92
Lorex Player for Mac: Viewing Backed up Video on Mac
Lorex Player for Mac: Viewing Backed up Video
on Mac
Lorex Player for Mac allows you to view your backed up video files.
To install Lorex Player Mac:
1 Go to www.lorextechnology.com and
search for the model number of your DVR (look at the
label underneath your DVR for the model number).
2 Navigat
e to the product page for your DVR model and download Backup Player for MAC.
3 Extr
act the file and double-click the Lorex Mac Player installer (.pkg) file. Follow the
on-screen instructions to install the software.
Launching Lorex Player Mac:
• Click the Lorex Player Mac icon ( ) in the Dock or in your Applications List in Finder.
Lorex Player Mac Interface
Video playlist
Video slider
Hide video playlist
Frame by frame
Fast forward
Rewind
Stop
Play
Volume slider
Video window
Load new file
Load folder
Remove selected file
Clear playlist
Looped playback
