Specification

Specications
Length: 24 (60.9)
Width: 24 (60.9)
Depth: 4-1/2 (11.4)
Weight: 16 lbs (7.3 kg)
All dimensions are inches (centimeters) unless otherwise specied.
FEATURES & SPECIFICATIONS
INTENDED USE — High performance parabolic luminaires for use in open area applications and
electronic oces where optical control, visual comfort and light cut-o are important.
Design optimized for use with T8 lamps and low-prole electronic ballasts.
Choice of diuse or specular louvers utilizing the latest developments in louver nishing for minimized
louver iridescence.
CONSTRUCTION — Black reveal provides oating louver appearance, conceals optional air-supply slots.
Square corner end plates improve strength and durability.
Integral T-bar safety clips hold xture to T-bar securely; no fasteners required.
Heavy-gauge hinges die-formed for maximum strength; spring action latches concealed in black reveal.
Housing formed from cold-rolled steel. Louver formed from anodized aluminum. No asbestos used in
this product.
Overlapping ange and modular ceiling trims available factory installed with swing gate hangers or eld
convertible with optional trim and hangers.
FINISH — Five-stage iron-phosphate pretreatment ensures superior paint adhesion. Painted parts
nished with high-gloss, baked white enamel.
ELECTRICAL SYSTEM — Thermally protected, resetting, Class P, HPF, non-PCB, UL Listed, CSA certied
ballast is standard.
Electronic ballasts are sound rated A.
Ballast disconnect provided standard where required to comply with US and Canadian electrical codes.
Fixture conforms to UL1570 and is suitable for damp locations. AWM, TFN or THHN wire used throughout,
rated for required temperatures.
LISTING — UL Listed (Standard), CSA Certied or NOM Certied (see Options).
WARRANTY — 1-year limited warranty. Complete warranty terms located at
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
Actual performance may dier as a result of end-user environment and application.
Note: Specications subject to change without notice.
2PM3N 17
Series Trim type Air function
Number of
lamps Lamp type
Number of
cells
1
Louver nish Voltage
2PM3N Paramax
3" louver
family
G Grid
F Overlapping
ange
ST Screw slot
B No air function
A Air supply/return (slots in
side trim)
D Dual function supply/
return/removal
2
3
4
(Not included)
17 17W T8 (24") 6
9
12
16
LD Low iridescent anodized
diuse silver
LS Low iridescent anodized
specular silver
MVOLT
2
120
277
347
(Others available)
ORDERING INFORMATION
For shortest lead times, congure products using bolded options.
Example: 2PM3N G B 3 17 9LD MVOLT 1/3 GEB10IS
Catalog
Number
Notes
Type
FLUORESCENT 2PM3N-2X2
Options
3
1/3 One 3-lamp ballast
1/4 One 4-lamp ballast
1/41/2 Use with LST. One 4-lamp and one 2-lamp ballast
GEB10IS Electronic ballast, <10% THD, instant start
GEB10PS Electronic ballast, <10% THD, programmed start
GEB10RS Electronic ballast, <10% THD, rapid start
EL Emergency battery pack (nominal 300 lumens; see
Fluorescent Battery Packs tab)
2
EL14 Emergency battery pack
PWS1836 6' prewire, 3/8" dia., 18-gauge, 3 wires
PWS1846 6' prewire, 3/8" dia., 18-gauge, 4 wires
QFC213_ Reloc Quick-Flex 12/3G, 13'
4,5
LST Tandem xture pairs (shared ballasts)
LP__ Lamped, specify lamp type and color
GLR Internal fast-blow fuse
5
GMF Internal slow-blow fuse
5
ACS Air closure strips (A and D models only)
APB Air-pattern control blades (A and D models only)
PAF Painted after fabrication (white enamel)
2R Two reector channel covers
6
JP Palletized and stretch-wrapped (G trim only)
CSA CSA certied
NOM NOM certied
PARAMAX
®
Parabolic Troer
2PM3N 2'x2'
3" Louver Family
Straight Lamps
Notes
1 Standard louver conguration:
2 lamps = 6 cells, diuse silver
3 lamps = 9 cells, diuse silver
4 lamps = 16 cells, diuse silver
2 MVOLT standard for 120V and 277V applications. Some options require voltage specied.
3 Some options increase xture depth. Consult factory if plenum space is a concern.
4 Must specify circuit wiring. Refer to www.lithonia.com/Reloc for additional information.
5 Must specify voltage.
6 Available with 3-lamp versions only.
24
(61.0)
4-1/2
(11.4)
24
(61.0)
