7” LCD Video Surveillance System with 2 Indoor/Outdoor Day/Night Cameras Instruction Manual English Version 1.0 MODEL: SHS-2S7LD Series www.lorexcctv.com Copyright © 2007 LOREX Technology Inc.
Thank you for purchasing the SHS-2S7LD. Lorex is committed to providing our customers with a high quality, reliable security product. To learn more about this Video Surveillance Product, and to learn about our complete range of accessory products, please visit our website at: http://www.lorexcctv.com CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
Important Safeguards Important Safeguards In addition to the careful attention devoted to quality standards in the manufacture process of your video product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to assure your enjoyment and proper use of the video product and accessory equipment. Please read them carefully before operating and using your video product. Installation 1.
Important Safeguards Service Use 13. Servicing - Do not attempt to service this video equipment yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 19. Cleaning - Unplug the video product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 14.
General Precautions NOTE This equipment has been certified and found to comply with the limits regulated by FCC, EMC, and LVD. Therefore, it is designated to provide reasonable protection against interference and will not cause interference with other appliance usage.
Table of Contents Table of Contents SHS-2S7LD Features ............................................................................... 7 Getting Started .......................................................................................... 8 SHS-2S7LD - Front / Bottom Views .......................................................... 9 SHS-2S7LD - Side View ......................................................................... 10 Monitor Mount - Stand & Wall Mount .....................................
SHS-2S7LD Features SHS-2S7LD Features Monitor: • 7'' TFT LCD Monitor • 2 channels with auto scanning function that witches between cameras • Easy connection to TV, VCR or Monitor with the included A/V cable • OSD (On-screen Display) • Small footprint - fits on a desk like a picture frame • Wall mountable or Desk stand Cameras: • Two color indoor/outdoor cameras with audio included • Plug and Play Cameras: All-in-one camera cable (with Video, Audio & Power) plugs directly to the monitor and eliminates the
Getting Started Getting Started The SHS-2S7LD comes with the following components: 1 x 7” LCD Monitor 1 x Wall Mount Bracket 1 x Mounting Screws 2 x Phone Jack to RCA Camera Connector Cables 1 x Monitor Stand 2 x Cameras with Stands 1 x AV Cable 2 x 60’ (18m) Extension Cables 1 x Power Adapter CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM, INCLUDING ALL COMPONENTS SHOWN ABOVE.
SHS-2S7LD - Front / Bottom Views SHS-2S7LD - Front / Bottom Views 1 2 3 4 5 Front 1. CH1 / CH2 LED DISPLAY - Indicates the currently displayed Camera number with a solid green LED indicator light. When the System is in auto switching mode, a Green Blinking light will appear. Bottom 2. DC 12V - Connects the 12V DC Power adaptor. 3. CAM1 ~ CAM2 INPUTS - Camera inputs. 4. STAND MOUNT - Attachment point for the Stand. 5. AV OUTPUT - Connects the System to a secondary TV, Monitor or Recording Device.
SHS-2S7LD - Side View SHS-2S7LD - Side View 1. VOLUME +/- - Raises or Lowers the Volume from the System. 2.
Monitor Mount - Stand & Wall Mount Monitor Mount - Stand & Wall Mount This system has a variety of Mounting Options. It can be placed on a Table or Countertop, can be attached to a stand or wall mounted. Counter / Table - Vertical • Place the System in the desired viewing location. The system is designed to remain balanced when placed on any flat surface. Counter / Table - Picture Frame • The built-in stand is designed to flip out providing a Picture Frame look and feel for the System.
SHS-2S7LD Cameras SHS-2S7LD Cameras The System includes 2 Color Day/Night*, Indoor/Outdoor Cameras** with built in microphone. INFRARED LEDs* Provides illumination for low light conditions CAMERA LENS MICROPHONE - Provides one way audio from the Camera to the Monitor STAND Metal stand connects to the Camera for mounting to walls, ceilings and other surfaces INPUT CABLE (BACK) Connects Video / Power from the SHS-2S7LD switcher to the Camera * IR illumination range up to 13ft.
Camera Installation Camera Installation Before you install the camera, carefully plan where and how you will position the camera, and where you will route the cable that connects the camera to the SHS-2S7LD. Installation Warnings: • Select a location for the camera that provides a clear view of the area you want to monitor, which is free from dust, and is not in line-of-sight to a strong light source or direct sunlight.
Camera Installation Connecting Cameras 1. Connect the female end of the supplied 60’ extension’ cable to the camera. NOTE: Confirm that the arrows on the DIN Camera Cable and the DIN Extension cable are pointed together when connecting the cable. If the pins in the DIN Cable are bent, the Camera will NOT function. 2. Connect the RCA end of the supplied 60’ extension cable to the corresponding colored cables on the Camera Connector Cable. 3. Connect the Camera Connector Cable to CH1 or CH2 on the System.
(Optional) Connection to a TV / Monitor / VCR using the AV Cable (Optional) Connection to a TV / Monitor / VCR using the AV Cable The system can be connected to a secondary Monitor or to a Recording Device (i.e. VCR or DVD-RW) using the included Audio/Video Cable. This allows you to simultaneously view images on another screen, or record the live video. Connect the Phone Jack End o the Audio/Video Cable to the AV Output Port on the bottom of the System.
SHS-2S7LD System Specifications - Appendix #1 SHS-2S7LD System Specifications - Appendix #1 LCD 7” Resolution 480 x 234 Monitor Display Response Time: T-ON 15ms / T-OFF 20ms Video Inputs 1 Vp-p @ 75 ohms Audio Inputs 1 Vp-p @ 600 ohms Audio Output 1 Vp-p @ 600 ohms Audio One way audio (from Camera to Monitor) Supply Voltage 12 V DC; 1A; 50/60Hz Power Consumption Aprox.
Camera Specifications - Appendix #2 Camera Specifications - Appendix #2 Image Sensor 1/3” Color CMOS Pixels NTSC: 510 (H) x 492 (V) PAL: 628 (H) x 582 (V) Video Format NTSC / PAL Horizontal Resolution 330 TV Lines Scan System NTSC: 525 Lines 2:1 Interlace PAL: 625 Lines 2:1 Interlace Sync System Internal S/N Ratio > 48 db Iris AES AES Shutter Speed NTSC: 1/60~1/100,000 sec. PAL: 1/50~1/100,000 sec. Minimum Illumination 3 LUX without IR LED 8~15 LUX with IR LED Video Output 1.
