FEATURES & SPECIFICATIONS

INTENDED USE — The CLX is a linear lighting solution that is available in multiple lengths, lumen

packages and distributions. Designed for versatility, the CLX can address virtually any indoor lighting

need. The CLX is also oﬀered in standard and high eﬃcacy conﬁgurations and capable of being continuous

row mounted or installed as a stand-alone ﬁxture. Ideal for uplight and downlight in commercial,

retail, manufacturing, warehouse, and display applications. Certain airborne contaminants can

diminish the integrity of acrylic and/or polycarbonate. Click here for Acrylic-Polycarbonate

Compatibility table for suitable uses.

CONSTRUCTION — Channel and cover are formed from code-gauge cold-rolled steel.

Finish: Paint options include high-gloss, baked white polyester (WH), galvanized (GALV), matte

black (MB) and smoke gray (SKGY). Five-stage iron phosphate pre-treatment ensures superior paint

adhesion and rust resistance. Housing and lens endcaps are injection molded plastic to provide a more

architectural look and feel. The endcaps come standard with a knock out for continuous mounting but

can be ordered without.

OPTICS — Oﬀered in lens and less lens conﬁgurations. Provides a choice of optical distributions

including, wide, narrow, and aisle.

ELECTRICAL — Utilizes high-output LEDs integrated on a two-layer circuit board, ensuring cool-

running operation. Optional internal pluggable wiring harness for reduced labor cost in row mounting

applications. (See PLR_ ordering information on page 8.) Electronic LED driver is rated for 75 input watts

maximum (see Operational Data on page two for actual wattage consumption), multi-volt input and

0-10V dimming standard. This ﬁxture is designed to withstand a maximum line surge of 2.5kV at 0.75kA

combination wave for indoor locations, for applications requiring higher level of protection additional

surge protection must be provided.

Enabled with Atrius™ - The CLX is enabled with Atrius™, making it part of the Atrius™ Sensory Network

and ready to deliver valuable data and connectivity to the Atrius™ Platform. For more information

concerning Atrius™ solutions, please refer to www.acuitybrands.com/atrius.

LEDs provide nominal 80 CRI or 90CRI at 3000 K, 3500 K,4000 K, or 5000 K.

Lumen output up to 2,500 lumens per foot.

INSTALLATION — Fixture may be ceiling or wall mounted (with or without THCLX hanger or angle

mounted with CLXANGBRT), pendant or stem mounted with appropriate mounting options.

LISTINGS — CSA certiﬁed to US and Canadian safety standards. For use in damp locations between -4°F

(-20°C) and 104°F (40°C). Optional High Ambeint (HA) ranging to 122°F(50°C) available on certian lumen

packages.

WARRANTY — 5-year limited warranty. Complete warranty terms located at:

www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx

Note: Actual performance may diﬀer as a result of end-user environment and application.

All values are design or typical values, measured under laboratory conditions at 25 °C.

Speciﬁcations subject to change without notice.

LED Linear

CLX

24", 36", 48" and 96" Lengths

Catalog

Number

Notes

Type

INDUSTRIAL IBG

Flat Diﬀuse Lens

Round Diﬀuse Lens

Wide Diﬀuse Lens

Stock configurations are offered for shorter lead times:

Stock Part Number UPC

CLX L48 3000LM FDL MVOLT 40K 80CRI WH

00191723525816

CLX L48 3000LM FDL MVOLT 50K 80CRI WH 00191723525885

CLX L48 5000LM FDL MVOLT 40K 80CRI WH 00191723525939

CLX L48 5000LM FDL MVOLT 50K 80CRI WH 00191723525908

CLX L96 6000LM FDL MVOLT 40K 80CRI WH 00191723525861

CLX L96 6000LM FDL MVOLT 50K 80CRI WH 00191723525915

CLX L96 10000LM FDL MVOLT 40K 80CRI WH 00191723525922

CLX L96 10000LM FDL MVOLT 50K 80CRI WH 00191723525830

CLX L48 3000LM RDL MVOLT 40K 80CRI WH 00191723525960

CLX L48 3000LM RDL MVOLT 50K 80CRI WH 00191723525892

CLX L48 5000LM RDL MVOLT 40K 80CRI WH 00191723525854

CLX L48 5000LM RDL MVOLT 50K 80CRI WH 00191723525946

CLX L96 6000LM RDL MVOLT 40K 80CRI WH 00191723525878

CLX L96 6000LM RDL MVOLT 50K 80CRI WH 00191723525823

CLX L96 10000LM RDL MVOLT 40K 80CRI WH 00191723525953

CLX L96 10000LM RDL MVOLT 50K 80CRI WH 00191723525847

ENABLED WITH

Summary of content (9 pages)

PAGE 1
Catalog Number Notes FEATURES & SPECIFICATIONS INTENDED USE — The CLX is a linear lighting solution that is available in multiple lengths, lumen packages and distributions. Designed for versatility, the CLX can address virtually any indoor lighting need. The CLX is also offered in standard and high efficacy configurations and capable of being continuous row mounted or installed as a stand-alone fixture.
PAGE 2
CLX LED Linear ORDERING INFORMATION Series Length CLX LED linear L24 Nominal lumens1 Performance package Louver 24"1,2,3 1500LM 2000LM 2500LM 3500LM 4500LM 5000LM 1,500 lumens 2,000 lumens 2,500 lumens 3,500 lumens 4,500 lumens 5,000 lumens SEF HEF (Blank) SBLW SBLMB SBLGV SBLSKGY L36 36"1,3 2250LM 3000LM 3750LM 5250LM 6750LM 7500LM 2,250 lumens 3,000 lumens 3,750 lumens 5,250 lumens 6,750 lumens 7,500 lumens L48 48" 3000LM 4000LM 5000LM 7000LM 9000LM 10000LM 3,000 lumens 4,000 lumens 5,
PAGE 3
CLX LED Linear Accessories: Order as separate catalog number.
PAGE 4
CLX LED Linear CLX OPERATIONAL DATA Length L24 L36 FDL L48 L96 L24 L36 RDL L48 L96 L24 L36 WDL L48 Delivered Lumens Nominal lumen package Performance package CRI 2500LM SEF 80 Wattage Color Temperature 3000K 3500K 4000K 5000K 2307 2372 2437 2495 18.41 5000LM SEF 80 4722 4855 4989 5107 41.48 3750LM SEF 80 3536 3636 3736 3825 26.47 7500LM SEF 80 6652 6840 7027 7194 62.6 5000LM SEF 80 4451 4576 4702 4813 34.8 10000LM SEF 80 9082 9338 9594 9822 73.
PAGE 5
CLX LED Linear CLX CHARACTERISTICS Wattage Lumen package Standard efficiency Length High efficiency 120V 277V 347V 480V 120V 277V 347V 480V 19.9 19.9 25.9 25.9 18.5 18.5 24.5 24.5 41.9 41.9 47.9 47.9 37.9 37.9 43.9 43.9 28.1 28.1 34.1 34.1 27.0 27.0 33.0 33.0 62.9 62.9 68.9 68.9 56.8 56.8 62.8 62.8 35.4 35.4 41.4 41.4 32.9 32.9 38.9 38.9 77.1 77.1 83.1 83.1 70.4 70.4 76.4 76.4 70.8 70.8 76.8 76.8 65.8 65.8 71.8 71.8 154.2 154.2 160.
PAGE 6
CLX LED Linear DIMENSIONS PALLET DIMENSIONS All dimensions are in inches (centimeters) unless otherwise indicated. Dimensions may vary with options or accessories. 8 7 Length 6 5 4 THCLX - SHIPS TWO PER ORDER, UTILIZES A #8 HEX HEAD SCREW AND NUT FIXTURE SITS 1.3 INCHES FROM STRUCTURE WHEN MOUNTED F Approx Weight Fixtures per pallet Pallet Dims L24 4 lb 100 54x46x37 L36 5 lb 80 54x46x37 L48 7.
PAGE 7
CLX LED Linear RRL - RELOC®-Ready Luminaire • • • • • RRL connectors can be used with Quick-Flex®, System 820 and OnePass® systems. Load side of connector factory installed to luminaire. 4-pole mating connector with push-in terminations allows for simple installation. Touch-safe design on both halves meets UL/CSA requirement. Wiping contact design allows safe disconnect under load. ORDERING INFORMATION Lead times will vary depending on options selected. Consult with your sales representative.
PAGE 8
CLX LED Linear PRODUCT INFORMATION Wiring Advanced plug-in system with three-circuit capability. Available on industrial and strip products and a variety of architectural products mounted in continuous rows. 1, 2, 3 and 4-lamp fixtures. PLR22 (2-circuit) and PLR33 (3-circuit) crossover harness switches hot circuit serving next fixture in row. Reduces fixture types on job for alternating circuit applications (see example below.) Easy one-step installation, saves up to 35% on labor costs.
PAGE 9
CLX LED Linear OPTIONS AND ACCESSORIES Narrow refl ector Ships separate from fi xture. Order as: CLXRN24 CLXRN36 CLXRN48 CLXRN96 Wide decorative refl ector Ships separtely from fi xture. Order as: CLXRW24 CLXRW36 CLXRW48 CLXRW96 Wireguard Ships separately from fi xture: 96" fi xture requires two WGCLX48. Order as: WGCLX24 WGCLX36 WGCLX48 Aircraft Cable with Canopy Available in 120" or 240" Order as: ZAC120 ZAC240 HANGER CHAIN 36" chain with Y hanger.
