Specification
MOUNTING DATA
2PM3N 2'x2' Straight Lamps, 3" Louver Family
DIMENSIONS
2PM3N-2X2
FLUORESCENT One Lithonia Way Conyers, GA 30012 Phone: 800-315-4963 Fax: 770-981-8191 www.lithonia.com ©1997-2014 Acuity Brands Lighting, Inc. All rights reserved. Rev. 07/30/14
Overlapping Flanged Trim
with swing-gate hangers
F
Lay-in Grid (exposed or
concealed grid)
G
Screw or bolt slot grid
ST
Continuous row mounting of anged units requires CRE and CRM trim options. Consult factory.
Notes
1 Recommended rough-in dimensions for F trim xtures 24"x24". (Tolerance is +1/4", -O”.) Swing-gate
range 1" to 4-3/16", span 23-1/2" to 26-5/16".
PHOTOMETRICS
Full photometric data available upon request.
4-1/2
(11.4)
3-1/2
(8.9)
2-13/16
(7.1)
24
(60.9)
24
(60.9)
24
(60.9)
4-1/2
(11.4)3-1/2
(8.9)
2-13/16
(7.1)
4-1/2
(11.4)
3-1/2
(8.9)
2-13/16
(7.1)
Coefficients of Utilization
%02fp
pc 80%50% 30%
pw 50%30% 10%50% 30%10% 50%30% 10%
0
1
2
3
4
5
6
7
8
9
10
90
81
71
63
56
50
45
41
37
34
31
90
78
67
57
50
43
38
34
31
28
25
90
75
63
53
45
39
34
30
26
23
21
84
76
67
60
53
48
43
39
35
32
30
84
74
64
55
48
42
37
33
30
27
25
84
72
61
52
44
38
33
29
26
23
21
80
73
65
58
51
46
42
38
34
32
29
80
71
62
54
47
41
37
33
29
27
24
80
70
59
51
44
38
33
29
26
23
21
RCR
Zonal Lumen Summary
Zone Lumens % Lamp % Fixture
0° - 30°
0° - 40°
0° - 60°
0° - 90°
90° - 180°
0° - 180°
563.4
964.5
1853.1
2040.2
0.0
2040.2
20.9
35.7
68.6
75.6
0.0
75.6
27.6
47.3
90.8
100.0
0.0
100.0
LTL15075TEST NO:
2PM3N 217 6
LUMENS PER LAMP: 1350
Coefficients of Utilization
%02fp
pc 80%50% 30%
pw 50%30% 10%50% 30%10% 50%30% 10%
0
1
2
3
4
5
6
7
8
9
10
82
74
66
59
53
47
43
39
35
32
30
82
72
62
54
47
42
37
33
30
27
25
82
69
59
50
43
37
33
29
26
23
21
77
70
62
56
50
45
41
37
34
31
29
77
68
59
52
46
40
36
32
29
26
24
77
66
57
49
42
37
32
29
26
23
21
73
67
60
54
48
44
40
36
33
31
28
73
65
58
51
45
40
35
32
29
26
24
73
64
55
48
42
36
32
29
26
23
21
RCR
Zonal Lumen Summary
Zone Lumens % Lamp % Fixture
0° - 30°
0° - 40°
0° - 60°
0° - 90°
90° - 180°
0° - 180°
880.3
1516.3
2576.7
2793.9
0.0
2793.9
21.7
37.4
63.6
69.0
0.0
69.0
31.5
54.3
92.2
100.0
0.0
100.0
LTL15074TEST NO:
2PM3N 317
LUMENS PER LAMP: 1350
Coefficients of Utilization
%02fp
pc 80%50% 30%
pw 50%30% 10%50% 30%10% 50%30% 10%
0
1
2
3
4
5
6
7
8
9
10
75
67
61
54
49
44
40
37
33
31
28
75
65
57
50
44
39
35
32
29
26
24
75
64
54
47
40
36
31
28
25
23
21
70
63
57
52
47
42
38
35
32
30
28
70
62
55
48
43
38
34
31
28
26
23
70
61
52
45
40
35
31
28
25
23
21
67
61
55
50
45
41
37
34
32
29
27
67
60
53
47
42
37
34
30
28
25
23
67
59
51
45
39
35
31
28
25
23
21
RCR
Zonal Lumen Summary
Zone Lumens % Lamp % Fixture
0° - 30°
0° - 40°
0° - 60°
0° - 90°
90° - 180°
0° - 180°
1224.9
1994.0
3191.9
3384.0
0.0
3384.0
22.7
36.9
59.1
62.7
0.0
62.7
36.2
58.9
94.3
100.0
0.0
100.0
LTL15076TEST NO:
2PM3N 417
LUMENS PER LAMP: 1350
Mounting Information - Trim Types
Ceiling type Appropriate trim type
Exposed grid tee G
Concealed grid tee G,ST
Concealed Z-spline F
Screw slot (consult factory) ST
Acoustical tile, plaster or plasterboard on rigid support parallel to lamps F
All dimensions are inches (centimeters) unless specied otherwise.
