Freestanding/Semi Built In Models
Front Clearance
Top Door Hinge Dimensions CS 2062, CBS 2062
When installing CS/CBS 20 units into a row of cabinets or
wall units; use these dimensions to achieve a custom look
with the cabinetry.
Consider the necessary clearance for the top door hinge
with CS/CBS 2062 units.
CS 2062, CBS 2062
Assuming centerline
11
Overall height can be in-
creased by 1-1/2" (40 mm).
