Specification Sheet

Catalog Number
Notes Type
FLUORESCENT BATTERY PACKS
PSQ500QD
1 of 2One Lithonia Way Conyers, GA 30012 Phone: [phone] www.relocwiring.com ©1997-2013 Acuity Brands Lighting, Inc. All rights reserved 4/8/13
ORDERING LOGIC
All congurations of this product are considered “standard” and have short lead times.
PSQ500QD MVOLT
Designation
Battery pack Remote or replacement test switch/pilot light;
mounts up to 25’ away from xture
Remote mounting enclosure
Accessories
1
(Order as separate item)
NOTES
1. See Inverter Accessories specication sheets for details
on other compatible devices.
PSQ500QD ELA TSPLP
ELA PSRME
by
Lead times will vary depending on options selected. Consult with your sales representative.
Example: PSQ500QD
FEATURES & SPECIFICATIONS
INTENDED USE
Patented labor saving design installs in 15 minutes or less, especially designed for field installa-
tion. Factory or field installed inside or ourside (Field only) fluorescent fixture to operate lamp(s) at
reduced light output, providing optimum glare-free illumination for a minimum of 90 minutes upon
interruption of normal power.
CONSTRUCTION
• Labor-saving design - 1/3 fewer wired and fewer connections than typical fluorescent power packs.
Engineering-grade charcoal gray plastic housing is impact-resistant, corrosion resistant and scratch-
resistant.
• UL94-04 flame rating
• U.S. Patent No. 6,522,147.
• Patented integrated test switch pilot light that requires only one-hole drilling.
PERFORMANCE
Operates one 2’- 4’ or U-shaped fluorescent lamp for 90 minutes. (Compatible with most electronic T8
and magnetic T12, instant start, rapid start and slimline ballasts).
ELECTRONIC
• Multi-voltage input capability (120V or 277V).
• Additional input lead provided to allow switching of fixture.
• Constant-current type charger.
• Input circuit provides high efficiency and reliable operation.
• High-efficiency push-pull inverter is the most effective method of converting DC power. It provides
maximum light output, battery life and reliability.
BATTERY
Sealed, maintenance-free, high-temperature nickel cadmium battery. Ensures long life over a wide
range of temperatures. Automatic battery recharge after 90-minute discharge. Fully charged after 24
hours.
INSTALLATION
• Patented Quick-Disconnect connector system allows for easy replacement capabilities.
• Push-nuts and insulation-displacement connectors reduce installation time. Custom, one-piece test
switch/pilot light allows for mounting flexibility.
• Mounts concealed within fixture wireway for clean appearance and protection against vandalism.
• Compact size (9.5” L x 2.5” W x 1.18” H) allows installation in a variety of fluorescent fixtures:
troffers, industrials, commercials and strips.
• Unit mounting centers are identical to a standard ballast.
• Unit wires two ways: on night light circuit (permanently energized) or on switchable circuit
(unswitched circuit to the battery charger and switched circuit to the fixture ballast). Unit will strike
normally off lamp.
LISTING
• UL listed. Meets UL 924, NFPA 101 (current Life Safety Code), NEC and OSHA
illumination standards.
• Standard unit is UL approved for installation in sealed and gasketed fixtures.
• For product UL approved for use in wet and damp location fixtures, see PSQ500DW specification
sheet.
WARRANTY
Three-year total customer satisfaction warranty. (For complete details, see warranty page in
Product Selection Guide).
H - 1.18”
W - 2.5”
L - 9.5”
