Data Sheet

WP2.6-12 12Volt 2.6Ah
Specifications
Nominal Voltage(V) 12V
Nominal Capacity
20 hour rate (0.13A to 10.50V) 2.6Ah
10 hour rate (0.247A to 10.50V)
2.47Ah
5 hour rate (0.442A to 10.20V) 2.21Ah
1 C (2.6A to 9.60V)
1.473Ah
3 C (7.8A to 9.60V)
1.04Ah
Weight Approx. 1.0kg(2.2Lbs.)
Internal Resistance (at 1KHz) Approx. 22 m
Dimensions mm(inch)
Maximum Discharge Current for
5 seconds: 39A
Charging Methods at 25(77)
Cycle use:
Charging Voltage 14.4 to 15.0V
Coefficient -5.0mV/
/cell
Maximum Charging Current
0.78A
Standby use:
Float Charging Voltage 13.5 to 13.8V
Coefficient -3.0mV//cell
Operating Temperature Range
Charge -15(5) to 40(104)
Discharge
-15(5) to 50(122)
Storage
-15(5) to 40(104)
Charge Retention (shelf life) at 20(68)
1 month 92
3 month
90
6 month
80
Case Material ABS UL94 HB
Option: Flammability resistance of (UL94 V-0)
Te rm i na l F1 or F2 (Faston Tab 187 or 250)
34.5 1(1.36 0.04)±±
178 1(7.01 0.04)±±
66 1(2.60 0.04)±±
60 1(2.36 0.04)±±
6. 35( 0. 25)
3. 2(0.126)
(Faston Tab 187)
4.75
(0.19)
0.8
(0.03)
F1
7.95(0.313)
3.4(0.134)
(Faston Tab 250)
6.35
(0.25)
0.8
(0 . 0 3 )
F2
2 4 6 8 10 20 40 60 2 5 6 8 10 20
1
8.0
9.0
10.0
11.0
12.0
13.0
FOR 12V
BATTERY
(v)
Discharge Time VS. Discharge Current (25 )
minutes
hours
7.8A
2.6A
0.442A
0.247A
0.13A
Discharge Time
