Internal Use Only Website:http://www.zenithappliances.com Dehumidifier SERVICE MANUAL MODELS: ZD30 CAUTION - BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. - ONLY FOR AUTHORIZED SERVICE.
1. Name 1. Model Specification MODELS ITEMS CAPACITY(Pints/24hrs) ZD30 30 POWER SUPPLY(Phase,V,Hz) 1Ø, 115V,60Hz 490 INPUT(W) RUNNING CURRENT(A) 4.8 ENERGY FACTOR(L/kw.h) 1.20 REFRIGERANT R22 REFRIGERANT CHARGE, oz(g) THERMISTOR OPEN 5.29(150) 33.8˚F(1±0.5°C) CLOSE 50˚F(10±0.5°C) SOLENOID VALVE COMPRESSOR MODEL No. PROTECTOR Using Temp/Humid.
2. Piping Diagrams Equipment needed: Vacuum pump, charging cylinder, manifold gauge, brazing equipment. pinch-off tool capable of making a vapor-proof seal, leak detector, tubing cutter, hand tools to remove components, service valve.
3.
4.
P/NO : MFL38891307 November , 2007
