MegaRAID Express 500 Hardware Guide
30
RAID Management Features
The RAID management features include:
Specification Feature
Support for SNMP Yes
Performance Monitor provided Yes
Remote control and monitoring Yes
Event broadcast and event alert Yes
Hardware connector RS232C
Drive roaming Yes
Support for concurrent multiple stripe
sizes
Yes
Web-based management tools Not released yet
Windows NT and NetWare server
support via GUI client utility
Yes
SCO Unix, OS/2, and UnixWare
server support via GUI client utility
Yes
DMI support Yes
Management through an industry-
standard browser
Not released yet
Fault Tolerance Features
The fault tolerance features include:
Specification Feature
Support for SMART Yes
Enclosure management SAF-TE compliant
Drive failure detection Automatic
Drive rebuild using hot spares Automatic
Parity Generation and checking Software
