21
Recording
Recording
By default, the system is set to immediately record video from connected cameras in
Continuous Recording Mode.
• Recording—Continuous: Normal, c
ontinuous recording.
You can set the system to stop recording once the hard drive is full, or to continually record
by
overwriting previously recorded data. For more details, see “Configuring Hard Drive
Settings” on page 49.
Event Recording
The system also includes motion recording:
• Reco
rding—Motion: The system records when motion is detected by the camera.
Recording Audio
The system can also record audio for 1, 2, or 4 channels (depending on model). You must
have audio-capable cameras (not included) or self-powered microphones (not included) in
order to record audio on the system.
For details, see “Appendix D: Recording Audio” on page 114.
