Logic MegaRAID Express User's Guide

MegaRAID Express 500 Hardware Guide
104
DOS ASPI Driver Error Messages
Message Corrective Action
LSI Logic ASPI Manager has
NOT been loaded.
The ASPI manager is not loaded. One of the failure
codes listed below is displayed next.
Controller setup FAILED
error code=[0xab]
Correct the condition that caused the failure. The failure
codes are:
0x40 No MegaRAID adapters found
0x80 Timed out waiting for interrupt to be posted
0x81 Timed out waiting for MegaRAID Express
500 Response command.
0x82 Invalid command completion count.
0x83 Invalid completion status received.
0x84 Invalid command ID received.
0x85 No MegaRAID Express adapters found or no
PCI BIOS support.
0x90 Unknown Setup completion error
No non-disk devices were
located
The driver did not find any non-hard drive devices
during scanning. A SCSI device that is not a hard disk
drive, such as a tape drive or CD-ROM drive, must be
attached to this SCSI channel. The SCSI ID must be
unique for each adapter and cannot be SCSI ID 0. The
supported SCSI IDs are 1, 2, 3, 4, 5, and 6.
'ERROR: VDS support is
*INACTIVE* for
MegaRAID Express logical
drives
The /h option is appended to driver in
CONFIG.SYS or this driver is used with a BIOS that is
earlier than v1.10, or no logical drives are configured.
