filter cover Click! • The exhaust filter is a reuseable filter. • To clean the exhaust filter, open the exhaust filter cover by pushing the button. • Separate the exhaust filter by pushing the lever. • Dust off the exhaust filter.(Do not wash the exhaust filter with water.) • Insert the exhaust filter lugs into the grooves of the motor housing and push the exhaust filter.
What to do if your vacuum cleaner does not work Check that the vacuum cleaner is plugged in correctly and that the electrical socket is working. What to do when suction power decreases • Turn off the vacuum cleaner and unplug it. • Check the telescopic pipe, flexible hose and cleaning tool for blockages or obstructions. • Check that the dust tank is not full. Empty if necessary. • Check that the exhaust filter is not clogged. Clean the exhaust filter if necessary.
راﮬﻨﻤﺎی ﻣﺼﺮف ﮐﻨﻨﺪﮔﺎن ﻧﻮع ﺟﺪﯾﺪ ﺟﺎرو ﺑﺮﻗﯽ ﺳﺎﯾﮑﻠﻮن اﯾﻦ راﮬﻨﻤﺎی ﻣﺼﺮف ﮐﻨﻨﺪﮔﺎن ،ﺣﺎوی دﺳﺘﻮراﻟﻌﻤﻞ ﮬﺎی ﻣﻬﻢ در ﺧﺼﻮص اﺳﺘﻔﺎده اﯾﻤﻦ و ﮬﻤﭽﻨﯿﻦ ﻧﺤﻮه ﻧﮕﻪ داری دﺳﺘﮕﺎه ﺟﺎرو ﺑﺮﻗﯽ ﻣﯽ ﺑﺎﺷﺪ. ﺧﺼﻮﺻﺎ ﮐﻠﯿﻪ اﻃﻼﻋﺎت ﺻﻔﺤﺎت 3و 4و 5را ﺟﻬﺖ ﺗﺎﻣﯿﻦ اﯾﻤﻨﯽ ﮐﺎﻣﻞ ﻣﻄﺎﻟﻌﻪ ﻓﺮﻣﺎﯾﯿﺪ. ﻟﻄﻔﺎ اﯾﻦ راﮬﻨﻤﺎ را ﮬﻤﯿﺸﻪ در دﺳﺘﺮس ﻗﺮار داده و در زﻣﺎن ﻧﯿﺎز ﺑﻪ آن ﻣﺮاﺟﻌﻪ ﮐﻨﯿﺪ. VB-7320HRF VB-7320HTS VB-7320HPL www.lg.
ﻓﻬﺮﺳﺖ ﻣﻄﺎﻟﺐ دﺳﺘﻮرﺍﻟﻌﻤﻞ ﻫﺎی ﻣﻬﻢ ﺍﯾﻤﻨﯽ 5-3.................................................... روش ﺍﺳﺘﻔﺎده15-6................................................................... روش ﺍﺗﺼﺎل ﺍﺟﺰﺍی دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ 6................................................. روش ﮐﺎرﮐﺮد ﺍﺯ ﺟﺎروﺑﺮﻗﯽ 8........................................................................ ﺍﺳﺘﻔﺎده ﺍﺯ ﻧﺎﺯل ﻓﺮش و ﮐﻔﭙﻮش /روﺯﻧﻪ ﻣﻜﺶ ﺑﺮﺍی ﻣﺤﺎﻓﻈﺖ دﺳﺘﮕﺎه 9..................... روش ﺍﺳﺘﻔﺎده ﺍﺯ ﺳﺮی ﺗﻤﯿﺰ ﮐﻨﻨﺪه دو ﮐﺎره10..........
دﺳﺘﻮرﺍﻟﻌﻤﻞ ﻫﺎی ﻣﻬﻢ ﺍﯾﻤﻨﯽ ﺑﻤﻨﻈﻮر ﺟﻠﻮﮔﯿﺮی ﺍﺯ ﺧﻄﺮﺍت آﺗﺶ ﺳﻮﺯی ،ﺑﺮق ﮔﺮﻓﺘﮕﯽ ،ﺑﺮوﺯ ﺟﺮﺍﺣﺖ و ﯾﺎ آﺳﯿﺐ دﯾﺪﮔﯽ دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ در ﻫﻨﮕﺎم ﺍﺳﺘﻔﺎده ،ﺍﯾﻦ رﺍﻫﻨﻤﺎ رﺍ ﻗﺒﻞ ﺍﺯ ﻣﻮرد ﺍﺳﺘﻔﺎده ﻗﺮﺍر دﺍدن دﺳﺘﮕﺎه ،ﻣﻄﺎﻟﻌﻪ و دﺳﺘﻮرﺍﻟﻌﻤﻞ ﻫﺎی آن رﺍ ﻣﻮرد دﻗﺖ ﻗﺮﺍر دﻫﯿﺪ .ﺍﯾﻦ دﻓﺘﺮﭼﻪ رﺍﻫﻨﻤﺎ ﺷﺎﻣﻞ ﮐﻠﯿﻪ ﺷﺮﺍﯾﻂ ﺍﺣﺘﻤﺎﻟﯽ ﭘﯿﺶ آﻣﺪه ﻧﻤﯽ ﺑﺎﺷﺪ .ﻫﻤﯿﺸﻪ در ﺑﺮﺧﻮرد ﺑﺎ ﺍﯾﺮﺍدﺍﺗﯽ ﮐﻪ در ﻣﻮرد آﻧﻬﺎ آﮔﺎﻫﯽ ﻧﺪﺍرﯾﺪ ،ﺑﺎ ﻧﻤﺎﯾﻨﺪه ﺳﺮوﯾﺲ و ﯾﺎ ﮐﺎرﺧﺎﻧﻪ ﺳﺎﺯﻧﺪه ﺗﻤﺎس ﺣﺎﺻﻞ ﺑﻔﺮﻣﺎﺋﯿﺪ. ﺍﯾﻦ دﺳﺘﮕﺎه ﺑﺮ ﺍﺳﺎس ﻗﻮﺍﻧﯿﻦ و ﺍﺳﺘﺎﻧﺪﺍردﻫﺎی ﺯﯾﺮ ﺳﺎﺧﺘﻪ ﺷﺪه ﺍﺳﺖ .
ﻫﺸﺪار دﺳﺘﻮرﺍﻟﻌﻤﻞ ﻫﺎی ﻣﻬﻢ ﺍﯾﻤﻨﯽ • در ﺻﻮرت ﻗﺮﺍر ﻧﺪﺍﺷﺘﻦ دﮐﻤﻪ ﮐﻨﺘﺮل ﺑﺮ روی وﺿﻌﯿﺖ ﺧﺎﻣﻮش، دوﺷﺎﺧﻪ دﺳﺘﮕﺎه رﺍ ﺑﻪ ﺑﺮق وﺻﻞ ﻧﻜﻨﯿﺪ. ﺣﺎﺻﻞ ﺍﯾﻦ ﻋﻤﻞ ﺟﺮﺍﺣﺖ ﻓﺮدی و ﯾﺎ آﺳﯿﺐ دﯾﺪﮔﯽ دﺳﺘﮕﺎه ﺧﻮﺍﻫﺪ ﺑﻮد. • ﺑﻤﻨﻈﻮر ﺟﻠﻮﮔﯿﺮی ﺍﺯ ﺑﺮوﺯ ﺟﺮﺍﺣﺎت ﺑﺮ ﺍﻓﺮﺍد ،در ﻫﻨﮕﺎم ﺟﻤﻊ ﮐﺮدن ﮐﺎﺑﻞ ﺑﺮق ﺑﻪ ﻣﻮﺍﻧﻊ ﻣﻮﺟﻮد ﺗﻮﺟﻪ دﺍﺷﺘﻪ ﺑﺎﺷﯿﺪ و در ﻋﯿﻦ ﺣﺎل ﮐﻮدﮐﺎن رﺍ ﺍﺯ دﺳﺘﮕﺎه دور ﻧﮕﻪ دﺍرﯾﺪ. ﺣﺮﮐﺖ ﮐﺎﺑﻞ در ﻫﻨﮕﺎم ﺟﻤﻊ ﺷﺪن ﺳﺮﯾﻊ ﺍﺳﺖ.
ﺍﺧﻄﺎر دﺳﺘﻮرﺍﻟﻌﻤﻞ ﻫﺎی ﻣﻬﻢ ﺍﯾﻤﻨﯽ • در ﻫﻨﮕﺎم ﺟﺎﺑﺠﺎﺋﯽ دﺳﺘﮕﺎه ،دﺳﺘﻪ ﻣﺤﻔﻈﻪ آﺷﻐﺎل را در دﺳﺖ ﻧﮕﯿﺮﯾﺪ. • ﺍﺯ ﻓﺮو ﮐﺮدن ﺍﺟﺴﺎم در ﻣﻨﺎﻓﺬ دﺳﺘﮕﺎه ﺧﻮددﺍری ﮐﻨﯿﺪ. ﻋﺪم رﻋﺎﯾﺖ ﺍﻧﺠﺎم ﭼﻨﯿﻦ ﮐﺎری ﺍﺣﺘﻤﺎل آﺳﯿﺐ دﯾﺪﮔﯽ دﺳﺘﮕﺎه رﺍ ﺑﻪ ﻫﻤﺮﺍه ﺧﻮﺍﻫﺪ دﺍﺷﺖ اﻣﮑﺎن دارد در ﻫﻨﮕﺎم ﺟﺪا ﺷﺪن ﻣﺤﻔﻈﻪ از ﺑﺪﻧﻪ ،ﻗﺴﻤﺖ ﺑﺪﻧﻪ ﺟﺎرو ﺑﺮﻗﯽ ﺑﻪ زﻣﯿﻦ ﺑﯿﻔﺘﺪ. • در ﻫﻨﮕﺎم ﺍﻧﺴﺪﺍد ﻫﺮﯾﻚ ﺍﺯ ﻣﻨﺎﻓﺬ دﺳﺘﮕﺎه ،ﺍﺳﺘﻔﺎده ﺍﺯ آن ﺧﻮددﺍری ﺷﻮد. ﺣﺎﺻﻞ اﯾﻦ ﻋﻤﻞ ﺟﺮاﺣﺖ ﻓﺮدی و ﯾﺎ آﺳﯿﺐ دﯾﺪﮔﯽ دﺳﺘﮕﺎه ﺧﻮاﻫﺪ ﺑﻮد.
روش ﺍﺳﺘﻔﺎده روش ﺍﺗﺼﺎل ﺍﺟﺰﺍی دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ ﮐﻠﯿﻚ! دﮐﻤﻪ ﻗﺴﻤﺖ ﺍﺗﺼﺎل ﻟﻮﻟﻪ 3 ﺷﻠﻨﮓ ﻗﺎﺑﻞ ﺍﻧﻌﻄﺎف ﻧﻘﻄﻪ ﺍﺗﺼﺎل 1ﻧﺎﺯل ﻓﺮش و ﮐﻒ ﺯﻣﯿﻦ ﻧﺎﺯل رﺍ در دﺍﺧﻞ ﻟﻮﻟﻪ ﺗﻠﺴﻜﻮﭘﯽ ﻓﺸﺎر دﻫﯿﺪ. 6 2ﻟﻮﻟﻪ ﺗﻠﺴﻜﻮﭘﯽ • ﻟﻮﻟﻪ ﺗﻠﺴﻜﻮﭘﯽ رﺍ ﺑﻄﻮر ﻣﺤﻜﻢ در دﺍﺧﻞ دﺳﺘﻪ ﻟﻮﻟﻪ ﺧﺮﻃﻮﻣﯽ ﻓﺸﺎر دﻫﯿﺪ. • ﺧﺎر ﻗﻔﻞ ﮐﻨﻨﺪه رﺍ ﻓﺸﺎر دﻫﯿﺪ ﺗﺎ ﻟﻮﻟﻪ ﺑﺎﺯ ﺷﻮد. • ﻟﻮﻟﻪ رﺍ ﺑﻪ ﺍﻧﺪﺍﺯه دﻟﺨﻮﺍه ﺑﯿﺮون ﺑﻜﺸﯿﺪ.
ﺧﺮﻃﻮﻣﯽ دﺳﺘﮕﯿﺮه ﻟﻮﻟﻪ ﺧﺎر ﻗﻔﻞ ﮐﻨﻨﺪه 2 ﮐﻠﯿﻚ ﻟﻮﻟﻪ ﺗﻠﺴﻜﻮﭘﯽ 1 3روش ﺍﺗﺼﺎل ﺷﻠﻨﮓ ﺧﺮﻃﻮﻣﯽ ﺑﻪ دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ ﻗﺴﻤﺖ ﺍﺗﺼﺎل ﻟﻮﻟﻪ ﻣﻮﺟﻮد ﺑﺮ روی ﺷﻠﻨﮓ ﻗﺎﺑﻞ ﺍﻧﻌﻄﺎف رﺍ در دﺍﺧﻞ ﻧﻘﻄﻪ ﺍﺗﺼﺎل دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ ﻓﺸﺎر دﻫﯿﺪ. ﺑﺮﺍی ﺑﯿﺮون آوردن ﺷﻠﻨﮓ ﻗﺎﺑﻞ ﺍﻧﻌﻄﺎف ﺯﺍﺋﺪه ی روی ﻟﻮﻟﻪ رﺍﺑﻂ رﺍ ﻓﺸﺎر دﻫﯿﺪ و ﺳﭙﺲ ﻟﻮﻟﻪ رﺍﺑﻂ رﺍ ﺍﺯ دﺍﺧﻞ دﺳﺘﮕﺎه ﺑﯿﺮون ﺑﻜﺸﯿﺪ.
روش ﺍﺳﺘﻔﺎده 1 روش ﮐﺎرﮐﺮد ﺍﺯ ﺟﺎروﺑﺮﻗﯽ 3 2 4 دوﺷﺎﺧﻪ دﮐﻤﻪ ﺳﯿﻢ ﺟﻤﻊ ﮐﻦ دﮐﻤﻪ ﮐﻨﺘﺮل ﺣﺪﺍﮐﺜﺮ ﺧﻂ 1روش ﮐﺎرﮐﺮد دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ 2ﺧﺎﻟﯽ ﮐﺮدن ﻣﺨﺰن ﮔﺮد و ﺧﺎك 3ﺣﺎﻟﺖ ﭘﺎرك دﺳﺘﮕﺎه • ﺳﯿﻢ ﺑﺮق رﺍ ﺑﻪ ﻣﯿﺰﺍن دﻟﺨﻮﺍه ﺑﯿﺮون ﮐﺸﯿﺪه و ﺳﭙﺲ دوﺷﺎﺧﻪ رﺍ ﺑﻪ ﭘﺮﯾﺰ ﻣﺘﺼﻞ ﮐﻨﯿﺪ. • ﺟﻬﺖ ﺑﻜﺎر ﺍﻧﺪﺍﺯی دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ ،دﮐﻤﻪ ﮐﻨﺘﺮل روی دﺳﺘﻪ ﻟﻮﻟﻪ ﺧﺮﻃﻮﻣﯽ رﺍ ﺣﺮﮐﺖ دﻫﯿﺪ. • ﺟﻬﺖ ﺧﺎﻣﻮش ﮐﺮدن دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ ،دﮐﻤﻪ ﮐﻨﺘﺮل رﺍ روی وﺿﻌﯿﺖ ﺧﺎﻣﻮش ﻗﺮﺍر دﻫﯿﺪ.
روش ﺍﺳﺘﻔﺎده 1 ﺍﺳﺘﻔﺎده ﺍﺯ ﻧﺎﺯل ﻓﺮش و ﮐﻔﭙﻮش/ روﺯﻧﻪ ﻣﻜﺶ ﺑﺮﺍی ﻣﺤﺎﻓﻈﺖ دﺳﺘﮕﺎه 2 ﻓﺮش ﭘﺪﺍل ﮐﻒ ﺯﻣﯿﻦ 2 روﺯﻧﻪ ﻣﻜﺶ ﺑﺮﺍی ﻣﺤﺎﻓﻈﺖ ﺍﺯ ﻗﻄﻌﻪ ﻟﻮﻟﻪ رﺍﺑﻂ ﺑﺮﺍی ﺗﻨﻈﯿﻢ ﻃﻮل 1ﻧﺎﺯل ﻓﺮش و ﮐﻔﭙﻮش )ﺑﻪ ﻣﺪل ﺑﺴﺘﮕﯽ دارد( • ﻧﺎﺯل دو ﺣﺎﻟﺘﻪ روی ﺍﯾﻦ ﻧﺎﺯل ﭘﺪﺍﻟﯽ ﻗﺮﺍر ﮔﺮﻓﺘﻪ ﺍﺳﺖ ﮐﻪ ﺑﻪ ﺷﻤﺎ ﺍﻣﻜﺎن ﻣﯽ دﻫﺪ ﺑﺮ ﺣﺴﺐ ﻧﻮﻉ ﮐﻒ ﻣﺤﻞ ،وﺿﻌﯿﺖ رﺍ ﺗﻐﯿﯿﺮ دﻫﯿﺪ. • ﺣﺎﻟﺖ ﻓﺮش ﯾﺎ ﻗﺎﻟﯿﭽﻪ ( رﺍ ﻓﺸﺎر دﻫﯿﺪ ﺗﺎ ﺑﺮس ﭘﺎﯾﯿﻦ ﺑﺮود. ﭘﺪﺍل ) • ﺣﺎﻟﺖ ﺳﻄﻮح ﺳﺨﺖ )ﮐﺎﺷﯽ ،ﭘﺎرﮐﺖ( ﭘﺪﺍل ) ( رﺍ ﻓﺸﺎر دﻫﯿﺪ ﺗﺎ ﺑﺮس ﺑﺎﻻ ﺑﺮود.
روش ﺍﺳﺘﻔﺎده روش اﺳﺘﻔﺎده از ﺳﺮی ﺗﻤﯿﺰ ﮐﻨﻨﺪه دو ﮐﺎره 3 3 3 4 ﺳﺮ ﺗﻤﯿﺰ ﮐﻨﻨﺪه ﻣﺒﻠﻤﺎن 4 4 3 ﺑﺮس ﻏﺒﺎر روب 4 3ﺳﺮ ﺗﻤﯿﺰ ﮐﻨﻨﺪه ﻣﺒﻠﻤﺎن )ﺑﻪ ﻣﺪل ﺑﺴﺘﮕﯽ دارد( ﮐﺎرﺑﺮد ﺳﺮ ﺗﻤﯿﺰ ﮐﻨﻨﺪه ﻣﺒﻠﻤﺎن ﺟﻬﺖ ﺗﻤﯿﺰﮐﺎری ﻣﺒﻠﻤﺎن، ﻟﺤﺎف و ﻏﯿﺮه ﻣﯽ ﺑﺎﺷﺪ. 4ﺑﺮس ﻏﺒﺎر روب )ﺑﻪ ﻣﺪل ﺑﺴﺘﮕﯽ دارد( ﮐﺎرﺑﺮد ﺑﺮس ﻏﺒﺎر روب در ﺗﻤﯿﺰ ﮐﺎری ﻗﺎب ﻫﺎی ﻋﮑﺲ، ﭼﻬﺎر ﭼﻮب اﺛﺎﺛﯿﻪ ،ﮐﺘﺎب ﻫﺎ و دﯾﮕﺮ ﺳﻄﻮح ﻏﯿﺮ ﻫﻤﻮار ﻣﯽ ﺑﺎﺷﺪ.
روش ﺍﺳﺘﻔﺎده روش ﺍﺳﺘﻔﺎده ﺍﺯ ﻧﺎﺯل ﻫﺎی ﺟﺎﻧﺒﯽ ﻧﺎﺯل ﮐﻨﺎره ﻫﺎی دﯾﻮﺍر 5 ﺳﺮ ﺗﻤﯿﺰ ﮐﻨﻨﺪه ﻣﺒﻠﻤﺎن 6 ﺑﺮس ﻏﺒﺎر روب 7 6 5 7 5ﻧﺎﺯل ﮐﻨﺎره ﻫﺎی دﯾﻮﺍر )ﺑﻪ ﻣﺪل ﺑﺴﺘﮕﯽ دارد( ﮐﺎرﺑﺮد ﻧﺎﺯل ﮐﻨﺎره ﻫﺎ در ﻫﻨﮕﺎم ﻧﯿﺎﺯ ﺑﻪ ﺗﻤﯿﺰ ﮐﺮدن ﻣﻜﺎن ﻫﺎﺋﯽ ﺍﺳﺖ ﮐﻪ ﺑﻄﻮر ﻋﺎدی دﺳﺖ ﺑﻪ آﻧﻬﺎ ﻧﻤﯽ رﺳﺪ. ﻣﺎﻧﻨﺪ ﺗﺎر ﻋﻨﻜﺒﻮت ﻫﺎی ﺳﻘﻒ و ﯾﺎ ﻻﺑﻼی ﮐﻮﺳﻦ ﻫﺎی ﮐﺎﻧﺎﭘﻪ.
روش ﺍﺳﺘﻔﺎده روش ﺗﺨﻠﯿﻪ ﻣﺤﻔﻈﻪ آﺷﻐﺎل ﺍﻫﺮم ﺟﺪﺍﺳﺎﺯ ﻣﺤﻔﻈﻪ آﺷﻐﺎل ﺑﯿﺮون ﺑﻜﺸﯿﺪ دﺳﺘﻪ ﻣﺤﻔﻈﻪ آﺷﻐﺎل ﺣﺪﺍﮐﺜﺮ ﺧﻂ درﭘﻮش ﻣﺤﻔﻈﻪ آﺷﻐﺎل ﻣﺨﺰن ﮔﺮد و ﺧﺎك ﭘﺲ ﺍﺯ رﺳﯿﺪن ﺳﻄﺢ ﻣﺨﺰن ﮔﺮد و ﺧﺎك ﺑﻪ ﺧﻂ MAXﺑﺎﯾﺪ ﺧﺎﻟﯽ ﺷﻮد. • دﺳﺘﮕﺎه رﺍ ﺧﺎﻣﻮش ﮐﺮده و دوﺷﺎﺧﻪ آن رﺍ ﺍﺯ ﭘﺮﯾﺰ ﺑﺮق ﺑﻜﺸﯿﺪ. • دﺳﺘﻪ ﻣﺤﻔﻈﻪ رﺍ در دﺳﺖ ﮔﺮﻓﺘﻪ و آﻧﮕﺎه ﺍﻫﺮم ﺟﺪﺍﮐﻨﻨﺪه ﻣﺤﻔﻈﻪ رﺍ ﻓﺸﺎر دﻫﯿﺪ. • ﻣﺤﻔﻈﻪ آﺷﻐﺎل رﺍ ﺑﯿﺮون ﺑﯿﺎورﯾﺪ. • ﻣﺤﻔﻈﻪ آﺷﻐﺎل رﺍ ﺧﺎﻟﯽ ﻧﻤﻮده و ﺳﭙﺲ ﻣﻄﺎﺑﻖ ﺷﻜﻞ ﺯﯾﺮ آن رﺍ ﻣﺠﺪدﺍًُ ﺑﻪ دﺳﺘﮕﺎه وﺻﻞ ﮐﻨﯿﺪ.
روش ﺍﺳﺘﻔﺎده روش ﺗﻤﯿﺰ ﮐﺮدن ﻣﺤﻔﻈﻪ آﺷﻐﺎل ﺍﻫﺮم ﺟﺪﺍﺳﺎﺯ ﻣﺤﻔﻈﻪ آﺷﻐﺎل ﺑﯿﺮون ﺑﻜﺸﯿﺪ دﺳﺘﻪ ﻣﺤﻔﻈﻪ آﺷﻐﺎل • دﮐﻤﻪ ﺟﺪﺍﮐﻨﻨﺪه ﻣﺤﻔﻈﻪ آﺷﻐﺎل رﺍ ﻓﺸﺎر دﺍده و ﻣﺤﻔﻈﻪ رﺍ ﺑﯿﺮون ﺑﯿﺎورﯾﺪ. • ﻣﺤﻔﻈﻪ آﺷﻐﺎل را ﺑﺸﻮﺋﯿﺪ. • درﭘﻮش ﻣﺤﻔﻈﻪ آﺷﻐﺎل رﺍ ﺑﺮدﺍرﯾﺪ. ﻼ در ﺳﺎﯾﻪ ﺧﺸﻚ ﮐﻨﯿﺪ ﺑﻄﻮرﯾﻜﻪ ﮐﻞ رﻃﻮﺑﺖ آن ﺍﺯ ﺑﯿﻦ ﺑﺮود. • ﮐﺎﻣ ً ﺗﻮﺟﻪ درﺻﻮرت ﮔﻢ ﺷﺪن ﻗﺪرت ﻣﻜﺶ ﭘﺲ ﺍﺯ ﺗﻤﯿﺰ ﮐﺮدن ﻣﺨﺰن ﮔﺮد و ﺧﺎك ،ﻓﯿﻠﺘﺮ ﻫﻮﺍ و ﻓﯿﻠﺘﺮ ﺍﯾﻤﻨﯽ ﻣﻮﺗﻮر رﺍ ﺗﻤﯿﺰ ﮐﻨﯿﺪ .
روش ﺍﺳﺘﻔﺎده روش ﺗﻤﯿﺰ ﮐﺮدن ﺟﺪا ﺳﺎز آﺷﻐﺎل -داﺧﻞ ﺟﺪا ﺳﺎز آﺷﻐﺎل ،ﻓﯿﻠﺘﺮ ﻫﻮا ،ﻓﯿﻠﺘﺮ اﯾﻤﻨﯽ ﻣﻮﺗﻮر ﺟﺪﺍﺳﺎﺯ آﺷﻐﺎل درﭘﻮش ﻓﯿﻠﺘﺮ ﻫﻮا درﭘﻮش راﻫﻨﻤﺎ اﻫﺮم درﭘﻮش ﻓﯿﻠﺘﺮ ﻫﻮا اﻫﺮم درﭘﻮش راﻫﻨﻤﺎ ﻓﯿﻠﺘﺮ ﻫﻮﺍ ﻓﯿﻠﺘﺮ ﺍﯾﻤﻨﯽ ﻣﻮﺗﻮر در ﺷﮑﻞ ﺑﺎﻻ ﻣﺤﻞ ﻗﺮار ﮔﺮﻓﺘﻦ ﻓﯿﻠﺘﺮ ﻫﻮا و ﻓﯿﻠﺘﺮ اﯾﻤﻨﯽ ﻣﻮﺗﻮر در ﻗﺴﻤﺖ ﺑﺎﻻی دﺳﺘﮕﺎه ﺟﺎرو ﺑﺮﻗﯽ ﻧﺸﺎن داده ﺷﺪه اﺳﺖ. • ﺑﺎ ﻓﺸﺎر دﮐﻤﻪ ،درﭘﻮش روی دﺳﺘﮕﺎه ﺟﺎرو ﺑﺮﻗﯽ را ﺑﺎز ﻧﻤﺎﺋﯿﺪ. • دﺳﺘﻪ ﺟﺪا ﺳﺎز آﺷﻐﺎل را در دﺳﺖ ﮔﺮﻓﺘﻪ و آن را ﺑﻪ ﺳﻤﺖ ﺑﯿﺮون ﺑﮑﺸﯿﺪ.
روش ﺍﺳﺘﻔﺎده روش ﺗﻤﯿﺰ ﮐﺮدن ﻓﯿﻠﺘﺮ ﻫﻮﺍ و ﻓﯿﻠﺘﺮ ﺍﯾﻤﻨﯽ ﻣﻮﺗﻮر درﭘﻮش ﻓﯿﻠﺘﺮ ﮬﻮای ﺧﺮوﺟﯽ ﻓﯿﻠﺘﺮ ﮬﻮای ﺧﺮوﺟﯽ دﮐﻤﻪ اﮬﺮم درﭘﻮش ﻓﯿﻠﺘﺮ ﮬﻮای ﺧﺮوﺟﯽ ﮐﻠﯿﮏ • ﻓﯿﻠﺘﺮ ﻫﻮای ﺧﺮوﺟﯽ ﻗﺎﺑﻠﯿﺖ اﺳﺘﻔﺎده ﻣﺠﺪد را دارد. • ﺑﻤﻨﻈﻮر ﺗﻤﯿﺰ ﮐﺮدن ﻓﯿﻠﺘﺮ ﻫﻮای ﺧﺮوﺟﯽ ،ﺑﺎ ﻓﺸﺎر دادن دﮐﻤﻪ ﻣﺮﺑﻮﻃﻪ ،درﭘﻮش اﯾﻦ ﻓﯿﻠﺘﺮ را ﺑﺎز ﮐﻨﯿﺪ. • ﺑﺎ ﻓﺸﺎر دادن اﻫﺮم ،ﻓﯿﻠﺘﺮ ﻫﻮای ﺧﺮوﺟﯽ را ﺟﺪا ﺳﺎزﯾﺪ. • ﮔﺮد و ﺧﺎک ﻓﯿﻠﺘﺮ ﻫﻮای ﺧﺮوﺟﯽ را ﺑﺘﮑﺎﻧﯿﺪ) .از ﺷﺴﺘﺸﻮی ﻓﯿﻠﺘﺮ ﻫﻮای ﺧﺮوﺟﯽ ﺑﺎ آب ﭘﺮﻫﯿﺰ ﺷﻮد(.
در ﺯﻣﺎن ﮐﺎر ﻧﻜﺮدن دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ ،ﭼﻪ ﮐﺎرﻫﺎﺋﯽ ﺑﺎﯾﺪ ﺍﻧﺠﺎم دﺍد ﺍﺑﺘﺪﺍ ﭼﻚ ﮐﻨﯿﺪ ﮐﻪ دوﺷﺎﺧﻪ دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ ﺑﻄﻮر ﺻﺤﯿﺢ در دﺍﺧﻞ دوﺷﺎﺧﻪ ﻗﺮﺍر ﮔﺮﻓﺘﻪ و ﭘﺮﯾﺰ ﻧﯿﺰ ﺑﺮق دﺍﺷﺘﻪ ﺑﺎﺷﺪ. در ﺯﻣﺎن ﮐﺎﻫﺶ ﮐﺎرآﺋﯽ ﻣﻜﺶ ،ﭼﻪ ﮐﺎرﻫﺎﺋﯽ ﺑﺎﯾﺪ ﺍﻧﺠﺎم دﺍد • دﺳﺘﮕﺎه ﺟﺎروﺑﺮﻗﯽ رﺍ ﺧﺎﻣﻮش ﻧﻤﻮده و دوﺷﺎﺧﻪ رﺍ ﺍﺯ ﭘﺮﯾﺰ ﺧﺎرج ﻧﻤﺎﺋﯿﺪ. • ﻟﻮﻟﻪ ﺗﻠﺴﻜﻮﭘﯽ ،ﺷﻠﻨﮓ ﺧﺮﻃﻮﻣﯽ و ﻧﺎﺯل رﺍ ﺍﺯ ﻟﺤﺎﻅ ﮔﺮﻓﺘﮕﯽ و ﺍﻧﺴﺪﺍد ﻣﺠﺎری ﭼﻚ ﻧﻤﺎﺋﯿﺪ. • ﻣﺤﻔﻈﻪ آﺷﻐﺎل رﺍ ﭼﻚ ﮐﻨﯿﺪ ﮐﻪ ﭘﺮ ﻧﺸﺪه ﺑﺎﺷﺪ .در ﺻﻮرت ﻟﺰوم آن رﺍ ﺧﺎﻟﯽ ﮐﻨﯿﺪ.
