Specification

Wafer LED Recessed Downlight
WF4
4” LED Module
IC/Non-IC
New Construction/Remodel
Specifications
Aperture: 3.2 (8.1)
Ceiling opening: 4.2 (10.7)
Overlap trim: 4.7 (12.0)
Height: 1.1 (2.8)
All dimensions are inches (centimeters) unless otherwise indicated.
FEATURES & SPECIFICATIONS
INTENDED USE — The 4" Wafer-Thin LED recessed downlight with remote driver box combines high
quality light output and efficiency while eliminating the pot light housing for competitive affordability.
This innovative wafer-slim Type IC design allows easy installation for new construction or remodel from
below the ceiling without the requirement of a pot light housing. The LED module maintains at least 70%
light output for 36,000 hours. These LED Wafer downlights are intended for closets, attics, hallways,
bathrooms, kitchens, basements, soffits, entry ways, porches, garages, stairwells, corridors, nursing/
retirement homes, condos, elevators, apartments, and any other small areas.
CONSTRUCTION — Ideal for shallow ceiling plenum since a pot light housing is NOT required. IC rated
driver and fixture - approved for direct contact with insulation. Aluminum die cast outer frame. Durable,
powder coat paint to prevent rust. Round fixture with integral edge-lit LED's. Steel spring clip for easy
installation. Plenum rated cable connector to connect from module to remote driver box. Isolated
driver integrated inside steel remote box with four 7/8" knockouts with slots for pryout. Not suitable
for pulling wires.
OPTICS — Wafer-Thin downlight edge-lit LED technology uses light guided plate to distribute light.
Polycarbonate lens provides even illumination throughout the space. Utilized 3000K and 4000K color
temperature LEDs.
ELECTRICAL — Connect directly to 120V power supply via provided UL recognized driver. High efficient
driver with power factor > 0.9. Ambient operating temperature: -40°F (-40°C) to +104°F (+40°C).
Dimming down to 10% (See page 2 for recommended dimmers). Standard input wattage is 9.6W, 70
lumens per watt.
LISTINGS — CSA certified to Canadian safety standards. ENERGY STAR® certified. Wet location. Air Tight
certified in accordance with ASTM E283-2004.
WARRANTY — 5-year limited warranty. Complete warranty terms located at:
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
Note: Actual performance may differ as a result of end-user environment and application.
All values are design or typical values, measured under laboratory conditions at 25 °C.
Specifications subject to change without notice.
DOWNLIGHTING WF4
D
I
M
M
A
B
L
E
WF4 LED MW
Series Lamp CCT/CRI/W/Lumens
1
Finish
WF4 4" wafer-thin LED downlight LED LED 30K 3000K/80CRI/9.6W/675L
40K 4000K/80CRI/10W/765L
MW Matte white
MB Matte black
BN Brushed nickel
ORB Oil-rubbed bronze
ORDERING INFORMATION
For shortest lead times, configure product using standard options (shown in bold).
Example: WF4 LED 30K MW
Catalog
Number
Notes
Type
3.2"
(8.1)
4"
(10.2)
4.7"
(12.0)
1.1"
(2.8)
4"
(10.2)
1.3"
(3.3
)
3"
(7.6
)
Accessories: Order as separate catalog number.
WF4 PAN R12 4" new construction pan, retail pack of 12
WFJB R4 Remodel joist bar, retail pack of 4
WFEXC6 U 6' FT4 cable
WFEXC10 U 10' FT4 cable
WFEXC20 U 20' FT4 cable
Matte black Brushed nickel Oil-rubbed bronze
Notes
1 Total system
delivered lumens.
WF3_Pan Joist Extension Cable
