Specification

Commercial Track Lighting
9000 SERIES
Front Loading Trackhead
PAR20, PAR30 and PAR38 Lamps
FEATURES & SPECIFICATIONS
INTENDED USE
This fresh and innovative track head combines aesthetics with superior functionality for applications such as
specialty retail, grocery, galleries, museums, hospitality, residential and educational environments. The 9000
Series provides high-quality, eco-friendly lighting solutions.
CONSTRUCTION
Lamp Holder: This low-prole lamp holder is made of die-cast aluminum.
Available in white, black or brushed nickel.
Adaptor: Low-prole injection-molded track mounting adaptor for easy attachment to Lithonia Commercial
(LT) track system. Snap lock secures adaptor to track. Adaptor also compatible with Nordic Aluminum Global
(GES & GET) Track Systems. Adaptors have been evaluated and tested in accordance to UL1574 Track System
Standards. Adjustable adaptor contacts can be positioned for track circuit 1 or 2.
Note: Lithonia Decorative Track Lighting components are not compatible with Lithonia
Commercial Track Lighting components. Installation of mixed components will result in risk of
shock hazard or re, damage of xture, failure to illuminate, and it does not meet UL standards.
ELECTRICAL
PAR20, PAR30 and PAR38 styles use an E26 medium base 120V porcelain socket.
LISTINGS
C
ETL
US
listed to UL1574 Track Lighting Standard.
WARRANTY
One-year limited warranty. Complete warranty terms located at:
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx.
Note: Specications subject to change without notice.
Actual performance may dier as a result of end-user environment and application.
LTH9000
Series Track head size
1
Finish
LTH9000 Front loading trackhead
PAR20
PAR20 compatible LED, 50W halogen maximum
PAR30
PAR30 long-neck compatible LED, 75W halogen maximum
PAR38
PAR38 compatible LED, 120W halogen maximum
WH White
DBL Black
BN Brushed nickel
ORDERING INFORMATION
All congurations of this product are considered “standard” and have short lead times.
Example: LTH9000 PAR20 WH
H
L
W
Specification
Lamp
designation
Width Length
Maximum
height
PAR20 3-5/16 4 8
PAR30 4-1/2 5 8-5/16
PAR38 5-1/2 5-1/2 9-5/8
All dimensions are inches (centimeters).
Catalog
Number
Notes
Type
LTH9000
COMMERCIAL TRACK LIGHTING One Lithonia Way Conyers, GA 30012 Phone: [phone] Fax: [phone] www.lithonia.com © 2012-2014 Acuity Brands, Inc. All rights reserved. Rev. 11/20/14
Notes
1. Lamp supplied by others.
