MegaRAID Express 500 Hardware Guide
110
68-Pin High Density Connectors,
Continued
Converting Internal Wide to Internal Non-Wide (Type 2)
The cable assembly for converting internal
wide SCSI connectors to internal non-wide SCSI connectors is shown below:
pin 1
pin 1
Connector A: 68 position plug (male)
AMP - 749925-5
Connector B:50 position IDC receptacle (female)
AMP - 499252-4, 1-746285-0, 1-746288-0
Wire: Twisted-Pair Flat Cable or
Laminated Discrete Wire Cable
25 pair 0.050 centerline
28 AWG
A
B
B
pin 1
68 POSITION
CONNECTOR
CONTACT NUMBER
50 POSITION
CONNECTOR
CONTACT NUMBER
16
240
37
441
2049
2116
2250
2317
4729
4863
4930
5064
2451
2518
2652
2719
*
*
*
*
*
*
OPEN
OPEN
OPEN
TABLE 1: CONNECTOR CONTACT
CONNECTION FOR WIDE
TO NON-WIDE CONVERSION
Cont’d
