Wireless-G Notebook Adapter Chapter 1: Introduction Welcome Thank you for choosing the Wireless-G Notebook Adapter. With this Adapter, your wireless networking experience will be faster and easier than ever. Like all wireless products, the Adapter allows for greater range and mobility within your wireless network. This adapter communicates over the 54Mbps 802.11g wireless standard, which is almost five times faster than 802.11b. But since they share the same 2.
Wireless-G Notebook Adapter What’s in this Guide? This user guide covers the steps for setting up and using the Wireless-G Notebook Adapter. • Chapter 1: Introduction This chapter describes the Adapter’s applications and this User Guide. • Chapter 2: Planning Your Wireless Network This chapter discusses a few of the basics about wireless networking. • Chapter 3: Getting to Know the Wireless-G Notebook Adapter This chapter describes the physical features of the Adapter.
Wireless-G Notebook Adapter • Appendix G: Regulatory Information This appendix supplies the Adapter’s regulatory information. • Appendix H: Contact Information This appendix provides contact information for a variety of Linksys resources, including Technical Support.
Wireless-G Notebook Adapter Chapter 2: Planning your Wireless Network Network Topology A wireless network is a group of computers, each equipped with one wireless adapter. Computers in a wireless network must be configured to share the same radio channel. Several PCs equipped with wireless cards or adapters can communicate with one another to form an ad-hoc network. topology: the physical layout of a network.
Wireless-G Notebook Adapter Network Layout Linksys wireless access points and wireless routers have been designed for use with 802.11a, 802.11b, and 802.11g products. With 802.11g products communicating with the 802.11b standard and some products incorporating both “a” and “g”, products using these standards can communicate with each other. Access points and wireless routers are compatible with 802.11a, 802.11b and 802.
Wireless-G Notebook Adapter Chapter3:GettingtoKnowtheWireless-GNotebookAdapter The LED Indicators The Network Adapter's LEDs display information about network activity. Figure 3-1: Front Panel Power Green. The Power LED lights up when the Adapter is powered on. Link Green. The Link LED lights up when the Adapter has an active connection.
Wireless-G Notebook Adapter Chapter 4: Software Installation and Configuration The Wireless Wireless-G Notebook Adapter Setup Wizard will guide you through the installation procedure. The Setup Wizard will install the WLAN Monitor and driver, as well as configure the Adapter. NOTE: You must run the Setup Wizard to install the software before installing the hardware. Insert the Setup Wizard CD-ROM into your CD-ROM drive. The Setup Wizard should run automatically, and the Welcome screen should appear.
Wireless-G Notebook Adapter The Installation Procedure 1. To install the Adapter, click the Install button on the Welcome screen. 2. After reading the License Agreement, click the Next button if you agree, or click the Cancel button to end the installation. Figure 4-2: The Setup Wizard’s License Agreement 3. The Setup Wizard will ask you to choose a network mode.
Wireless-G Notebook Adapter 4. If you chose Infrastructure Mode, go to Step 5 now. If you chose Ad-Hoc Mode, select the correct operating channel for your network. Then, select the Network Mode from the drop-down menu. Click the Next button, and go to Step 5. Click the Back button to change any settings. Channel - The channel you choose should match the channel set on the other devices in your wireless network. If you are unsure about which channel to use, select the default channel (Channel 6).
Wireless-G Notebook Adapter 6. After the software has been successfully installed, the Congratulations screen will appear. Click the Exit button. Proceed to “Chapter 5: Hardware Installation.
Wireless-G Notebook Adapter Chapter 5: Hardware Installation NOTE: You must run the Setup Wizard to install the software before installing the hardware. Connecting the Adapter 1. Turn off your notebook PC. 2. Locate an available CardBus slot on your notebook PC. 3. With the connector pin end facing the CardBus slot and the label facing up, as shown in Figure 5-1, slide the Adapter into the CardBus slot until it locks in place. 4. Restart your notebook PC.
Wireless-G Notebook Adapter Chapter 6: Using the WLAN Monitor Use the WLAN Monitor to check the link information, search for available wireless networks, or create profiles that hold different configuration settings. Accessing the WLAN Monitor After installing the Adapter, the Wireless-G Notebook Adapter WLAN Monitor icon will appear in your system tray. Double-click the icon. The Link Information screen will appear.
Wireless-G Notebook Adapter State - The status of the wireless network connection. SSID - The SSID of the wireless network. Channel - The channel to which the wireless network devices are set. Security- The status of the security feature. Network Mode - The wireless mode currently in use. IP Address - The IP Address of the Adapter. Subnet Mask - The Subnet Mask of the Adapter. Default Gateway - The Default Gateway address of the Adapter. DNS - The DNS address of the Adapter.
Wireless-G Notebook Adapter Network Statistics The Networks Statistics screen provides statistics on your current network settings. Transmit Rate - The data transfer rate of the current connection.(In Auto mode, the Adapter dynamically shifts to the fastest data transfer rate possible at any given time.) Receive Rate - The rate that data is received. Authentication - The current security authentication mode. Network Mode - The mode of the wireless network currently in use.
Wireless-G Notebook Adapter Site Survey The Site Survey screen displays a list of infrastructure and ad-hoc networks available for connection in the table on the right. This table shows the network’s SSID, Channel, and the quality of the wireless signal the Adapter is receiving. You may click SSID, Channel, or Signal, to sort by that field. Site Information For each network selected, the following settings are listed: Network Type - The wireless mode currently in use.
Wireless-G Notebook Adapter Profiles The Profiles screen lets you save different configuration profiles for different network setups. The table on the right displays a list of infrastructure and ad-hoc networks available for connection This table shows the network’s profile name and the wireless network’s SSID, as set in the connection profile. Profile Information For each profile selected, the following are listed: Network Mode - The mode of the wireless network currently in use.
Wireless-G Notebook Adapter NOTE: If you want to export more than one profile, you have to export them one at a time. Figure 6-8: Exporting a Profile Creating a New Profile 1. On the Profiles screen, click the New button to create a new profile. 2. Enter a name for the new profile, and click the OK button. Click the Cancel button to return to the Profiles screen without entering a name.
Wireless-G Notebook Adapter 3. The Choose a network type screen shows a choice of two wireless modes. Click the Infrastructure Mode radio button if you want your wireless computers to communicate with computers on your wired network via a wireless access point. Click the Ad-Hoc Mode radio button if you want multiple wireless computers to communicate directly with each other. Enter the SSID for your network. Click the Next button to continue or the Back button to return to the previous screen.
Wireless-G Notebook Adapter 5. The Network Setting screen will appear next. If your network has a DHCP server, click the radio button next to Obtain an IP address automatically (DHCP). Click the Next button to continue, or click the Cancel button to return to the Profiles screen. If your network does not have a DHCP server, click the radio button next to Specify the IP Setting. Enter an IP Address, Subnet Mask, Default Gateway, and DNS appropriate for your network.
Wireless-G Notebook Adapter Transmit Key - The default transmit key number is 1. If your network’s access point or wireless router uses transmit key number 2, 3, or 4, select the appropriate number from the Transmit Key drop-down box. Key 1- The WEP key you enter must match the WEP key of your wireless network. If you are using 64-bit WEP encryption, then the key must consist of exactly 10 hexadecimal characters.
Wireless-G Notebook Adapter Select the type of algorithm, TKIP or AES, for the Encryption Type. Enter a WPA Shared Key of 8-63 characters in the Passphrase field.
Wireless-G Notebook Adapter WPA RADIUS. WPA RADIUS features WPA used in coordination with a RADIUS server. (This should only be used when a RADIUS server is connected to the Router.) WPA Radius offers two encryption methods, TKIP and AES, with dynamic encryption keys. It offers five authentication methods: EAP-TLS, EAP-TTLS, EAP-MD5, EAP-PEAP, and LEAP. Click the Next button to continue and the screen in Figure 6-19 appears. Click the Back button to return to the previous screen.
Wireless-G Notebook Adapter The screen in Figure 6-20 appears next. Select the Authentication Method from the drop-down menu. The options are described below. EAP-TLS Enter the Login name of your wireless network in the Login Name field. From the Certificate drop-down menu, select the certificate you have installed to authenticate you on your wireless network. Select Validate server cerificate to make sure that the certificate for the server is valid. Click the Next button to continue.
Wireless-G Notebook Adapter EAP-MD5 Enter the Login name of your wireless network in the Login Name field. Enter the password of your wireless network in the Password field. Click the Next button to continue. Click the Back button to return to the previous screen. EAP-PEAP Figure 6-22: EAP-MD5 Authentication Enter the Login name of your wireless network in the Login Name field. Enter the password of your wireless network in the Password field.
Wireless-G Notebook Adapter RADIUS RADIUS features WPA used in coordination with a RADIUS server. (This should only be used when a RADIUS server is connected to the Router.) It offers five authentication methods: EAP-TLS, EAP-TTLS, EAP-MD5, EAPPEAP, and LEAP. Click the Next button to continue and the screen in Figure 6-19 appears. Click the Back button to return to the previous screen. The screen in Figure 6-26 appears next. Select the Authentication Method from the drop-down menu.
Wireless-G Notebook Adapter EAP-TTLS Enter the Login name of your wireless network in the Login Name field. Enter the password of your wireless network in the Password field. Select Validate server cerificate to make sure that the certificate for the server is valid. Select the TTLS Protocol from the drop-down menu. Click the Next button to continue. Click the Back button to return to the previous screen.
Wireless-G Notebook Adapter EAP-PEAP Enter the Login name of your wireless network in the Login Name field. Enter the password of your wireless network in the Password field. Select Validate server cerificate to make sure that the certificate for the server is valid. Then, select the Peap Inner EAP from the drop-down menu. Click the Next button to continue. Click the Back button to return to the previous screen.
Wireless-G Notebook Adapter 7. The Confirm New Settings screen will appear next showing the new settings. To save the new settings, click the Yes button. To edit the new settings, click the Back button. Figure 6-31: Confirm New Settings for New Profile 8. The Congratulations screen will appear next. Click Activate new settings now to implement the new settings immediately and return to the Link Information screen.
Wireless-G Notebook Adapter Appendix A: Troubleshooting This appendix consists of two parts: “Common Problems and Solutions” and “Frequently Asked Questions.” This appendix provides solutions to problems that may occur during the installation and operation of the Wireless-G Notebook Adapter. Read the description below to solve your problems. If you can't find an answer here, check the Linksys website at www.linksys.com. Common Problems and Solutions 1.
Wireless-G Notebook Adapter Frequently Asked Questions Can I run an application from a remote computer over the wireless network? This will depend on whether or not the application is designed to be used over a network. Consult the application’s user guide to determine if it supports operation over a network. Can I play computer games with other members of the wireless network? Yes, as long as the game supports multiple players over a LAN (local area network).
Wireless-G Notebook Adapter maintain contact with the wireless network even when not actually transmitting data. Achieving these functions simultaneously requires a dynamic RF networking technology that links access points and nodes. In such a system, the user’s end node undertakes a search for the best possible access to the system.
Wireless-G Notebook Adapter Would the information be intercepted while transmitting on air? WLAN features two-fold protection in security. On the hardware side, as with Direct Sequence Spread Spectrum technology, it has the inherent security feature of scrambling. On the software side, WLAN offers the encryption function (WEP) to enhance security and access control. What is WEP? WEP is Wired Equivalent Privacy, a data privacy mechanism based on a shared key algorithm, as described in the IEEE 802.
Wireless-G Notebook Adapter Appendix B: Wireless Security Linksys wants to make wireless networking as safe and easy for you as possible. The current generation of Linksys products provide several network security features, but they require specific action on your part for implementation. So, keep the following in mind whenever you are setting up or using your wireless network.
Wireless-G Notebook Adapter 1. Disable Broadcast 2. Make it unique 3. Change it often Most wireless networking devices will give you the option of broadcasting the SSID. While this option may be more convenient, it allows anyone to log into your wireless network. This includes hackers. So, don’t broadcast the SSID. Wireless networking products come with a default SSID set by the factory. (The Linksys default SSID is “linksys”.) Hackers know these defaults and can check these against your network.
Wireless-G Notebook Adapter WPA-PSK. If you do not have a RADIUS server, Select the type of algorithm, TKIP or AES, and enter a password in the Passphrase field of 8-63 characters. WPA RADIUS. WPA used in coordination with a RADIUS server. (This should only be used when a RADIUS server is connected to the Router or other device.) WPA Radius offers two encryption methods, TKIP and AES, with dynamic encryption keys. RADIUS. WEP used in coordination with a RADIUS server.
Wireless-G Notebook Adapter Appendix C: Windows Help All wireless products require Microsoft Windows. Windows is the most used operating system in the world and comes with many features that help make networking easier. These features can be accessed through Windows Help and are described in this appendix. TCP/IP Before a computer can communicate with an access point or wireless router, TCP/IP must be enabled. TCP/IP is a set of instructions, or protocol, all PCs follow to communicate over a network.
Wireless-G Notebook Adapter Appendix D: Glossary 802.11b - An IEEE wireless networking standard that specifies a maximum data transfer rate of 11Mbps and an operating frequency of 2.4GHz. Adapter - A device that adds network functionality to your PC. Ad-hoc - A group of wireless devices communicating directly with each other (peer-to-peer) without the use of an access point. Backbone - The part of a network that connects most of the systems and networks together, and handles the most data.
Wireless-G Notebook Adapter Fragmentation -Breaking a packet into smaller units when transmitting over a network medium that cannot support the original size of the packet. Hardware - The physical aspect of computers, telecommunications, and other information technology devices. IEEE (The Institute of Electrical and Electronics Engineers) - An independent institute that develops networking standards. Infrastructure - A wireless network that is bridged to a wired network via an access point.
Wireless-G Notebook Adapter Server - Any computer whose function in a network is to provide user access to files, printing, communications, and other services. Software - Instructions for the computer. A series of instructions that performs a particular task is called a "program". Spread Spectrum - Wideband radio frequency technique used for more reliable and secure data transmission. SSID (Service Set IDentifier) - Your wireless network's name.
Wireless-G Notebook Adapter Appendix E: Specifications Standards IEEE 802.11g, IEEE 802.11b Channels 11 Channels (USA, Canada) 13 Channels (Europe) 14 Channels (Japan) LEDs Power, Link Transmit Power 15 dBm Protocols 802.11b: CCK (11 Mbps), DQPSK (2 Mbps), DBPSK (1 Mbps); 802.11g: OFDM Network Protocols TCP/IP, IPX/SPX, NetBEUI Security Features WEP, AES, TKIP, 802.1x WEP Key Bits 64, 128 Bit Dimensions 4.53" x 2.13" x 0.30" (115 mm x 54 mm x 7.5 mm) Unit Weight 1.66 oz. (0.047 kg.
