Modular Under Cabinet Lighting Plug-In Installation
Installers ■ Read all instructions before installation. ■ In order to assure safe use of Lightkiwi® modular under cabinet lighting, proceed according to the installation instruction. ■ LIghtkiwi® modular under cabinet lighting is not safe to use, unless it is completely installed according to the following instructions. Caution: Always remember to turn-off the electric power when performing electric work Overview Fantastic lighting in your kitchen is simple solution for incredible makeover.
Notes 1. Each and every project is unique. These instructions are given as know approaches and general guidelines to installing our product. Your project may dictate an entirely different installation approach, which makes your installation unique. If you have questions regarding your installation please send an email to cs@lightkiwi.com or contact your local electrical contractor. 2. Keep the product away from extreme heat or cold, as well as any flammable items or damp places.
Modular LED Under Cabinet Lighting Kit generally contains 1 2 3 4 5 6 7 Lightkiwi® Modular LED Under Cabinet Lighting Panel Power Supply Dimmer Switch 4-Way Splitter Interconnect Cable Modular Connector Mounting Brackets with Screws (Standard); Mounting Screws (Lilium) 1 2 3 3 4 5 6 7 Lightkiwi® Modular LED Under Cabinet Lighting
Tools List To mount Lightkiwi® Modular LED Under Cabinet Lighting Panel, you may need tools below (not included) to make installation easier.
Before You Start To prevent any hassle after the installation, we recommend to double check every items operate properly by testing them firstly without any mounting.
Step 1: Selecting a power supply location ■ Determine where you would like to plug in your power supply. ■ Locate the power supply in a location that is accessible in the unlikely event of servicing. ■ You can have the transformer hooked up to a wall outlet that is switched or hard wire the transformer directly to a switched circuit as long as you leave access to the transformer per electrical code.
Step 2: Selecting a lighting location ■ Lay the lights out, below their intended installation location. Determine how you want the light to fall. ■ Position the lights to give the desired illumination on counter. ■ For optimal lighting, the lights should be located toward the front of the cabinet. Step 3: Install mounting brackets 1. 2. 3. 4. Establish location for mounting brackets*. Measure and mark location for pilot hole. Drill 1/16th” hole. (Optional) Mount mounting brackets.
Step 4: Mount LED light panel Snap modular LED light panel into brackets. Step 5: Connect interconnect cable 1. Connect interconnect cable between LED light panels to link all LED light panels together. 2. Use wire clips (not included) to “clean up” loose wires and hide under cabinet. (Optional) Please skip Step 6 - 7 and 9 If you do not have or need a dimmer switch. Step 6: Install dimmer switch 1. Connect dimmer switch between power supply and first LED light panels. 2.
Step 7: Mount dimmer switch 1. 2. 3. 4. Establish location for dimmer switch Measure and mark location for pilot hole. Drill 1/16th” hole. Mount dimmer switch Recommended location of dimmer switch is side or under the cabinet. Step 8: Install power supply 1. Plug power suppy into wall receptacle. 2. Connect the other end into dimmer switch. Step 9: Power up 1. Press On/Off button on dimmer switch to turn on the lights. 2. Press and hold the High or Low button to control the brightness as desired.
FAQ 1. Can I add additional LED light panel(s)? Yes. But ensure the wattage of the combined units do not exceed the maximum wattage of the power supply used. 2. Can I combine 6 inch, 12 inch LED light panels, and LED puck lights together as one lighting system? Yes. But ensure the wattage of the combined units do not exceed the maximum wattage of the power supply used. 3. How many LED light panels are needed for my cabinet? It differs from person to person.
FAQ 5. Is in line dimmer switch compatible with a wall on/off switch? Yes, in line dimmer switch would remember its previous setting of power and brightness. Therefore, it is possible to use with a wall on/off switch to control the brightness with dimmer switch and control the power with wall on/off switch. 6.
Warranty Our company provides customers with warranty of... 36 MONTHS from the date of purchase for LED light panel & power supply / 12 MONTHS from the date of purchase for all other items. Contact Us For any inquiries or comments concerning our products, please send an email to cs@lightkiwi.com, and we will respond to you as soon as possible. If there is any quality-related issue with the product, you may request a REPLACEMENT OR REFUND by submitting a request form at www.lightkiwi.
