Installation & Assembly

/ 11
FIXTURE
FASTENING
SCREWS
x4 PCS
MOUNTING SCREWS
AND WASHERS X 4 PCS
MOUNTING ANCHORS
X 4 PCS
FIRE PAN
HOT WIRE
(SMOOTH/BLACK)
NEUTRAL
(RIBBED/WHITE)
HOT WIRE
GROUND
(BARE COPPER/GREEN)
GROUND
NEUTRAL
SILICONE
WHEN MOUNTING IN WET LOCATION,
APPLY A BEAD OF SILICONE AROUND
THE PERIMETER OF THE FIXTURE BASE
TO SEAL THE ELECTRICAL
CONNECTIONS FROM WATER.
COLUMN LIGHT
UNIVERSAL MOUNTING INSTRUCTIONS
CAUTION : DISCONNECT POWER
ALWAYS SHUT OFF POWER WHEN INSTALLING OR REPAIRING THIS, OR ANY OTHER ELECTRICAL
APPLIANCE. FAILURE TO DO SO MAY RESULT IN SEVERE INJURY OR DEATH.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY
A PERSON FAMILIAR WITH CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS
INVOLVED.
