User Guide

39W PAR30
FL
(FC) is initial footcandles at center of
beam.
Beam length (L) and beam width (W) are
to where the candlepower is reduced to
50% of center beam candlepower.
CBCP is center beam candlepower.
(C) is distance to the center of the
beam.
Performance data shown is based on
bare lamp photometrics of MasterColor
™
lamps by Philips Lighting. Contact lamp
manufacturers for availability and
performance.
Accent Lighting performance data
15’ 187 2.6’ 2.6’
20’ 105 3.5’ 3.5’
25’ 67 4.4’ 4.4’
30’ 47 5.2’ 5.2’
7’ 133 3.8’ 3.8’
10’ 65 5.4’ 5.4’
13’ 38 7.0’ 7.0’
16’ 25 8.6’ 8.6’
10’ 5.8’ 273 2.3’ 2.0’
15’ 8.7’ 121 3.5’ 3.0’
20’ 11.5’ 68 4.7’ 4.0’
25’ 14.4’ 44 5.8’ 5.1’
6’ 3.5’ 117 4.4’ 3.7’
9’ 5.2’ 52 6.6’ 5.6’
12’ 6.9’ 29 8.8’ 7.4’
15’ 8.7’ 19 11.0’ 9.9’
5’ 8.7’ 210 3.6’ 1.7’
8’ 13.9’ 82 5.7’ 2.8’
11’ 19.1’ 43 7.9’ 3.8’
14’ 24.2’ 27 10.0’ 4.9’
2’ 3.5’ 203 5.5’ 2.1’
3’ 5.2’ 90 8.2’ 3.2’
4’ 6.9’ 51 10.9’ 4.3’
5’ 8.7’ 33 13.7’ 5.4’
8’ 9.5’ 174 3.4’ 2.2’
12’ 14.3’ 77 5.1’ 3.3’
16’ 19.1’ 44 6.9’ 4.4’
20’ 23.8’ 28 8.6’ 5.5’
4’ 4.6’ 108 5.8’ 3.2’
6’ 7.2’ 48 8.7’ 6.0’
8’ 9.5’ 27 11.6’ 6.7’
10’ 11.9’ 17 14.4’ 8.3’
DFCLW
DCFCLW DCFCLW DCFCLW
Beam Spread Rated
50% Max CP CBCP Life-Hrs
9000
9000
42000
6500
39W PAR30
SP
10°
30°
39W 0° AIMING ANGLE 30° AIMING ANGLE 30° AIMING ANGLE 40˚ AIMING ANGLE
Lamp
Calculite
®
ProSpec
®
Linear Downlight PA4H3039
Page 2 of 2 4 Light PAR30 MH Series A
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
