Use and Care Manual

27
Playback and Backup
3 Click and drag on the area of the screen you would like to enlarge. The image zooms in on the
selected area.
• The box in the lower right-hand corner shows the entire camera picture with a black box
ar
ound the zoomed-in area.
• Click inside the box and drag to move the zoom area.
4 R
ight-click to exit and select a different zoom area. Right-click again to exit Zoom Mode and
return to Playback Mode.
Using Video Clip Backup (ECO Blackbox+ Series Only)
Video clip backup allows you to select a duration of video during playback mode and save
it to a USB flash drive (not included).
NOTE: Video clip backup is onl
y available when a single channel is selected for Playback.
To create a backup video clip:
1 Connect
a USB flash drive (not included) to one of the USB ports on the DVR.
2 Open Playback
mode with only one channel selected. For details, see “Playing Back
Recorded Video” on page 22.
3 C
lick the clip backup button ( ) to start your backup at the current playback time.
4 When
you want the backup clip to stop, click again.
TIP:
You can use fast forward or click-and-drag the video cursor to select the stop time for
the clip. This is useful because it allows you to backup longer segments of video without
having to watch the whole video each time. You must have enough space on your USB flash
drive to save the file.
Zoom icon
Click and drag to
zoom in on an
area
Click and drag inside the
box to move the zoom area
Right-click to exit and select
a different zoom area
Click to select the start and stop times
