WA-410 Wireless Home Security System Instruction Manual

listed below. It will automatically advance to the next sequencing learning
order position.
11
7. If the sensor that was learnt into the main console is sending a signal during
the learning mode, the main console will indicate on the LCD, as shown
below and will not allow duplication.
8. If the sensors “learned” reaches 63 zone numbers, the LCD panel will show
a full message memory.
3.3: Replacement Menu
When the sensor becomes faulty and needs to be replaced with a new one you will need
to activate the menu. To replace the original sensor, key-in the sequence learning order
number and press ENTER . Trigger the sensor, and the new sensor will “learn’ into the
main console.
Note: Please use the same type of sensor to replace the old one.
Press 2 to go into the replace sensor mode.
Once replaced, It will go back to the system menu as shown below.
3.4: Clear Menu
Clear Sensors ( 1 - Single 2 – All )
Select 1- Single, key-in the sequencing learning order number and press
ENTER . It will clear that sensor. If you select 2- All, all learned sensors will
SYS_OPTS: 0-SYS_OPTS
1 – SEQ 2 – REPLAC 3 - CLR
Trigger Sensor To
Replace 01
Replace Sensor
Enter Sensor Num :
Sensor Already
Exists in System 02
Sequential Pgming
Mem Full 63
Sequential Pgming
Trigger Sensor 02
Sequential Pgming
Sensor Added
