ASSEMBLING AND PREPARING

Disconnect the power cord first, and then
move or install the Monitor set. Otherwise
electric shock may occur.

If you install the Monitor set on a ceiling or
slanted wall, it may fall and result in severe
injury.

Use only an authorized LG wall mount
and contact the local dealer or qualified
personnel.

Do not over tighten the screws as this may
cause damage to the Monitor set and void
your warranty.

Use only screws and wall mounts that
meet the VESA standard. Any damages
or injuries by misuse or using an improper
accessory are not covered by the warranty.

Use the screws that are listed on the VESA
standard screw specifications.

The wall mount kit will include an installation
manual and necessary parts.

The wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.

The length of screws may differ depending
on the wall mount. Be sure to use the proper
length.

For more information, refer to the
instructions supplied with the wall mount.
CAUTION
NOTE
Model
E1951S
E2051S
E2251S
E1951T
E2051T
E2251T
E2351T
E2251VR
E2351VR
E2251VQ
E2351VQ
VESA (A x B) 75 x 75
Standard screw M4
Number of screws 4
Wall mount bracket
(optional)
RW120
If you intend to mount the Monitor set to a wall,
attach Wall mounting interface (optional parts) to
the back of the set.
When you install the Monitor set using the wall
mounting interface (optional parts), attach it
carefully so it will not drop.
1
Please, Use the screw and wall mount interface
in accordance with VESA Standards.
2
If you use screw longer than standard, the
monitor might be damaged internally.
3
If you use improper screw, the product might be
damaged and drop from mounted position. In
this case, LG Electronics is not responsible for it.
4
VESA compatible only with respect to screw
mounting interface dimensions and mounting
screw specifications.
5
Please use VESA standard as below.

784.8 mm (30.9 inch) and under
* Wall Mount Pad Thickness : 2.6 mm
* Screw :
Φ
4.0 mm x Pitch 0.7 mm x
Length 10 mm

787.4 mm (31.0 inch) and above
* Please use VESA standard wall mount pad
and screws.
A
B

VESA (A x B)
