Technical Specifications

FEATURES & SPECIFICATIONS
INTENDED USE
Provides maintenance-free general illumination for outdoor use in residential and commercial applications
such as retail, education, multi-unit housing and storage. Ideal for lighting building facades, parking
areas, walkways, garages, loading areas and any other outdoor space requiring reliable security lighting.
CONSTRUCTION
Sturdy weather-resistant aluminum housing with a dark bronze nish.
High performance LEDs are powered by an MVOLT driver providing 2720 and 3970 delivered lumens at
5000K. 100,000 hours LED lifespan based on IESNA LM-80-08 results and calculated per IESNA TM-21-11
methodology. Fixture is maintenance-free.
Rated for outdoor installations -40°C minimum ambient.
Adjustable Dusk-to-Dawn, photocell standard automatically turns light on at dusk and o at dawn for
convenience and energy savings.
Photocell can be disabled by rotating the photocell cover.
OPTICS
Precision-molded acrylic lenses provide optimal luminaire spacing with Type 3 distribution.
Nighttime Friendly™ full cuto above 90° angle, standard.
INSTALLATION
Wall or arm mount (mounting arm sold separately).
All mounting hardware included.
LISTINGS
UL Certied to US safety standards. C-UL Certied to Canadian safety standards. Wet location listed.
Tested in accordance with IESNA LM-79 and LM-80 standards. DLC qualied product.
WARRANTY
5-year limited warranty. Complete warranty terms located at
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
NOTE: Specications are subject to change without notice.
OLW
Series Lumens / Color temperature (CCT) Voltage Features Finish
OLW LED Wall Light
23 2720 delivered lumens / 5000K
1
31 3970 delivered lumens / 5000K
1
(blank) MVOLT (120V-277V) (blank) Photocell included (blank) DDB Dark Bronze
ORDERING INFORMATION
For shortest lead times, congure products using bolded options.
Example: OLW 23
Accessories: Order as separate catalog number.
OMA DDB M6 14” Steel mounting arm
Outdoor General Purpose
OLW
LED WALL PACK
Specications
All dimensions are inches (centimeters)
14-7/8
(37.8)
2-5/8
(6.7)
2-3/16
(5.6)
9-7/8
(25.1)
4-3/8
(11.1)
9-7/8
(25.1)
Notes
1 Correlated Color Temperature (CCT) shown is nominal per ANSI C78,377-2008.
COMMERCIAL OUTDOOR OLW
Catalog
Number
Notes
Type
