Specification Sheet

BLT Tunable White Volumetric Recessed Lighting 1'x4'
BLT1X4NTUNE
LED: One Lithonia Way Conyers, GA 30012 Phone: [phone] Fax: [phone] www.lithonia.com © 2015-2016 Acuity Brands Lighting, Inc. All rights reserved. Rev. 04/19/16
ORDERING INFORMATION
Lead times will vary depending on options selected. Consult with your sales representative.
Example: BLT4 TUWH PROR 30L ADP NLT
BLT4
Series Dynamic feature Dynamic range Lumens
1
Diffuser Voltage
BLT4 1x4 BLT TUWH Tunable white PROR Productivity range
(3000-5000K)
20L 2000
30L 3000
40L 4000
48L 4800
60L 6000
ADP Curved, linear prisms
ADSM Curved, smooth
SDP Square, linear prisms
SDSM Square, smooth
Diffusers w/ trim rings
ADPT Curved, linear prisms
ADSMT Curved, smooth
SDPT Square, linear prisms
SDSMT Square, smooth
(blank) MVOLT
120 120
277 277
347 347
2
Control interface type Occupancy control
4
Options
NLT
nLight nTune interface
3
(blank) No sensor control
nLight Wired Networking
NES7 nLight™ nES 7 PIR integral occupancy sensor
NESPDT7 nLight™ nES PDT 7 dual technology integral
occupancy control
NES7ADCX nLight™ nES 7 ADCX PIR integral occupancy
sensor with automatic dimming photocell
NESPDT7ADCX nLight™ nES PDT 7 dual technology integral
occupancy sensor with automatic dimming
photocell
EL7L 700 lumen battery pack
5
EL14L 1400 lumen battery pack
5
BGTD Bodine Generator Transfer Device
6
PWS1836 6’ pre-wire, 3/8” diameter, 18 gauge, 1 circuit
PWS1846 6’ pre-wire, 3/8” diameter, 18 gauge, 2 circuit
GLR Fast-blowing fuse
7
GMF Slow-blowing fuse
7
NPLT Narrow pallet
RRL_ RELOC®-ready luminaire
8
LATC Earthquake clip
DWAM Anti-Microbial paint
Notes
1 Approximate lumen output.
2 Not available with SLD,EL7L or EL14L battery packs.
3 Requires power from nLight network bridge or NPS 80.
4 Must specify diffuser with trims rings. See sensor options in ordering information.
5 When using pre-wire option, use PWS1846.
6 Requires BSE labeling. Consult factory for options.
7 Must specify voltage, 120 or 277 with GLR & GMF fusing.
8 For ordering logic consult: RRL_2013.
Accessories: Order as separate catalog number.
DGA14 Drywall grid adapter for 1x4 recessed fixture
Replacement Parts: Order as separate catalog number.
*237LKE DBLT48 ADP LENS ASSEMBLY 4 ft. replacement lens (light traps included)
*237LKL DBLT48 SDP LENS ASSEMBLY 4 ft. replacement lens (light traps included)
*237LL2 DBLT48 ADSM LENS ASSEMBLY 4 ft. replacement lens (light traps included)
*237LLA DBLT48 SDSM LENS ASSEMBLY 4 ft. replacement lens (light traps included)
*237LT2 DBLT48 ADPT LENS ASSEMBLY 4 ft. replacement lens (trims included)
*237LT4 DBLT48 SDPT LENS ASSEMBLY 4 ft. replacement lens (trims included)
*237LT6 DBLT48 ADSMT LENS ASSEMBLY 4 ft. replacement lens (trims included)
*237LT8 DBLT48 SDSMT LENS ASSEMBLY 4 ft. replacement lens (trims included)
*237LTA DBLT48 ADPT SENSOR LENS ASSEMBLY 4 ft. replacement lens (trims included)
*237M52 DBLT48 SDPT SENSOR LENS ASSEMBLY 4 ft. replacement lens (trims included)
*237M5A DBLT48 ADSMT SENSOR LENS ASSEMBLY 4 ft. replacement lens (trims included)
*237M5L DBLT48 SDSMT SENSOR LENS ASSEMBLY 4 ft. replacement lens (trims included)
nLight® Control Accessories:
Order as separate catalog number. Visit www.acuitybrands.com/products/controls/nlight.
WallPod stations Model number Occupancy sensors Model number
On/Off nPODM Small motion 360°, ceiling (PIR / dual tech) nCM 9 RJB / nCM PDT 9 RJB
On/Off & raise/lower nPODM DX Large motion 360°, ceiling (PIR / dual tech) nCM10 RJB / nCM PDT 10 RJB
Wall switch with raise/lower nWSX PDT LV DX [color]
Photocell controls Model number Cat-5 cable (plenum rated) Model number
Full range dimming nCM ADCX RJB 10' cable CAT5 10FT J1
30' cable CAT5 30FT J1
Power Supply
nLight Power Supply nPS 80
