10. Specifications
Model 15 inch XGA TFT LCD Color Monitor
Display
Type 15” Color Active Matrix TFT LCD
Color 16.7Million (8 bit/color)
Pitch 0.3 x 0.3 mm
Screen size 307.2(H) x 230.4(V) mm
Back light 2 CCFLs
Resolution (max.) 1024 x 768(XGA) at 60 to 75Hz (Optimum 60Hz)
Contrast ratio 250:1
Brightness 400 cd/m
2
Video
Sync frequency Vertical: 56 ~ 75Hz (Optimum 60Hz)
Horizontal: 31.5 ~ 80KHz
Input signal Analog RGB 0.714 V
P-P
, 15 Pin D-sub type
Viewing angle Up/Down: 60º / 60º
Right/Left: 70º / 70º
Audio
Speaker 1W x 2
Compatibility
Plug & Play VESA DDC 1/2B
Compatibility VESA / IBM / MAC
Power Management VESA Standard, DPMS
Operating Conditions
Power Consumption Operating: 35 watt max.
Stand-by: 3.5 watt max.
Temperature Operating: 0 ºC ~ 40 ºC
Storage: -20 ºC ~ 60 ºC
Humidity Operating: 10% ~ 85% R.H.
Non-Operating: 90% R.H. Max.
User control
OSD Menu / Sel / Power / Down /Up
Mechanical
Size Packed : 412 (W) x 141 (D) x 440 (H) mm
Weight Packed : 3.5 kg
