ENGLISH OWNER’S MANUAL LED LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LED LCD MONITOR MODELS E1951S E2051S E2251S E1951T E2051T E2251T E2351T E2251VR E2351VR E2251VQ E2351VQ www.lg.
TABLE OF CONTENTS CONTENTS ENGLISH ENG 3 ASSEMBLING AND PREPARING 26 - HDMI Timing 26 Indicator 3 Unpacking 4 Parts and buttons 27 PROPER POSTURE 6 Setting up the Monitor set 27 Proper posture for using the Monitor set.
ASSEMBLING AND PREPARING 3 ASSEMBLING AND PREPARING Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. CD(Owner's Manual) / Card D-SUB Cable (This signal cable may be attached to this product before shipping out.) DVI-D Cable (This cable is not included in all countries.
ASSEMBLING AND PREPARING Parts and buttons ENGLISH ENG Power Indicator yyLighting On: Turned on yyLighting Off: Turned off (Power Button) Button ("CUSTOMIZING SETTINGS" on page 13) E2251VR E2251VQ E1951S E2051S E2251S E2351VR E2351VQ DC-IN / D-SUB 䏳㵎幑‣ HDMI DVI-D D-SUB DC-IN / 䏳㵎幑‣ HDMI DC-IN / E1951T E2051T D-SUBE2351T 䏳㵎幑‣ E2251T DC-IN / DVI-D D-SUB 䏳㵎幑‣ DVI-D Connection panel (See p.
ASSEMBLING AND PREPARING Button 5 Description Accesses the main menus.(See p.14) Left First Button OSD LOCKED/ UNLOCKED SUPER+ RESOLUTION Use this button to enter SUPER+ RESOLUTION menu. For more information.(See p.16) DUAL Use this button to enter DUAL menu. For more information.(See p.17) AUTO When adjusting your display settings, always press the AUTO button on the MONITOR SETUP OSD.
ASSEMBLING AND PREPARING ENGLISH ENG Setting up the Monitor set Detaching the Stand Base Attaching the Stand Base 1 Place the Monitor set with the screen side 1 Place the Monitor set with the screen side 2 Turn the screw to the left, and then pull out the down on a flat and cushioned surface. down on a flat and cushioned surface. Stand Base from the Stand Body. CAUTION Lay a foam mat or soft protective cloth on the surface to protect the screen from damage.
ASSEMBLING AND PREPARING 2 Remove 4 screws and pull out the Stand Body from the Monitor set. 7 2 Connect the AC-DC Adapter and Power Cord DC-IN / 䏳㵎幑‣ 3 Press Power button on the front switch of panel to turn the power on. Mounting on a table 1 Lift and tilt the Monitor set into its upright position on a table. Leave a 10 cm (minimum) space from the wall for proper ventilation. 10 cm 10 cm 10 cm 10 cm CAUTION Disconnect the power cord first, and then move or install the Monitor set.
ASSEMBLING AND PREPARING manual supplied with the Kensington security system or visit http://www.kensington.com . WARNING ENGLISH ENG When you adjust the angle, do not hold the bottom of the Monitor set frame as shown on the following illustration, as may injure your fingers. Do not touch or press the screen when adjusting the angle of the monitor. Connect the Kensington security system cable between the Monitor set and a table. NOTE The Kensington security system is optional.
ASSEMBLING AND PREPARING 1 Please, Use the screw and wall mount interface 2 in accordance with VESA Standards. If you use screw longer than standard, the monitor might be damaged internally. 3 If you use improper screw, the product might be damaged and drop from mounted position. In this case, LG Electronics is not responsible for it. 4 VESA compatible only with respect to screw mounting interface dimensions and mounting screw specifications. 5 Please use VESA standard as below. 784.8 mm (30.
USING THE MONITOR SET USING THE MONITOR SET ENGLISH ENG Connecting to a PC E2251VR E2351VR E2251VQ E2351VQ Your Monitor set supports Plug & Play*. yy *Plug & Play: A PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention. HDMI DC-IN / DVI-D D-SUB 䏳㵎幑‣ D-SUB connection Transmits analog video from your PC to the Monitor set.
USING THE MONITOR SET CAUTION Transmits a digital video signal from your PC to the Monitor set. Connect the PC and the Monitor set with a DVI cable as shown in the following illustrations. E1951T E2051T E2251T E2351T DC-IN / DVI-D D-SUB 䏳㵎幑‣ DVI OUT E2251VR E2351VR E2251VQ E2351VQ HDMI DC-IN / DVI-D DVI OUT D-SUB 䏳㵎幑‣ Connect the signal yy input cable and tighten it by turning the screws clockwise.
USING THE MONITOR SET HDMI connection Self Image Setting Function ENGLISH ENG Transmits the digital video and audio signals from your PC or A/V to the Monitor set. Connect the PC or A/V and the Monitor set with the HDMI cable as shown in the following illustrations. Press the power button on the front panel to turn the power on. When monitor power is turned on, the "Self Image Setting" Function is executed automatically.
CUSTOMIZING SETTINGS 13 CUSTOMIZING SETTINGS ENG ENGLISH Accessing The Main Menus 1 Press any button on the front of the Monitor set to display the MONITOR SETUP OSD menu. 2 Press the desired menu item. 3 Change the value of the menu item by pressing the buttons on the front of the Monitor set. To return to the upper menu or set other menu items, use the up arrow ( ) button. 4 Select EXIT to leave the OSD menu. Monitor set Buttons MENU (See p.14) Sets the screen options. AUTO (See p.
CUSTOMIZING SETTINGS Customizing Settings ENGLISH ENG Menu Settings MENU 1 Press any button on the front of the Monitor set to display the MONITOR SETUP OSD menu. 2 Press the MENU button to display the options in the OSD menu. 3 Set the options by pressing the ◄ or ► or ▼ buttons. 4 Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button.
CUSTOMIZING SETTINGS SUPER ENERGY SAVING Settings 15 SUPER ENERGY SAVING ENG ENGLISH 1 Press any button on the front of the Monitor set to display the MONITOR SETUP OSD menu. ON 2 Press the MENU button to display the options in the OSD Menu. 3 Select SUPER ENERGY SAVING by pressing the ▼ button. SUPER SAVING : 5 W/h LED SAVING : 12 W/h OFF RESET TOTAL POWER REDUCTION: 20 W TOTAL CO2 REDUCTION: 16 g 4 Enter to SUPER ENERGY SAVING by pressing the ► button.
CUSTOMIZING SETTINGS SUPER+ RESOLUTION Settings SUPER+ RESOLUTION ENGLISH ENG 1 Press any button on the front of the Monitor set to display the MONITOR SETUP OSD menu. NORMAL 2 Press the SUPER+ RESOLUTION button to display LOW MEDIUM the options in the OSD menu. HIGH EXIT 3 Set the options by pressing ◄ or ► buttons. 4 Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button.
CUSTOMIZING SETTINGS DUAL MONITOR Settings 17 DUAL PACKAGE ► DUAL MONITOR ENG ENGLISH 1 Press any button on the front of the Monitor set to display the MONITOR SETUP OSD menu. 2 Press the DUAL button to display the options in the OSD menu. OFF 3 Set the options by pressing ▼ and then ◄ and ► buttons. EXTENDED CLONE 4 Select EXIT to leave the OSD menu. EXIT To return to the upper menu or set other menu items, use the up arrow ( ) button. The available DUAL MONITOR settings are described below.
TROUBLESHOOTING ENGLISH ENG TROUBLESHOOTING Check the following before calling for service. No image appears Is the power cord of the display connected? yy Check and see if the power cord is connected properly to the power outlet. Is the power indicator light on? yy Press the Power button. yy If the display is in power saving mode, try moving the mouse or pressing any key on the keyboard to bring up the screen. yy Try to turn on the PC.
TROUBLESHOOTING 19 The screen color is mono or abnormal. The screen blinks. yy Check if the signal cable is properly connected and use a screwdriver to fasten if necessary. yy Make sure the video card is properly inserted in the slot. yy Set the color setting higher than 24 bits (true color) at Control Panel ► Settings. yy Check if the screen is set to interlace mode and if yes, change it to the recommend resolution.
SPECIFICATIONS ENGLISH ENG SPECIFICATIONS E1951S E1951T Display Sync Input Video Input Resolution Plug & Play Power Consumption Screen Type 47.0 cm (18.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size: 47.0 cm Pixel Pitch Horizontal Frequency Vertical Frequency Input Form E1951S E1951T Signal Input E1951S E1951T 0.3 mm x 0.
SPECIFICATIONS E2051T Display Sync Input Video Input Resolution Plug & Play Power Consumption Screen Type 50.8 cm (20.0 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size: 50.8 cm Pixel Pitch Horizontal Frequency Vertical Frequency Input Form E2051S E2051T Signal Input E2051S E2051T Input Form E2051S E2051T Max E2051S E2051T Recommend E2051S E2051T On Mode : 21 W(Typ.) Sleep Mode ≤ 0.5 W Off Mode ≤ 0.5 W 0.2766 mm x 0.
SPECIFICATIONS E2251S E2251T ENGLISH ENG Display Sync Input Video Input Resolution Plug & Play Power Consumption Screen Type Pixel Pitch Horizontal Frequency Vertical Frequency Input Form E2251S E2251T Signal Input E2251S E2251T Input Form E2251S E2251T Max E2251S E2251T Recommend E2251S E2251T On Mode : 26 W(Typ.) Sleep Mode ≤ 0.5 W Off Mode ≤ 0.5 W 54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating. Visible diagonal size: 54.6 cm 0.248 mm x 0.
SPECIFICATIONS 23 E2251VR E2251VQ Screen Type Sync Input Pixel Pitch Horizontal Frequency Vertical Frequency 54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating. Visible diagonal size: 54.6 cm 0.248 mm x 0.248 mm (Pixel Pitch) 30 kHz to 83 kHz (Automatic) 56Hz to 75Hz (D-SUB, DVI-D) 56Hz to 61Hz (HDMI) Video Input Input Form Signal Input Separate Sync. Digital.
SPECIFICATIONS E2351T E2351VR E2351VQ ENGLISH ENG Display Sync Input Video Input Resolution Screen Type 58.4 cm (23 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size: 58.4 cm Pixel Pitch Horizontal Frequency Vertical Frequency E2351T E2351VR / E2351VQ 0.265 mm x 0.
SPECIFICATIONS 25 Preset Modes (Resolution) ENG ENGLISH D-SUB / DVI Timing E1951S / E1951T *If you can't select 1366 x 768 in display property timing option, please update your video card driver from your video card vendor. Display Modes (Resolution) Horizontal Frequency(kHz) Vertical Frequency(Hz) Polarity(H/V) 720 x 400 31.468 70 -/+ 640 x 480 31.469 60 -/- 640 x 480 37.500 75 -/- 800 x 600 37.879 60 +/+ 800 x 600 46.875 75 +/+ 832 x 624 49.725 75 -/- 1024 x 768 48.
SPECIFICATIONS HDMI Timing ENGLISH ENG E2251VR / E2251VQ / E2351VR / E2351VQ Display Modes (Resolution) Horizontal Frequency(kHz) Vertical Frequency(Hz) 480P 31.50 60 576P 31.25 50 720P 37.50 50 720P 45.00 60 1080i 28.12 50 1080i 33.75 60 1080P 56.25 50 1080P 67.
PROPER POSTURE 27 ENG ENGLISH PROPER POSTURE Proper posture for using the Monitor set. Adjust the Monitor set and your posture to allow you to view images at the optimal viewing angle. Place your hands gently on the keyboard, keeping your arms bent at the elbows and horizontally outright. Adjust the location of the Monitor set to avoid it reflecting light.
Make sure to read the Safety Precautions before using the product. Keep the Owner’s Manual (CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service. MODEL SERIAL ENERGY STAR is a set of power-saving guidelines issued by the U.S.Environmental Protection Agency(EPA). As an ENERGY STAR Partner LGE U. S. A.,Inc.
