15 inch XGA TFT LCD Color Monitor
11. VIDEO MODE SUPPORT
The modes are detected when presented to the input and previous alignments for setup are
automatically recalled. A true multi-sync monitor emulation is implemented.
The factory preset supported modes include:
VESA Standard
Mode
*1
Pixel freq.Resolution
640 x 350
Industry Standard
VESA Standard
IBM VGA 3H720 x 400
640 x 480
640 x 480
VESA Standard
VESA Guidelines
640 x 480
800 x 600
VESA Standard
VESA Standard
800 x 600
800 x 600
Refresh rate H-freq.
VESA Guidelines1024 x 768
VESA Standard
VESA Standard1024 x 768
1024 x 768 60KHZ
56.5KHz
VGA
VGA
VGA
VGA
VGA
SVGA
SVGA
SVGA
XGA
XGA
XGA
48.4KHz
46.9KHZ
48.1KHz
37.9KHz
37.5KHZ
37.9KHz
31.5KHz
31.469KHZ
31.47KHz
75HZ
70Hz
60Hz
75HZ
72Hz
60Hz
75HZ
72Hz
60Hz
59.940HZ
70Hz
78.750MHZ
75.000MHz
65.000MHz
49.500MHZ
50.000MHz
40.000MHz
31.500MHZ
31.500MHz
25.175MHz
25.175MHZ
25.175MHz
Remarks
*1
Notes:
1. All mentioned modes are non-interlaced. The maximum and minimum frame rates are determined by the TFTLCD.
2. Factory preset modes are overwritten by additional user alignments for automatic recall. At all times it remains
possible to recall the initial factory presets.
