Advanced15Color TFT Monitor inch XGA TFTLCD LCD Color Monitor USER’S MANUAL 15 inch XGA TFT LCD Color Monitor Page 1
15 inch XGA TFT LCD Color Monitor CONTENTS 0. Connections 3 1. Quick Start 3 2. U.S. FCC Class B Notice 4 3. Product Overview 5 4. Plug & Play 5 5. Usage Notice 6 6. Package Checklist 7 7. Front Button 8 8. OSD Operation 9 9. Troubleshooting 13 10. Specifications 14 11.
15 inch XGA TFT LCD Color Monitor 0. CONNECTIONS Speaker Audio In Audio Out Analog RGB DC in PC VGA / Sound 12V Adapter 1. QUICK START (1) Connect the 15-pin D-sub connector to the VGA port of PC. (2) Connect the opposite side of VGA cable to TFT LCD monitor. (3) Plug in the Audio cables to the proper connecter of your monitor.
15 inch XGA TFT LCD Color Monitor (4) Plug in the power cord to AC/DC adapter power inlet and 110V / 220V consent. (5) Plug in the 12V DC output to TFT LCD monitor. (6) Adjust the tilt of your monitor. (7) Turn on PC and TFT LCD monitor. (8) Adjust the display. (XGA, 1024x768 pixels, 8 bit color) 2. U.S. FCC CLASS B NOTICE This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules.
15 inch XGA TFT LCD Color Monitor 3. PRODUCT OVERVIEW This 15” XGA TFT LCD Monitor, accepts standard analog RGB signal. This monitor supports XGA and lower resolutions at the frame frequency up to 75Hz. Lower resolution modes can be expanded to full screen through the expansion algorithm. The user interface includes Menu,Sel,Power,Down/Up. This monitor contains high-end LCD controller, which have high performance and user friendly interfaces. Fancy design monitor makes your desk simple and luxury.
15 inch XGA TFT LCD Color Monitor 5. USAGE NOTICE Warning Please do not open or disassemble the products, because it may cause electric shock. Please be advised all the warnings, precautions, and maintenance advice as recommended in this user’s manual in order to maximize the life of your monitor. Do: • • • • Turn off the monitor before cleaning its surface. Periodically wipe its surface with a soft and dry cloth. Use the quality and safety-approved AD/DC adapter.
15 inch XGA TFT LCD Color Monitor 6. PACKAGE CHECKLIST 15” TFT LCD MONITOR * Attention Monitor and stand part are packed disassembled. Please be careful not to drop the stand part when you take the monitor out of protecting styrofoam.
15 inch XGA TFT LCD Color Monitor 7. FRONT BUTTON Menu Down Sel Up OSD Function Button Function Menu Activate menu/Exit Menu Exit Sub-Menu/ Move to previous Menu SEL POWER LED Status Brightness/Contrast/Color Etc….
15 inch XGA TFT LCD Color Monitor 8. OSD OPERATION 8.1 BRIGHTNESS CONTROL - This control allows you to make adjustments to brightness of the display screen Menu > Sel > Increase/Decrease Value(down/up) > Select 8.2 CONTRAST CONTROL - This control allows you to make adjustments to the contrast of the display screen 8.3 H-POSITION - Select this control menu, and then use down/up buttons to center the image horizontally on the screen.
15 inch XGA TFT LCD Color Monitor 8.4 V-POSITION - Select this control menu, and then use the down/up buttons to center the image vertically on the screen. 8.5 CLOCK - Select this control menu, and then use down/up buttons to optimize screen quality by removing noise. 8.6 CLOCK PHASE + - Select this control menu, and then use down/up buttons to adjust the screen image until it looks focused, crisp and sharp. One of the good points of LCD Monitor.
15 inch XGA TFT LCD Color Monitor 8.7 COLOR CONTROL - Select this control menu, then scroll to the desired color temperature among 9300K, 6500K or USER for custom setting. In User Mode, adjust R,G,B color control. 8.8 LANGUAGE - Select this control menu, choose from English (ENGLISH), German (DEUTSCH), Spanish (ESPAÑOL), Italian (ITALIANO), French (FRANÇAIS). 8.9 INFORMATION - Select this menu allows you to confirm information of the display.
15 inch XGA TFT LCD Color Monitor 8.10 OSD - Select this control menu, and then use the button to select the duration time for the OSD menu. Use the down/up buttons to select the time, to center the OSD image horizontally & vertically on the screen. 8.11 AUTO ADJUST - This control will automatically make adjustments to the horizontal and vertical size, horizontal and vertical position, phase and color. 8.
15 inch XGA TFT LCD Color Monitor 9. Troubleshooting Warning Please do not open the monitor, because it may cause electric shock to the customer. Also, the warranty program may not support the damages, which user causes. When problem persists in spite of trying the following troubleshooting advice, please contact dealer or the repair center listed. Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
15 inch XGA TFT LCD Color Monitor 10. Specifications Model 15 inch XGA TFT LCD Color Monitor Display Type Color Pitch Screen size Back light Resolution (max.) Contrast ratio Brightness 15” Color Active Matrix TFT LCD 16.7Million (8 bit/color) 0.3 x 0.3 mm 307.2(H) x 230.4(V) mm 2 CCFLs 1024 x 768(XGA) at 60 to 75Hz (Optimum 60Hz) 250:1 400 cd/m2 Video Sync frequency Input signal Viewing angle Vertical: 56 ~ 75Hz (Optimum 60Hz) Horizontal: 31.5 ~ 80KHz Analog RGB 0.
inch XGA TFT LCD Color Monitor 11. VIDEO MODE SUPPORT The modes are detected when presented to the input and previous alignments for setup are automatically recalled. A true multi-sync monitor emulation is implemented. The factory preset supported modes include: Mode*1 Resolution H-freq. Pixel freq. Remarks*1 VGA 640 x 350 70Hz 31.47KHz 25.175MHz VESA Standard VGA 720 x 400 59.940HZ 31.469KHZ 25.175MHZ IBM VGA 3H VGA 640 x 480 60Hz 31.5KHz 25.
